Brand Gigabyte Form Factor mATX Memory Type DDR4 Socket AM4 CPU AMD Socket AM4 Chipset AMD B450 Memory 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory Onboard Graphics Port 1 x HDMI port* Support for HDMI 2.1 version and HDCP 2.2 Audio Realtek® Audio codec LAN Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps) Expansion Slots 1 x PCI Express x16 slot, running at x16 (PCI Express 3.0)1 x PCI Express x16 slot, running at x1 (PCI Express 3.0)1 x PCI Express x1 slot (PCI Express 2.0) Storage Interface 1 x M.2 connector (PCI Express 3.0)4 x SATA 6Gb/s connectors USB 2 x USB 3.1 Gen 1 ports available through the internal USB header6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)4 x USB 3.1 Gen 1 ports on the back panel Internal I/O Connectors 1 x 24-pin ATX main power connector1 x 8-pin ATX 12V power connector1 x CPU fan header1 x system fan header1 x CPU cooler LED strip/RGB LED strip header1 x RGB LED strip header2 x addressable LED strip headers1 x M.2 Socket 3 connector4 x SATA 6Gb/s connectors1 x front panel header1 x front panel audio header1 x S/PDIF Out header1 x USB 3.1 Gen 1 header1 x USB 2.0/1.1 header1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only)1 x serial port header1 x Clear CMOS jumper Back Panel Connectors 1 x PS/2 keyboard/mouse port1 x HDMI port4 x USB 3.1 Gen 1 ports4 x USB 2.0/1.1 ports1 x RJ-45 port3 x audio jacks Operating System Support for Windows 11 64-bitSupport for Windows 10 64-bitSupport for Windows 7 64-bit Form Factor Micro ATX Form Factor; 24.4cm x 21.5cm

Read more less

 Specifications: Form Factor:  Micro-ATX (m-ATX)  Socket:  AMD AM4  Chipset:  AMD B450  CPU Support:  Compatible with AMD Ryzen™ processors (5000, 4000, 3000, 2000, 1000 series) and Athlon™ processors  Memory: Four DDR4 DIMM sockets  Up to 128GB system memory  Dual-channel memory architecture  Supports DDR4 2933/2667/2400/2133 MT/s and XMP profiles  Expansion Slots: 1x PCIe 3.0 x16 slot  Additional PCIe slots for expansion  Storage: 1x M.2 slot (PCIe 3.0 x4) for high-speed SSDs, supporting up to 32Gb/s  4x SATA 6Gb/s ports  Supports RAID 0, 1, and 10  Networking:  Realtek® GbE LAN chip (1 Gbps)  Audio:  Realtek® Audio codec for 2/4/5.1/7.1-channel high definition audio  Rear Panel Ports: HDMI (HDMI 2.1) for video output  USB 3.0 ports  USB 2.0 ports  Audio and LAN ports

Read more less

Specifications: Brand:  Gigabyte  Model:  GA-B450M-DS3H-WIFI  Socket:  AM4  Chipset:  AMD B450  Form Factor:  Micro-ATX (MATX)  Memory: 4 x DDR4 DIMM sockets  Supports up to 128GB system memory  Dual-channel memory architecture  Expansion Slots: 1 x M.2 connector with SSD support  PCIe slots  Storage: 1 x M.2 slot  4 x SATA ports  Networking: Intel Dual Band Wireless-AC 802.11ac and Bluetooth 4.2  Realtek GbE LAN port  Audio: Realtek Audio CODEC  High Definition Audio  Connectors: HDMI and DVI-D ports for display output  USB ports, including USB 3.1 Gen 1  CPU Support: AMD Ryzen™ 5000 series  Ryzen™ 5000 G-Series  3rd Gen Ryzen™  2nd Gen Ryzen™  1st Gen Ryzen™  Athlon™ with Radeon™ Vega Graphics

