Power capacity : 360 W / 650 VA
Battery Backup : 4 battery backup with surge protection outlets for multi-device power protection
Automatic Voltage Regulation (AVR)
Boost and Trim” AVR instantly corrects voltage fluctuations without using the battery, saving battery life for power outages
Circuit Breaker Reset
Push the circuit breaker button to reset for easy recovery from circuit overloads, protecting the UPS and connected electronics from electrical damage
Automatic Diagnostic Testing
Periodic battery self-test ensures early detection of a battery that needs to be replaced, ensuring your unit is ready when you need it
Generator Compatible
Provides clean instant battery power to prevent frequency variations from affecting the connected load
Specification
Details
UPS Model
BVX650I-PH
Power Capacity
360 W / 650 VA
Nominal Output Voltage
230 VAC ± 10%
Topology
Line Interactive
Transfer Time
4–6 ms typical, 10 ms max
Output Connections
(4) NEMA 5-15R Battery Backup Outlets
Nominal Input Voltage
230 VAC
Input Voltage Range
140 – 300 VAC
Frequency
50 Hz / 60 Hz ± 5 Hz
Input Circuit Breaker
5 A
Cord Length
1.2 m
AC Power Surge Protection
All Outlets
LED Indicators
LED Status display with online : on battery
Alarms
On battery : low battery : overload continuous tone alarm
Battery Type
Maintenance-free, sealed lead-acid battery, leak proof
Dimensions (H x W x D)
14.2 cm x 10.1 cm x 30 cm
Audible Noise at 1m from Unit
40 dBA max
Electrical and performance
Output Power Capacity:
1000VA / 600 Watts
Topology:
Line Interactive
Nominal Input Voltage:
230V
Nominal Output Voltage:
230V
Waveform Type:
Stepped approximation to a sine wave
Transfer Time:
6ms typical / 10ms maximum
Input Frequency:
50/60 Hz +/- 5 Hz auto-sensing
Output Frequency:
50/60 Hz +/- 1 Hz unsynchronized
Input Voltage Range:
170V – 280V
Surge Energy Rating:
156 Joules
Automatic Voltage Regulation (AVR):
Yes
Battery
Battery Type:
Maintenance-free sealed Lead-Acid
Battery Voltage:
12V
Typical Recharge Time:
8 hours
Expected Battery Life:
3–5 years
Replacement Battery:
RBC17
Physical and environmental
Outlets:
4 universal receptacles (battery backup & surge protection)
Dimensions (H x W x D):
9.25 cm x 16.05 cm x 30.5 cm
Net Weight:
5.7 kg
Color:
Black
Audible Noise:
40.0 dBA at 1 meter
Operating Temperature:
0°C to 40°C
Standard Warranty:
2-year
Power specifications
Rated Power:
1800W / 2000VA
Output Voltage:
230V (configurable for 220V and 240V)
Input Voltage:
230V (with input voltage limits of 110–285V for half load and 180–285V for full load)
Wave Type:
Pure sine wave
Efficiency:
88% at full load
Bypass:
Internal bypass (automatic and manual)
Input/Output Connections:
1x IEC C14 input and 4x IEC C13 outputs
Key features
LCD Interface:
Provides detailed status information and configuration
Intelligent Card Slot:
Allows for network management card installation
ECO Mode:
Energy-saving mode for high efficiency
Battery:
48V battery voltage, with a 4-hour recharge time to 90% capacity
Communication:
USB and RS-232 ports are included
Certification:
Complies with safety standards like EN/IEC 62040-1 and EN/IEC 62040-2
Physical specifications
Form Factor:
Tower
Dimensions:
40 cm×14.5 cm×23.8 cm40 cm cross 14.5 cm cross 23.8 cm
40 cm×14.5 cm×23.8 cm
(LWH)
Weight:
17 kg
Color:
Black (RAL 7010)
Specifications
Run time for load 2400W 4min 24s
Main Input Voltage 230 V
Other Input Voltage 220V & 240V
Main Output Voltage 230 V
Other Output Voltage 220V & 240V
rated power in W 2400 W
Rated power in VA 3000 VA
Input Connection Type IEC 60320 C14
output connection type 6 IEC 60320 C13 / 1 IEC 60320 C19
Cable length 1.50 m
Number of cables 1
Provided equipment 1 IEC 60320 C13 to Schuko power cable
1 IEC 60320 C13 to C14 power cable
1 USB cable
1 RS-232 configuration cable
user manual
Batteries & Runtime
Battery type Lead-acid battery
Battery voltage 72 V
Number of battery filled slots 0
Number of battery free slots N/A
Battery recharge time 4 h
Battery life 3…5 year(s)
Replacement battery APCRBCV205
Battery charger power 60 W rated
Physical
Colour Black (RAL 7010)
Size(LWH) 42.5 cm , 19 cm , 33.6 cm
Product weight 26.8 kg
Mounting location Front
Mounting support Floor
Mounting preference No preference
Mounting mode Not rack-mountable
USB compatible Yes
Mounting position Vertical
_____________________________________________________Warranty Information:• Item compatibility is buyer’s responsibility.• For security purposes: Kindly secure unboxing video incase wrong item and defective upon received.• Check all items upon receipt.• All items/claims for warranty are carry-in.• Tampered warranty sticker voids the warranty.• Overclocking may void the warranty.• Items for warranty must be complete with original contents/packaging and accompanied by warranty receipt.• Defective items for warranty are subject for pull out and RMA services. (Shipping fee should be shoulder by customer)
Specifications
Voltage:
220V input and output
Wattage:
500 watts
Maximum Capacity:
50VA (Volt-Amperes)
Fuse:
5A
Sockets:
3 x 220V outlets
Casing:
Compact, powder-coated metal case
Specifications:
Power Capacity:
2200VA / 1200 Watts
Topology:
Line-Interactive
Output Voltage:
230V (On Battery: 230V +/- 10% at 100% load)
Waveform:
Stepped approximation to a sinewave
Output Connections:
4 Universal outlets for battery backup
Automatic Voltage Regulation (AVR):
Corrects voltage fluctuations by increasing or decreasing output voltage without using the battery, conserving its power.
