Category
Specification
Brand
Seagate
Series
IronWolf
Model
ST4000VN006
Packaging
Bare Drive
Interface
SATA 6.0 Gb/s
Capacity
4 TB
Rotational Speed
5900 RPM
Cache
64 MB
Form Factor
3.5″
Height (Max)
26.11 mm
Width (Max)
101.85 mm
Length (Max)
146.99 mm
_____________________________________________________Warranty Information:• Item compatibility is buyer’s responsibility.• For security purposes: Kindly secure unboxing video incase wrong item and defective upon received.• Check all items upon receipt.• All items/claims for warranty are carry-in.• Tampered warranty sticker voids the warranty.• Overclocking may void the warranty.• Items for warranty must be complete with original contents/packaging and accompanied by warranty receipt.• Defective items for warranty are subject for pull out and RMA services. (Shipping fee should be shoulder by customer)
Digital Storage Capacity
8 TB
Hard Disk Interface
Raid
Connectivity Technology
SATA
Brand
Seagate
Special Feature
Portable
Hard Disk Form Factor
3.5 Inches
Hard Disk Description
Mechanical Hard Disk
Compatible Devices
Desktop
Installation Type
Dashboard Mount
Versatility at the Ready
Versatile and dependable, Seagates fierce BarraCuda drives are inspired by the past but
ready for the future. BarraCuda 2.5-inch drives, in 7mm and 15mm z-heights, are a cost-effective
way to handle all your PC needs.
Multi-Tier Caching Technology
All hard drives in the BarraCuda family come equipped with Multi-Tier Caching Technology
(MTC). MTC takes your PC to new performance levels. By applying intelligent layers of NAND
Flash, DRAM and media cache technologies, BarraCuda delivers improved read and write
performance by optimizing data flow, allowing you to load apps and files faster than ever before.
Major Capacity
Store it all. With capacities 1TB, BarraCuda leads the market with the widest range of
storage options available. With a 2.5-inch form factor, users can upgrade their laptop, mobile,
external storage, or all-in-one PC systems with ease.
TECH SPECS
Feature
Details
Capacity
1TB
Form Factor
2.5 inch
z-Height
7 mm / 15 mm
Interface
SATA 6Gb/s
Performance
Multi-Tier™ Caching Technology
Key Feature
High capacity in a small size
Ideal Use
Laptop storage, mobile storage, all-in-ones, external storage
See More. Store More.
Optimised for DVRs and NVRs, SkyHawk surveillance drives are tuned for 24×7 workloads in capacities up to 10 TB. Equipped with enhanced ImagePerfect firmware, SkyHawk helps to minimise dropped frames and downtime with a workload rating 3x that of a desktop drive and IS ready to record up to 90% of the time while supporting up to 64 HD cameras.
SkyHawk Is Smart
The innovative ImagePerfect firmware enables smooth, clear video streaming for always-on, 24/7 surveillance environments helping to ensure your business can always have a formidable layer of protection.
And SkyHawk Is Vigilant
Built to record 90% of the time supports up to 64 cameras
Up to 10 TB or 2,000+1 hours of HD video
180 TB/year workload rating, 3× the workload of a desktop drive and backed by a 1-year limited warranty
NVR ready drives deliver robust drive design for multi-drive environments
Protect your data against the unexpected with an optional +Rescue Data Recovery Service plan
1. HD video stream measured as a Mpeg-4 H.264 satellite and 30fps 2MP HD security or 10 Mb/s
Use the Video Storage Selector to find the best hard drive. For more information, refer to the Surveillance
Drive Selection Guide or Surveillance System Application Guide.
Soar Higher and Longer
SkyHawk is built to scale with your needs and reliably performs in multi-drive systems. Multi-drive
surveillance systems can rely on the SkyHawks RAID-optimised hardware, keeping drives and systems
in the field longer.
NVR ready design enables reliable performance in DVR and NVR systems with 8+ drives*
Robust drive design in a RAID environment maintains drive performance by improving vibration tolerance
Stay Secure and Be Prepared
Be prepared for the unthinkable with a 1-year Seagate +Rescue Data Recovery Service plan. Under the
protective wing of SkyHawk, vandalism, viruses and accidents are no longer the end of the world.