Read more less

AMD B450 Ultra Durable Motherboard with GbE LAN and Bandwidth Management, ​PCIe Gen3 x4 M.2, Anti-Sulfur Resistor Design​ Supports AMD Ryzen™ 5000 series / Ryzen™ 5000 G-Series/ 3rd Gen Ryzen™/ 2nd Gen Ryzen™/ 1st Gen Ryzen™/ 2nd Gen Ryzen™ with Radeon™ Vega Graphics/ 1st Gen Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors​ Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs​ PCIe Gen3 x4 M.2 with PCIe NVMe & SATA mode support​ GbE LAN with Bandwidth Management​ 8-Channel HD Audio with High Quality Audio Capacitors​ Smart Fan 5 features 5 Temperature Sensors and 2 Hybrid Fan Headers​ GIGABYTE APP Center, Simple and Easy Use​ NVMe PCIe Gen 3x4 22110 M.2 Connector GIGABYTE Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their system’s potential. GbE LAN with Bandwidth Management GbE LAN features a network bandwidth management application which helps to improve network latency and maintain low ping times to deliver better responsiveness in crowded LAN environments. AUDIO High-End Audio Capacitors GIGABYTE motherboards use high-end audio capacitors. These high-quality capacitors help deliver high resolution and high-fidelity audio to provide the most realistic sound effects for gamers. Audio Noise Guard GIGABYTE motherboards feature an audio noise guard that essentially separates the board’s sensitive analog audio components from potential noise pollution at the PCB level. Humidity Protection Glass Fabric PCB There is nothing more harmful to the longevity of your PC than moisture, and most parts of the world experience moisture in the air as humidity at some point during the year. GIGABYTE motherboards have been designed to make sure that humidity is never an issue, incorporating a new Glass Fabric PCB technology that repels moisture caused by humid and damp conditions. Glass Fabric PCB technology uses a new PCB material which reduces the amount of space between the fiber weave, making it much more difficult for moisture to penetrate compared to traditional motherboard PCBs. This offers much better protection from short circuit and system malfunction caused by humid and damp conditions. High Temperature Protection Lower RDS (on) MOSFETs Design GIGABYTE motherboards use Low RDS (on) MOSFETs which reduce energy wastage through unnecessary residual heat dissipation. This all amounts to tangible energy savings which are beneficial for both end-users and the environment without impacting system performance. SPECIFICATIONS:  CPU AMD Socket AM4, support for: AMD Ryzen™ 5000 Series Processors/ AMD Ryzen™ 5000 G-Series Processors/ AMD Ryzen™ 4000 G-Series Processors/ 3rd Generation AMD Ryzen™ processors/ 2nd Generation AMD Ryzen™ processors/ 1st Generation AMD Ryzen™ processors/ 2nd Generation Ryzen™ with Radeon™ Vega Graphics processors/ 1st Generation Ryzen™ with Radeon™ Vega Graphics processors/ Athlon™ with Radeon™ Vega Graphics Processors (Please refer "CPU Support List" for more information.) Chipset AMD B450 Memory Support for DDR4 3600(O.C.)/3466(O.C.)/2933/2667/2400/2133 MHz memory modules 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules (Please refer "Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor: 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz Support for HDMI 2.0 version and HDCP 2.2. Maximum shared memory of 16 GB Audio Realtek® Audio CODEC High-Definition Audio 2/4/5.1/7.1-channel You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. LAN Realtek® GbE LAN chip (1 Gbps/ 100 Mbps) Expansion Slots CPU: 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16* Actual support may vary by CPU. Chipset: 1 x PCI Express x1 slot, supporting PCIe 2.0 and running at x1 Storage Interface 1 x M.2 connector (Socket 3, M key, type 22110/2280/2260/2242 SATA and PCIe 3.0 x4/x2(Note) SSD support) * Refer to "2-7 Internal Connectors," for the installation notices for the M.2 connector. 4 x SATA 6Gb/s connectors RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices RAID 0, RAID 1, and RAID 10 support for SATA storage devices (Note) Supports only M.2 SATA SSDs when using an Athlon™ with Radeon™ Vega Graphics Processors. USB Chipset: 2 x USB 3.2 Gen 1 ports available through the internal USB header 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers) CPU: 4 x USB 3.2 Gen 1 ports on the back panel Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x system fan header 1 x M.2 Socket 3 connector 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only) 1 x speaker header 1 x Clear CMOS jumper 1 x chassis intrusion header Back Panel Connectors 1 x PS/2 keyboard port 1 x PS/2 mouse port 1 x HDMI 2.0 port 4 x USB 3.2 Gen 1 ports 2 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks I/O Controller iTE® I/O Controller Chip H/W Monitoring Voltage detection Temperature detection Fan speed detection Fan fail warning Fan speed control Whether the fan speed control function is supported will depend on the cooler you install. BIOS 1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. @BIOS EasyTune Smart Backup System Information Viewer Support for Q-Flash Support for Xpress Install Bundled Software Norton® Internet Security (OEM version) LAN bandwidth management software Operating System Support for Windows 11 64-bit Support for Windows 10 64-bit Support for Windows 7 64-bit * To support Windows 7 64-bit, you must install an AMD Pinnacle Ridge & Summit Ridge CPU. * Please download the "Windows USB Installation Tool" from GIGABYTE's website and install it before installing Windows 7. Form Factor Micro ATX Form Factor; 24.4cm x 19.5cm

