DDR4 offers multiple advantages over previous DRAM generations, and ADATA provides the highest quality and the fastest performance. Our Premier DDR4 3200 SO-DIMM memory modules for notebooks arrive in convenient 8GB to 32GB for instant upgrades on any compatible notebook. They deliver faster data transfers than DDR3, coupled with lower energy consumption that reduces heat and extends battery life. Our DDR4 is also optimized to unlock the power of the newest Intel/AMD processors.
Meets Demanding Standards for New-Generation Platforms
Complies with JEDEC standards
RoHS compliant
Supports Intel® Core™ 8th/9th/10th series and AMD® ZEN 2nd 3rd Ryzen™ series*
* Actual speed may vary by platform or CPU.
Specification
Module Type SO-DIMM
Form Factor Standard 1.18" height
Memory Type DDR4
Standard JEDEC
Pin Count 260-Pin
Density 16GB
Speed 3200MHz
DRAM spec/VCC DDR4 STD 1.2V
Operating temperature 0°C to 85°C
Specifications
Module Type:
SO-DIMM (for laptops)
Memory Type:
DDR4
Capacity:
16GB
Speed:
3200MHz
Voltage:
1.2V (DDR4 STD)
Pin Count:
260-pin
Form Factor:
Standard 1.18" height
Operating Temperature:
0°C to 85°C
Compatibility:
Supports Intel® Core™ 8th/9th/10th Gen and AMD® Ryzen™ 2nd/3rd Gen processors
Category
Details
CL (IDD)
22 cycles
Row Cycle Time (tRCmin)
45.75 ns (min)
Refresh to Active / Refresh Command Time (tRFCmin)
350 ns (min)
Row Active Time (tRASmin)
32 ns (min)
UL Rating
94 V-0
Operating Temperature
0°C to +85°C
Storage Temperature
-55°C to +100°C
SPECIFICATION
Module Type
VULCAN Z DDR4 Desktop Memory
Capacity
8GB (1x8GB)
Frequency
3200MHz
Latency
CL16
Data Transfer Bandwidth
25600 MB/s
Voltage
1.35V
Compatibility
Intel: Z390/Z490/Z590
AMD : B550/X570
Team P/N
TLZGD48G3200HC16F01
Dimensions
32(H) x 140(L) x 7(W) mm
The quality first principle
TEAMGROUP’s ELITE series releases an all new DDR4 SO-DIMM product. It is compliant with JEDEC international standards and the operating voltage is only 1.2v, which saves a lot of power consumption. It reduces the heat generated by the product itself and also maintains the ambient temperature around the system. It is also proven to be 100% compatible with all major laptops on the market. High quality IC are selected for their outstanding performance, stability and compatibility, making them the best choice for laptop users to expand their capacity.
SPECIFICATIONS
Module Type:
ELITE DDR4 LAPTOP MEMORY
Capacity:
16GB (1x16GB)
Frequency:
3200MHz
Latency:
CL22
Data Transfer Bandwrith:
25600MB/s
Voltage:
1.2V
Team P/N:
TED416G3200C22-S01
Dimensions:
30(H) x 67.6(L)mm
DELTA TUF Gaming Alliance RGB DDR4 DESKTOP MEMORY
Certified memory by TUF Gaming Alliance
TEAMGROUP T-FORCE once again joins forces with motherboard leader ASUS and releases the T-FORCE DELTA TUF Gaming RGB overclocking memory which is certified and strictly tested by TUF Gaming Alliance. The appearance is designed with TUF Gaming Alliance’s unique military camouflage pattern. T-FORCE DELTA TUF Gaming RGB overclocking memory is definitely your best and bravest comrade!
TUF Gaming design elements
With creativity and ingenuity, TEAMGROUP design team adds TUF Gaming’s elements on the heat spreader of the ASUS co-branded memory. With design concept of the ultra-wide-angle force flowing lighting, the T-FORCE DELTA TUF Gaming RGB overclocking memory is perfectly created, offering a never-seen-before visual experience to gamers.
Asymmetrical, minimalist design
The appearance of T-FORCE DELTA TUF Gaming RGB overclocking memory is designed using integrated geometric line to create a simple and sleek heat spreader that presents a new stereoscopic art style which is the perfect combination of arts and crafts. The embossed lines on the surface not only increase the heat dissipation area and also effectively enhance cooling of the gaming memory module, so the quality of the operation can be finely stabilized.
Selected high quality IC chips
With strict testing standard, TEAMGROUP insists on using high quality IC chips which offers excellent quality, optimal performance, stability and compatibility. It provides gamers the ultimate sensation of overclocking and an RGB overclocking memory module with high stability.
Supports ASUS Aura Sync software and motherboard lighting effect synchronization
DELTA TUF Gaming Alliance RGB memory module supports ASUS Aura Sync software[2]. These lightning-controlled software allows gamers to control lighting effects and lighting synchronization with DELTA TUF Gaming Alliance RGB luminous memory module. It creates a unique, dazzling color aesthetics and offers a brilliant RGB system!
T-FORCE
T-FORCE is TEAM force. The red “T” on the logo of “TF” represents TEAMGROUP’s passion for the storage products. The black “F” represents TEAMGROUP’s over 18 years of promotion of storage products. The visual design of the perfect combination elegantly symbolizes a pair of flying wings. They represent that the high quality and extreme performance gaming products from TEAMGROUP are capable of allowing all gamers to break the speed limit and enjoy the ever-changing world of gaming.
SPECIFICATIONS
Module Type:
DDR4 288 pin Non-ECC Unbuffered DIMM
Frequency:
3200
Latency:
CL16-20-20-40
Capacity:
16GBx2
Data Transfer Bandwidth:
25,600 MB/s (PC4 25600)
Voltage:
1.35V
Dimensions:
49(H) x 147(L) x 7(W)mm
Heat Spreader:
Aluminum heat spreader
Features
Compact Low-Profile Heatsink Design
Top Quality RAM for High Durability
Higher Performance and Reliability
Works with the Latest AMD Platforms
Supports Intel® XMP 2.0 for easy overclocking
RoHS compliant
SPECIFICATIONS
Heatsink Color:
White
Speed:
DDR4 3200 MT/s
CAS Latencies:
16-20-20
Module size:
16GB
Operating temperature:
0°C to 85°C
Storage temperature:
-20°C to 65°C
Operating voltage:
1.35V
Compatibility:
DDR4 2666 CL19-19-19 at 1.2V
Dimensions (LxWxH):
133.35 x 34 x 5.9mm
Weight:
28.41g
Description
Features
Compact Low-Profile Heatsink Design
Customizable RGB light effects
Create Personalized Lightshow with XPG Prime
PMIC for power supply stability
On-die ECC error correction
High-quality materials for stable overclocking
Supports Intel® XMP 3.0 and AMD EXPO for easy overclocking
SPECIFICATION
Memory Type
DDR5
Form Factor
U-DIMM
Color
Black / White
Capacity
32GB
Speeds
6400 MT/s
CAS Latencies
32
Operating Voltage
1.1-1.4V
Operating Temperature
0°C to 85°C
Dimensions (L x W x H)
133.35 x 40 x 7.86mm