Fast and easy recovery process data can often be restored in 15 days or less
Seagate leads the industry in data recovery with a 90% success rate
TECH SPECS
Parameter
Specification
Ideal for
DVR or NVR systems with multiple drives and HD cameras; optimized to improve reliability, reduce costs, and support video analytics
Capacity
6 TB
Cameras Supported
Up to 64
User Workload Rate
180 TB/year
Mean Time Between Failures (MTBF)
1,000,000 hours
RV sensors and RAID Support
✓
Cache Memory Installed Size
128 MB
Hard Disk Form Factor
3.5 in
Hardware Connectivity
SATA 6.0 Gb/s
Item Dimensions (L × W × H)
4.01 × 5.79 × 1.03 in
Cost-effective storage upgrade for laptop or desktop computers
Store all your games, music, movies and more with up to 4TB of storage
SATA 6Gb/s interface optimizes burst performance
Seagate Secure models for hardware-based data security
Instant Secure Erase allows safe and easy drive retirement; protect data with Self-Encrypting Drive (SED) models
Standard Model Numbers
ST2000DM008
Capacity
2TB / 2000GB
Bytes per Sector
4096 / Emulated 512e
Performance
- Interface
SATA 6Gb/s
- SATA Transfer Rates Supported (Gb/s)
6.0/3.0/1.5
- Max. Sustained Transfer Rate OD (MB/s)
190MB/s
- Cache, Multisegmented (MB)
256
- Rotational Speed (RPM)
5400
Reliability/Data Integrity
- Load/Unload Cycles
600,000
- Power-On Hours per Year (24×7)
2400
- Nonrecoverable Read Errors per Bits Read, Max
1 per 10E15
- Workload Rate Limit (TB/Year)
55
Power Management
- Startup Power (A)
2.0
- Operating Mode, Typical (W)
3.7
- Idle Average (W)
2.5W
- Standby Mode/Sleep Mode, Typical (W)
0.25/0.25
- Voltage Tolerance, Inc. Noise (5V)
±5%
- Voltage Tolerance, Inc. Noise (12V)
±10%
Environmental Temperature
- Operating (ambient, min)
0°C
- Operating (drive case, max)
60°C
- Nonoperating (ambient)
-40°C – 70°C
- Halogen Free
Yes
- RoHS Compliance
Yes
Physical
- Height (mm/in)
20.20mm/0.795in
- Width (mm/in)
101.85mm/4.010in
- Depth (mm/in)
146.99mm/5.787in
- Weight (g/lb)
490g/1.08lb
_____________________________________________________
Warranty Information:
• Item compatibility is buyer’s responsibility.
• For security purposes: Kindly secure unboxing video incase wrong item and defective upon received.
• Check all items upon receipt.
• All items/claims for warranty are carry-in.
• Tampered warranty sticker voids the warranty.
• Overclocking may void the warranty.
• Items for warranty must be complete with original contents/packaging and accompanied by warranty receipt.
• Defective items for warranty are subject for pull out and RMA services. (Shipping fee should be shoulder by customer)
Home Security Systems: Store video footage from home surveillance cameras.
Small Business Surveillance: Monitor business premises with multiple cameras.
Retail Surveillance: Record customer interactions and prevent theft.
Public Safety: Support surveillance initiatives in public areas.
Specification
Details
Capacity
2TB
Interface
SATA III (6 Gb/s)
Spindle Speed
5400 RPM
Cache
256 MB
Form Factor
3.5-inch
Dimensions (L × W × H)
147 × 100 × 26.5 mm
Weight
620 g
Operating Temperature
5°C to 60°C
Non-Operating Temperature
-40°C to 70°C
Acoustic Noise
22 dBA
Rotational Vibration Tolerance
3.5 mm peak-to-peak
Shock Tolerance
200G (5 ms duration)
Seagate IronWolf NAS Hard Drive Specifications
Category
Details
Product Name
Seagate IronWolf
Model
ST2000VN003
Capacity
2 TB (2000 GB)
HDD Size / Form Factor
3.5-inch
Interface
SATA 6 Gb/s
Cache
256 MB
Rotational Speed
5400 RPM
Designed For
Connected Home, SOHO, Small-to-Medium Business NAS
Usage Environment
Consumer and commercial NAS systems
Operating Mode
24×7 performance in multi-bay, networked environments
Key Technology
AgileArray™
AgileArray™ Features
Dual-Plane BalancingTime-Limited Error Recovery (TLER)
Performance Benefit
Optimized RAID performance and reliability in multi-bay NAS systems
Brand Promise
Tough. Ready. Scalable.