Read more less

Category Specifications CPU AMD Socket AM4, support for: AMD Ryzen™ 5000 Series / Ryzen™ 5000 G-Series / Ryzen™ 4000 G-Series / Ryzen™ 3000 Series / Ryzen™ 3000 G-Series Processors(Refer to “CPU Support List” for more information.) Chipset AMD B550 Memory 4 x DDR4 DIMM sockets, up to 128 GB (32 GB per DIMM)Supports DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHzDual channel architectureSupports ECC and non-ECC Un-buffered DIMMsSupports Extreme Memory Profile (XMP) modules Onboard Graphics Integrated Graphics Processor:• 1 x DisplayPort (max 5120x2880@60 Hz, DP 1.4, HDCP 2.3, HDR)• 1 x HDMI (max 4096x2160@60 Hz, HDMI 2.1, HDCP 2.3, HDR)• Max shared memory: 16 GB Audio Realtek® ALC1200 codecHigh Definition Audio2/4/5.1/7.1-channelSupports S/PDIF Out LAN Realtek® 2.5GbE LAN chip (2.5 Gbit / 1 Gbit / 100 Mbit) Wireless Communication Intel® Wi-Fi 6 AX200Wi-Fi a/b/g/n/ac/ax (2.4/5 GHz Dual-Band)Bluetooth® 5Supports 11ax 160MHz, up to 2.4 Gbps (actual speed varies) Expansion Slots • 1 x PCIe x16 (CPU): PCIe 4.0 x16 (Ryzen 5000/3000), PCIe 3.0 x16 (Ryzen G-Series)• 1 x PCIe x16 (Chipset): PCIe 3.0 x2• 1 x PCIe x16 (Chipset): PCIe 3.0 x1• 1 x PCIe x1 (Chipset): PCIe 3.0 x1 Storage Interface • 1 x M.2 (M2A_CPU): 2242/2260/2280/22110 SSDs– PCIe 4.0 x4/x2 (Ryzen 5000/3000)– PCIe 3.0 x4/x2 (Ryzen G-Series)• 1 x M.2 (M2B_SB): PCIe 3.0 x4/x2 & SATA support• 4 x SATA 6Gb/s ports (RAID 0/1/10) USB CPU:– 2 x USB 3.2 Gen 2 Type-A (red, Ryzen 5000/3000)– 2 x USB 3.2 Gen 1 (red, Ryzen G-Series)– 2 x USB 3.2 Gen 1 on back panelChipset:– 1 x USB Type-C (USB 3.2 Gen 1, internal)– 1 x USB 3.2 Gen 1 (rear)– 2 x USB 3.2 Gen 1 (internal header)– 2 x USB 2.0 (rear)Chipset + Hub:– 4 x USB 2.0 (internal headers) Internal I/O 1 x 24-pin ATX main power1 x 8-pin ATX 12V2 x M.2 sockets4 x SATA 6Gb/s1 x CPU fan header1 x water cooling fan header3 x system fan headers1 x CPU cooler RGB header2 x addressable LED headers2 x RGB LED headers1 x front panel header1 x front audio header1 x USB Type-C header1 x USB 3.2 Gen 1 header2 x USB 2.0 headers1 x TPM header1 x Clear CMOS jumper Back Panel Connectors 1 x DisplayPort1 x HDMI2 x SMA antenna connectors2 x USB 3.2 Gen 2 Type-A (Ryzen 5000/3000 only)3 x USB 3.2 Gen 12 x USB 2.01 x Q-Flash Plus button1 x RJ-45 LAN port1 x optical S/PDIF Out5 x audio jacks I/O Controller iTE® I/O Controller Chip H/W Monitoring Voltage / Temperature / Fan Speed / Water Flow DetectionOverheat & Fan Fail WarningFan Speed Control (depends on fan model) BIOS 1 x 256 Mbit flashAMI UEFI BIOSPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center@BIOS, EasyTune, RGB Fusion, Smart Backup, System Information ViewerSupport for Q-Flash Plus & Q-Flash Bundled Software Norton® Internet Security (OEM)LAN bandwidth management software Operating System Windows 11 64-bit / Windows 10 64-bit Form Factor ATX, 30.5 cm x 24.4 cm