Data Line Protection:
Includes RJ45 Gigabit ports for network surge protection
Runtime:
Typical Backup Time (½ Load):
8.5 minutes
Typical Backup Time (Full Load):
1 minute
Batteries:
Type:
Maintenance-free, sealed Lead-Acid
Recharge Time:
Approximately 8 hours for a typical recharge
Management:
Features intelligent battery management, with a periodic self-test to detect failing batteries and provide early warnings for replacement.
Specifications
Power Capacity:
800VA / 450 Watts
Voltage:
230V nominal input and output
Output Connections:
4 Universal Receptacles (all battery backup)
Topology:
Line Interactive
Waveform Type:
Stepped approximation to a sinewave
Transfer Time:
6ms typical, 10ms maximum
Input Connection:
IEC-320 C14
Battery:
Maintenance-free sealed Lead-Acid
Features & Management
Automatic Voltage Regulation (AVR):
Corrects for voltage fluctuations without switching to battery power.
Universal Outlets:
Standardized connections for various plug types.
Control Panel:
LED Status display for power conditions (On Line, On Battery).
Audible Alarms:
Provides alerts for low battery, overload, and being on battery.
Cold-start capable - Provides temporary battery power when the utility power is out.
Boost Automatic Voltage Regulation (AVR) - Preserves battery life and maximizes runtime by correcting low voltages without discharging the battery.
Transformer-block spaced outlets - Protect equipment with input transformer blocks without blocking access to other receptacles.
Sleek design - Slim, modern design can be upright, flat, or wall-mounted to comfortably fit any electronics set-up and complement home décor.
PROTECTION
Battery backup and surge protection - Outlets provide abundant runtime for network gateway equipment and other critical low-power devices, allowing for hours of internet access during a power outage.
Battery and surge protected outlets - Back up and protect your hardware and data during power outages, surges and spikes.
MANAGEABILITY
LED Indicators - Provide easy-to-read status of the unit and utility power conditions.
Audible alarms - Provides notification of changing utility power and UPS power conditions
Specifications
Power Capacity:
1200VA / 650 Watts
Voltage:
230V (Nominal Input & Output)
Topology:
Line-Interactive
Output Connections:
1 x IEC 320 C13 (Battery Backup)
4 x Universal (Battery Backup)
Waveform Type:
Stepped approximation to a sinewave
Transfer Time:
6 ms typical / 10 ms maximum
Runtime:
5 minutes at 50% load
Features
Automatic Voltage Regulation (AVR):
Corrects voltage fluctuations without draining the battery.
Computer Grade Surge Protection:
Protects against damaging power surges and spikes.
Quick Mute:
Allows for silencing of audible alarms during a power event.
LED Indicators:
Provides easy visual confirmation of the UPS's functional status.
Design:
Slim and modern, can be placed upright, flat, or wall-mounted.
Additional Information
Input Connection:
IEC 60320 C14
Cord Length:
1.2 meters
Battery:
Maintenance-free sealed Lead-Acid battery
Regulatory Approvals:
CE, CB, EN/IEC 62040-1, EN/IEC 62040-2.
Common specifications
UPS Type:
Double-conversion online
Output:
Pure sine wave
Input Voltage:
230V (configurable to 220V or 240V)
Input Frequency:
40-70 Hz auto-sensing
Output Frequency:
50/60 Hz +/- 3 Hz sync to mains
Efficiency:
Up to 88% at full load; 98% in eco mode
Power Factor:
High power factor
Bypass:
Automatic internal bypass
Design:
Rack/tower convertible
Management:
LCD status and control console, intelligent card slot for optional management cards
Model-specific specifications
Model
Power Output (Watts)
Power Output (VA)
Output Connections
SRV1KI-E
900W
1000VA
3x IEC C13
SRV2KIL-E
1800W
2000VA
4x IEC C13
SRV3KIL-E
2700W
3000VA
6x IEC C13 + 1x IEC C19
