Anytime, anywhere access
Access, manage, and share your files and media from anywhere with Synology Drive. Available on PC, Mac, Linux, Chromebook, Android, iOS, or any device equipped with a browser.
Intelligent backup and syncing
Safeguard against ransomware attacks or accidental deletion with real-time or scheduled folder backups. Reduce local storage use with on-demand sync, only downloading files as needed.
|
CPU
|
CPU Model |
Realtek RTD1619B |
|
CPU Quantity |
1 |
|
CPU Architecture |
64-bit |
|
CPU Frequency |
4-core 1.7 GHz |
|
Hardware Encryption Engine |
|
|
Memory
|
System Memory |
1 GB DDR4 non-ECC |
|
Notes |
Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance. |
|
Storage
|
Drive Bays |
1 |
|
Compatible Drive Type* (See all supported drives)
|
- 3.5" SATA HDD
- 2.5" SATA SSD (with optional 2.5" Disk Holder)
|
|
Hot Swappable Drive* |
- |
|
Notes |
"Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay. |
|
External Ports
|
RJ-45 1GbE LAN Port |
1 |
|
USB 3.2 Gen 1 Port* |
2 |
|
Notes |
- This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
- The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
|
|
Appearance
|
Size (Height x Width x Depth) |
166 mm x 71 mm x 224 mm |
|
Weight |
0.7 kg |
|
Others
|
System Fan |
60 mm x 60 mm x 1 pcs |
|
Fan Speed Mode |
- Full-Speed Mode
- Cool Mode
- Quiet Mode
- Low-power Mode
|
|
Brightness Adjustable Front LED Indicators |
|
|
Power Recovery |
|
|
Noise Level* |
19.0 dB(A) |
|
Scheduled Power On / Off |
|
|
Wake on LAN / WAN |
|
|
Power Supply Unit / Adapter |
36 W |
|
AC Input Power Voltage |
100V to 240V AC |
|
Power Frequency |
50/60 Hz, Single Phase |
|
Power Consumption |
10.69 W (Access)
3.44 W (HDD Hibernation) |
|
British Thermal Unit |
36.50 BTU/hr (Access)
11.75 BTU/hr (HDD Hibernation) |
|
Notes |
- For more information on how power consumption is measured, refer to this article.
- Noise testing was conducted with the Synology system fully installed with Synology SATA HDDs and in an idle state. Two GRAS 40AE microphones are placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
|
|
Temperature
|
Operating Temperature |
0°C to 40°C (32°F to 104°F) |
|
Storage Temperature |
-20°C to 60°C (-5°F to 140°F) |
|
Relative Humidity |
5% to 95% RH |
|
Certification
|
- FCC
- CE
- BSMI
- VCCI
- RCM
- UKCA
- EAC
- CCC
- KC
|
|
|
|
|
Environment
|
RoHS Compliant |
|
Packaging Content
|
- Main Unit X 1
- Accessory Pack X 1
- AC Power Adapter X 1
- RJ-45 LAN Cable X 1
- Quick Installation Guide X 1
|
|
Optional Accessories
|
Plus Series 3.5" SATA HDD: HAT3300 Series
|