Read more less

AMD B550 Mini-ITX AORUS Motherboard with Direct 8 Phases Digital VRM, Advanced Thermal Design with Extended VRM Heatsink, Thermal Baseplate, Dual PCIe 4.0/3.0 M.2 with Thermal Guard, Intel® WiFi 6 802.11ax, 2.5GbE LAN, RGB FUSION 2.0, Q-Flash Plus SPECIFICATIONS:  Supports AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series and Ryzen™ 3000 Series Processors Dual Channel ECC/ Non-ECC Unbuffered DDR4, 2 DIMMs Direct 8 Phases Digital VRM Solution with 90A Smart Power Stage (SPS) Advanced Thermal Design with Extended & Multi-Layered Heatsink and Thermal Baseplate Ultra Durable™ PCIe 4.0 Ready x16 Slot Dual Ultra-Fast NVMe PCIe 4.0/3.0 x4 M.2 with Thermal Guard Onboard Intel® WiFi 6 802.11ax 2T2R & BT5 with AORUS Antenna AMP-UP Audio with ALC1220-VB and Nichicon Audio Capacitors for Rear 120dB SNR Blazing Fast 2.5GbE LAN with Bandwidth Management USB 3.2 Gen2 Type-C™ & DisplayPort + Dual HDMI Support RGB FUSION 2.0 Supports Addressable LED & RGB LED Strips Smart Fan 5 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card Pre-installed IO Shield for Easy and Quick Installation

Read more less

General specifications Form Factor:  Micro-ATX CPU Socket:  AM4 Chipset:  AMD B550 Supported Processors:  AMD Ryzen 5000 Series, Ryzen 5000 G-Series, Ryzen 4000 G-Series, and Ryzen 3000/3000 G-Series  Memory Slots:  4 x DDR4 DIMM Maximum Capacity:  128GB Memory Type:  ECC/Non-ECC Unbuffered Speed:  Up to 4733 MHz (OC)  Storage M.2 Slots:  Dual M.2 connectors supporting PCIe 4.0/3.0 SSDs SATA Ports:  4 x SATA 3 ports  Expansion and Graphics PCIe:  One PCIe 4.0 x16 slot Onboard Graphics: 1 x DVI-D port (1920x1200@60Hz) 1 x HDMI 2.1 port (4096x2160@60Hz) Max 16 GB shared memory  Audio Codec:  Realtek ALC887 (7.1-channel) or Realtek ALC1200 Features:  High-Quality Audio Capacitors and Audio Noise Guard  Networking LAN:  Realtek GbE LAN chip with Bandwidth Management  AMD B550 Ultra Durable Motherboard with Pure Digital VRM Solution, PCIe 4.0 x16 Slot, Dual PCIe 4.0/3.0 M.2 Connectors, Realtek GbE LAN, Smart Fan 5 with FAN STOP,  RGB FUSION 2.0, Q-Flash Plus Supports AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series/ Ryzen™ 3000 and Ryzen™ 3000 G-Series Processors Dual Channel ECC/ Non-ECC Unbuffered DDR4, 4 DIMMs 5+3 Phases Pure Digital VRM Solution with Low RDS(on) MOSFETs Ultra Durable™ PCIe 4.0 Ready x16 Slot Dual Ultra-Fast NVMe PCIe 4.0/3.0 M.2 Connectors High Quality Audio Capacitors and Audio Noise Guard for Ultimate Audio Quality Realtek GbE LAN with Bandwidth Management Rear HDMI & DVI Support RGB FUSION 2.0 Supports Addressable LED & RGB LED Strips Smart Fan 5 Features Multiple Temperature Sensors , Hybrid Fan Headers with FAN STOP Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card Anti-Sulfur Resistors Design Specification   B550M AORUS ELITE (rev. 1.0/1.1/1.2)  rev. 1.3 Key Features   Specification   Support   News & Awards   Buy CPU AMD Socket AM4, support for: AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series, Ryzen™ 3000 Series and Ryzen™ 3000 G-Series Processors (Please refer "CPU Support List" for more information.) Chipset AMD B550 Memory 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules** ECC memory (ECC mode) support varies by CPU Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules (Please refer "Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor: 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz* The DVI-D port does not support D-Sub connection by adapter. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz* Support for HDMI 2.1 version, HDCP 2.3, and HDR. Maximum shared memory of 16 GB Audio Realtek® Audio CODEC High Definition Audio 2/4/5.1/7.1-channel* To configure 7.1-channel audio, you need to open the audio software and select Device advanced settings > Playback Device to change the default setting first. Please visit GIGABYTE's website for details on configuring the audio software. LAN Realtek® GbE LAN chip (10/100/1000 Mbit) Expansion Slots 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU: AMD Ryzen™ 5000 Series* and Ryzen™ 3000 Series Processors support PCIe 4.0 x16 mode* Actual support may vary by AMD CPU's specification. AMD Ryzen™ Ryzen™ 5000 G-Series and Ryzen™ 4000 G-Series Processors support PCIe 3.0 x16 mode* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. 1 x PCI Express x16 slot (PCIEX4), integrated in the Chipset: Supporting PCIe 3.0 x4 mode 1 x PCI Express x1 slot (PCIEX1), integrated in the Chipset: Supporting PCIe 3.0 x1 mode Storage Interface 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2242/2260/2280/22110 SSDs: AMD Ryzen™ 5000 Series and Ryzen™ 3000 Series Processors support SATA and PCIe 4.0 x4/x2 SSDs AMD Ryzen™ Ryzen™ 5000 G-Series and Ryzen™ 4000 G-Series Processors support SATA and PCIe 3.0 x4/x2 SSDs 1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2242/2260/2280 SSDs: Supporting SATA and PCIe 3.0 x2 SSDs 4 x SATA 6Gb/s connectors, integrated in the Chipset: Support for RAID 0, RAID 1, and RAID 10 USB CPU: 4 x USB 3.2 Gen 1 ports on the back panel Chipset: 2 x USB 3.2 Gen 1 ports available through the internal USB header 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header) Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 2 x system fan headers 2 x addressable LED strip headers 2 x RGB LED strip headers 1 x CPU cooler LED strip/RGB LED strip header 2 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB 3.2 Gen 1 header 1 x USB 2.0/1.1 header 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only) 1 x serial port header 1 x Clear CMOS jumper 1 x Q-Flash Plus button ＊All fan headers are subject to support AIO_Pump, Pump and high performance fan with the capability of delivering up to 2A/12V @ 24W. Back Panel Connectors 1 x PS/2 keyboard/mouse port 1 x DVI-D port 1 x HDMI port 4 x USB 3.2 Gen 1 ports 4 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks I/O Controller iTE® I/O Controller Chip H/W Monitoring Voltage detection Temperature detection Fan speed detection Overheating warning Fan fail warning Fan speed control* Whether the fan speed control function is supported will depend on the cooler you install. BIOS 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.@BIOSEasyTuneFast BootON/OFF ChargeRGB FusionSmart BackupSystem Information Viewer Support for Q-Flash Plus Support for Q-Flash Support for Xpress Install Bundled Software Norton® Internet Security (OEM version) LAN bandwidth management software Operating System Support for Windows 11 64-bit Support for Windows 10 64-bit Form Factor Micro ATX Form Factor; 24.4cm x 24.4cm

Read more less

Specification CPU Support:  AMD AM4 socket, compatible with Ryzen 3000, 4000 G-Series, 5000, and 5000 G-Series Processors.  Memory:  Dual Channel DDR4 architecture with 4 DIMM slots, supporting up to 128 GB and frequencies up to 4733(OC) MT/s.  Expansion Slots: 1x PCIe 4.0 x16 slot with Quick Release design.  1x PCIe 4.0 M.2 slot.  Other PCIe slots for additional cards.  Storage:  2x M.2 slots, supporting both PCIe 4.0 and 3.0 standards.  Networking:  Realtek Gigabit LAN with Bandwidth Management for optimized network performance.  Onboard Graphics:  Supports up to 3 displays with HDMI, DisplayPort, and DVI-D output.  VRM Solution:  A Digital 5+3 phases Pure Digital VRM solution for stable power delivery.  Cooling:  Hybrid Fan Pin Headers and support for both Chassis and CPU fans. RGB:  2x Addressable LED Strip Headers for customizable lighting.  Form Factor:  Micro ATX (m-ATX).

Read more less

CPU AMD Socket AM4, support for: AMD Ryzen™ 5000 G-Series Processors/ AMD Ryzen™ 5000 Series Processors/ AMD Ryzen™ 4000 G-Series Processors/ AMD Ryzen™ 3000 Series Processors(Please refer "CPU Support List" for more information.) Chipset AMD B550 Memory 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memorySupport for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MT/s memory modulesDual channel memory architectureSupport for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modulesSupport for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modulesSupport for Extreme Memory Profile (XMP) memory modules(Please refer "Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor:- 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz* The DVI-D port does not support D-Sub connection by adapter.- 1 x DisplayPort, supporting a maximum resolution of 5120x2880@60 Hz* Support for DisplayPort 1.4 version, HDCP 2.3, and HDR.- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz* Support for HDMI 2.1 version, HDCP 2.3, and HDR. Support for up to 3 displays at the same timeMaximum shared memory of 16 GB Audio Realtek® ALC1220-VB CODEC* The back panel line out jack supports DSD audio.High Definition Audio2/4/5.1/7.1-channel* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. LAN Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps) Wireless Communication module AzureWave Wi-Fi AW-CB304NF (Realtek® RTL8821CE) (PCB rev. 1.7)- WIFI 802.11a, b, g, n, ac, supporting 2.4/5 GHz Dual-Band- BLUETOOTH 4.2- Support for 11ac wireless standard and up to 433 Gbps data rate(Actual data rate may vary depending on environment and equipment.) Expansion Slots  1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:- AMD Ryzen™ 5000 Series/3000 Series Processors support PCIe 4.0 x16 mode- AMD Ryzen™ 5000 G-Series/4000 G-Series Processors support PCIe 3.0 x16 mode* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.1 x PCI Express x16 slot (PCIEX4), integrated in the Chipset:- Supporting PCIe 3.0 x4 mode1 x PCI Express x1 slot (PCIEX1), integrated in the Chipset:- Supporting PCIe 3.0 x1 mode Storage Interface 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2280/22110 SSDs:- AMD Ryzen™ 5000 Series/3000 Series Processors support SATA and PCIe 4.0 x4/x2 SSDs- AMD Ryzen™ 5000 G-Series/4000 G-Series Processors support SATA and PCIe 3.0 x4/x2 SSDs1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2280 SSDs:- Supporting SATA and PCIe 3.0 x2 SSDs4 x SATA 6Gb/s connectors, integrated in the ChipsetSupport for RAID 0, RAID 1, and RAID 10 USB CPU:- 4 x USB 3.2 Gen 1 ports on the back panelChipset:- 2 x USB 3.2 Gen 1 ports available through the internal USB header- 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header) Internal I/O Connectors 1 x 24-pin ATX main power connector1 x 8-pin ATX 12V power connector1 x CPU fan header2 x system fan headers2 x addressable LED strip headers2 x RGB LED strip headers1 x CPU cooler LED strip/RGB LED strip header2 x M.2 Socket 3 connectors4 x SATA 6Gb/s connectors1 x front panel header1 x front panel audio header1 x USB 3.2 Gen 1 header1 x USB 2.0/1.1 header1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)1 x serial port header1 x Clear CMOS jumper1 x Q-Flash Plus button Back Panel Connectors 1 x PS/2 keyboard/mouse port1 x DVI-D port1 x DisplayPort1 x HDMI port2 x SMA antenna connectors4 x USB 3.2 Gen 1 ports4 x USB 2.0/1.1 ports1 x RJ-45 port3 x audio jacks I/O Controller iTE® I/O Controller Chip H/W Monitoring Voltage detectionTemperature detectionFan speed detectionOverheating warningFan fail warningFan speed control* Whether the fan speed control function is supported will depend on the fan you install. BIOS 1 x 128 Mbit flashUse of licensed AMI UEFI BIOSPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.- @BIOS- EasyTune- RGB Fusion- Smart Backup- System Information ViewerSupport for Q-Flash PlusSupport for Q-Flash Bundled Software Norton® Internet Security (OEM version)LAN bandwidth management software Operating System Support for Windows 11 64-bitSupport for Windows 10 64-bit Form Factor Micro ATX Form Factor; 24.4cm x 24.4cm

Read more less

SPECIFICATION CPU AMD Socket AM4, support for: AMD Ryzen™ 5000 G-Series Processors/ AMD Ryzen™ 5000 Series Processors/ AMD Ryzen™ 4000 G-Series Processors/ AMD Ryzen™ 3000 Series Processors(Please refer "CPU Support List" for more information.) Chipset AMD B550 Memory 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memorySupport for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MT/s memory modulesDual channel memory architectureSupport for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modulesSupport for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modulesSupport for Extreme Memory Profile (XMP) memory modules(Please refer "Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor:- 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz* The DVI-D port does not support D-Sub connection by adapter.- 1 x DisplayPort, supporting a maximum resolution of 5120x2880@60 Hz* Support for DisplayPort 1.4 version, HDCP 2.3, and HDR.- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz* Support for HDMI 2.1 version, HDCP 2.3, and HDR. Support for up to 3 displays at the same timeMaximum shared memory of 16 GB Audio Realtek® ALC1220-VB CODEC* The back panel line out jack supports DSD audio.High Definition Audio2/4/5.1/7.1-channel* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. LAN Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps) Wireless Communication module AzureWave Wi-Fi AW-CB304NF (Realtek® RTL8821CE) (PCB rev. 1.7)- WIFI 802.11a, b, g, n, ac, supporting 2.4/5 GHz Dual-Band- BLUETOOTH 4.2- Support for 11ac wireless standard and up to 433 Gbps data rate(Actual data rate may vary depending on environment and equipment.) Expansion Slots  1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:- AMD Ryzen™ 5000 Series/3000 Series Processors support PCIe 4.0 x16 mode- AMD Ryzen™ 5000 G-Series/4000 G-Series Processors support PCIe 3.0 x16 mode* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.1 x PCI Express x16 slot (PCIEX4), integrated in the Chipset:- Supporting PCIe 3.0 x4 mode1 x PCI Express x1 slot (PCIEX1), integrated in the Chipset:- Supporting PCIe 3.0 x1 mode Storage Interface 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2280/22110 SSDs:- AMD Ryzen™ 5000 Series/3000 Series Processors support SATA and PCIe 4.0 x4/x2 SSDs- AMD Ryzen™ 5000 G-Series/4000 G-Series Processors support SATA and PCIe 3.0 x4/x2 SSDs1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2280 SSDs:- Supporting SATA and PCIe 3.0 x2 SSDs4 x SATA 6Gb/s connectors, integrated in the ChipsetSupport for RAID 0, RAID 1, and RAID 10 USB CPU:- 4 x USB 3.2 Gen 1 ports on the back panelChipset:- 2 x USB 3.2 Gen 1 ports available through the internal USB header- 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header) Internal I/O Connectors 1 x 24-pin ATX main power connector1 x 8-pin ATX 12V power connector1 x CPU fan header2 x system fan headers2 x addressable LED strip headers2 x RGB LED strip headers1 x CPU cooler LED strip/RGB LED strip header2 x M.2 Socket 3 connectors4 x SATA 6Gb/s connectors1 x front panel header1 x front panel audio header1 x USB 3.2 Gen 1 header1 x USB 2.0/1.1 header1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)1 x serial port header1 x Clear CMOS jumper1 x Q-Flash Plus button Back Panel Connectors 1 x PS/2 keyboard/mouse port1 x DVI-D port1 x DisplayPort1 x HDMI port2 x SMA antenna connectors4 x USB 3.2 Gen 1 ports4 x USB 2.0/1.1 ports1 x RJ-45 port3 x audio jacks I/O Controller iTE® I/O Controller Chip H/W Monitoring Voltage detectionTemperature detectionFan speed detectionOverheating warningFan fail warningFan speed control* Whether the fan speed control function is supported will depend on the fan you install. BIOS 1 x 128 Mbit flashUse of licensed AMI UEFI BIOSPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.- @BIOS- EasyTune- RGB Fusion- Smart Backup- System Information ViewerSupport for Q-Flash PlusSupport for Q-Flash Bundled Software Norton® Internet Security (OEM version)LAN bandwidth management software Operating System Support for Windows 11 64-bitSupport for Windows 10 64-bit Form Factor Micro ATX Form Factor; 24.4cm x 24.4cm

Read more less

AMD Socket AM4：Supports AMD Ryzen™ 5000 / 4000 / 3000 Series Processors Digital 5+3 phases VRM solution Dual Channel DDR4：4*DIMMs EZ-Latch：PCIe slots with Quick Release Design Ultra-Fast Storage：2*M.2 slots, including PCIe 4.0 x1 Efficient Thermal：VRM Thermal Armor Advanced Fast Networking：GbE LAN Extended Connectivity：HDMI, Displayport PCIe UD Slot：PCIe 4.0 x16 slots with 10X strength for graphics card & Better Heat dissipation effect   Specification: CPU AMD Socket AM4, support for:AMD Ryzen™ 5000 G-Series Processors/AMD Ryzen™ 5000 Series Processors/AMD Ryzen™ 4000 G-Series Processors/AMD Ryzen™ 3000 G-Series Processors/AMD Ryzen™ 3000 Series Processors(Go to GIGABYTE's website for the latest CPU support list.) Chipset AMD B550 Memory 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity)of system memorySupport for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MT/s memory modulesDual channel memory architectureSupport for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modulesSupport for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modulesSupport for Extreme Memory Profile (XMP) memory modules(The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information.) Onboard Graphics Integrated Graphics Processor with AMD Radeon™ Graphics support:- 1 x DisplayPort, supporting a maximum resolution of 5120x2880@60 Hz * Support for DisplayPort 1.4 version, HDCP 2.3, and HDR. - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version, HDCP 2.3, and HDR.** Support for native HDMI 2.1 TMDS compatible ports. (Graphics specifications may vary depending on CPU support.)Maximum shared memory of 16 GB Audio Realtek® ALC1220 CODEC * The back panel line out jack supports DSD audio. High Definition Audio2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. LAN Realtek® GbE LAN chip (1 Gbps/100 Gbps/10 Mbps) Expansion Slots 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:AMD Ryzen™ 5000/3000 Series Processors support PCIe 4.0 x16 modeAMD Ryzen™ 5000 G/4000 G/3000 G Series Processors support PCIe 3.0x16 mode * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot. Chipset:- 1 x PCI Express x16 slot (PCIEX4), supporting PCIe 3.0 and running at x4- 1 x PCI Express x1 slot (PCIEX1), supporting PCIe 3.0 and running at x1 Storage Interface 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2280 SSDs:AMD Ryzen™ 5000/3000 Series Processors support SATA and PCIe 4.0x4/x2 SSDsAMD Ryzen™ 5000 G/4000 G/3000 G Series Processors support SATA and PCIe 3.0 x4/x2 SSDs1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2280 SATA and PCIe 3.0 x2 SSDs4 x SATA 6Gb/s connectorsRAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devicesRAID 0, RAID 1, and RAID 10 support for SATA storage devices USB CPU:- 4 x USB 3.2 Gen 1 ports on the back panelChipset:- 1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header- 2 x USB 3.2 Gen 1 ports available through the internal USB header- 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header) Internal I/O Connectors 1 x 24-pin ATX main power connector1 x 8-pin ATX 12V power connector1 x CPU fan header2 x system fan headers2 x addressable LED strip headers2 x RGB LED strip headers1 x CPU cooler LED strip/RGB LED strip header2 x M.2 Socket 3 connectors4 x SATA 6Gb/s connectors1 x front panel header1 x front panel audio header1 x USB Type-C® header, with USB 3.2 Gen 1 support1 x USB 3.2 Gen 1 header1 x USB 2.0/1.1 header1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)1 x serial port header1 x Clear CMOS jumper1 x Q-Flash Plus button Back Panel Connectors 2 x USB 2.0/1.1 ports1 x PS/2 keyboard/mouse port1 x HDMI port (Note)1 x DisplayPort (Note)4 x USB 3.2 Gen 1 ports1 x RJ-45 port3 x audio jacks(Note) Actual support may vary by CPU. I/O Controller iTE® I/O Controller Chip H/W Monitoring Voltage detectionTemperature detectionFan speed detectionOverheating warningFan fail warningFan speed control * Whether the fan speed control function is supported will depend on the fan you install. BIOS 1 x 128 Mbit flashUse of licensed AMI UEFI BIOSPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. - @BIOS- EasyTune- RGB Fusion- Smart Backup- System Information ViewerSupport for Q-Flash PlusSupport for Q-Flash Bundled Software Norton® Internet Security (OEM version)LAN bandwidth management software Operating System Support for Windows 11 64-bitSupport for Windows 10 64-bit Form Factor Micro ATX Form Factor; 24.4cm x 24.4cm

Read more less

Category Specification CPU AMD Socket AM4, supports Ryzen™ 5000/5000 G/4000 G/3000/3000 G-Series processors Chipset AMD B550 Memory 4 x DDR4 DIMM sockets, up to 128 GB, DDR4 2133–4733 MHz (OC), dual channel, ECC & non-ECC support, XMP support Onboard Graphics 1 x DisplayPort 1.4 (max 5120x2880@60Hz), 1 x HDMI 2.1 (max 4096x2160@60Hz), max shared memory 16 GB Audio Realtek® Audio CODEC, HD Audio, 2/4/5.1/7.1-channel, configurable via software LAN Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps) Expansion Slots 1 x PCIe x16 (CPU), 1 x PCIe x1 (Chipset) Storage Interface 2 x M.2 (M2A_CPU PCIe 4.0/3.0, M2B_SB PCIe 3.0), 4 x SATA 6Gb/s (RAID 0/1/10) USB Ports CPU: 4 x USB 3.2 Gen1 (back) Chipset: 2 x USB 3.2 Gen1 (internal), 6 x USB 2.0/1.1 (4 back, 2 internal) Internal I/O Connectors 24-pin ATX, 8-pin CPU 12V, CPU/system fan headers, 2 x M.2 sockets, 4 x SATA, front panel & audio headers, USB 3.2/2.0 headers, TPM header, Clear CMOS jumper Back Panel Connectors PS/2, DisplayPort, HDMI, 4 x USB 3.2 Gen1, 4 x USB 2.0/1.1, RJ-45, 3 x audio jacks I/O Controller iTE® I/O Controller Chip H/W Monitoring Voltage, Temperature, Fan speed, Fan fail warning, Fan speed control (depends on cooler) BIOS 128 Mbit Flash, AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SMBIOS 2.7, ACPI 5.0 Unique Features APP Center, @BIOS, EasyTune, Smart Backup, System Info Viewer, Q-Flash Bundled Software Norton® Internet Security (OEM), LAN bandwidth management software Operating System Support Windows 11 64-bit, Windows 10 64-bit Form Factor Micro ATX, 24.4 x 24.4 cm