Key specifications
Capacity:
500GB
Interface:
SATA 6Gb/s (backward compatible with SATA 3Gb/s)
Form Factor:
2.5-inch, 7mm height
Spindle Speed:
7200 RPM
Cache:
32MB
Average Seek Time:
11ms
Dimensions:
100.55mm (length) x 69.85mm (width) x 7mm (height)
Weight:
Approximately 95g
Power Draw:
1.8W (Active) / 0.65W (Idle)
Operating Shock:
400 G / 2.0 ms
Multi-Tier Caching Technology
Optimized read and write data flow.
All hard drives in the BarraCuda family come equipped with Multi-Tier Caching Technology (MTC). By optimizing data flow with intelligent layers of NAND Flash, DRAM, and media cache technologies—get faster load and applications times and improved read and write performance.
Your Data Matters to Us
Trusted dependability.
For more than 20 years, Seagate has manufactured and delivered the reliable BarraCuda family of drives. Your positive hard drive experience matters to us, which is why we offer robust limited warranties on all BarraCuda drives.
Add new drives with ease.
DiscWizard software makes it easy to add new drives to your computer—guiding you through steps to easily clone your current drive to your new Seagate drive, create and format partitions, transfer data, back up data for increased security, and more.
HIGH-CAPACITY DRIVES
Massive capacity in a desktop hard drive.
The Seagate BarraCuda Hard Drive delivers massive storage for desktops, offering up to 24TB of capacity. Perfect for storing large files, games, and media libraries, it’s built to handle your growing digital needs. With reliable performance and trusted durability, it’s the ultimate desktop storage solution.
Digital Storage Capacity
6 TB
Hard Disk Interface
Unknown
Connectivity Technology
SATA
Brand
Seagate
Special Feature
Portable
Hard Disk Form Factor
3.5 Inches
Hard Disk Description
Mechanical Hard Disk
Compatible Devices
Laptop, Desktop
Installation Type
Internal Hard Drive
Hard Disk Size
6 TB
Digital Storage Capacity
8 TB
Hard Disk Interface
Serial ATA
Connectivity Technology
SATA
Brand
Seagate
Special Feature
Data Recovery Service
Hard Disk Form Factor
3.5 Inches
Hard Disk Description
Mechanical Hard Disk
Compatible Devices
Gaming Console, Desktop
Installation Type
Internal Hard Drive
Hard Disk Size
8 TB
Tough. Ready. Scalable.
For everything NAS, theres IronWolf and IronWolf Pro. Always on and always working,
IronWolf is enhanced with AgileArray technology for optimal reliability and system agility.
Multi-user technology and extreme workload rates allow IronWolf to perform and scale up with your enterprise.
IronWolf + the Power of AgileArray
NAS-optimized hard drive for the best-possible user experience
IronWolf Health Management in Synology NAS1 continuously helps to safeguard the health of your data
Drive balance with Rotational Vibration (RV) sensors manage multi-bay vibration for long-term consistent performance and reliability
RAID performance optimized that maximizes responsiveness and uptime with NAS-aware Error Recovery Control
Advanced power management saves energy and delivers the right power at the right time
1. IronWolf Health Management Beta is only available in capacities of 4TB and up.
Actively Protect Your Data with IronWolf Health Management in Synology DiskStations
IronWolf Health Management is designed to operate on enabled Synology DiskStation NAS,
populated with supported IronWolf or IronWolf Pro HDDs.1 It improves the overall system
reliability by displaying actionable prevention, intervention or recovery options for the user.
Prevention. IHM monitors the user environment and recommends preventative actions
to enable superior NAS experience.
Intervention. Analyzes hundreds of parameters and recommends backup ahead of any
potential catastrophic data loss events.
Recovery. Access to Seagate® Data Recovery Services (included with IronWolf Pro for two years),
helps to ensure a secure environment for data recovery in the event of failure.
1. IronWolf Health Management features subject to change.
2. Synology DiskStation may vary in compatibility with IronWolf Health Management. Contact your Seagate sales representative for further details.
Multi-Bay and NAS-Ready With Built-In RV Sensor
First in its class, IronWolf drives are equipped with RV sensors on high capacity drives to
maintain performance in multi-bay NAS enclosures. RV sensors on IronWolf Pro come
standard, helping business and creative pros to have consistent performance for years to come.
Do More With Multi-User Optimization
Do more with your NAS with multi-user optimization. Enabling user workloads of up to
180 TB/year on IronWolf and 300TB/year with IronWolf Pro, multiple users can confidently
upload and download data to a NAS server. Whether youre a creative pro or a small business,
IronWolf is on your side.
IronWolf Pro Comes With 2-year Rescue Data Recovery Service1
Your data is important and a Rescue plan provides peace of mind in case of unexpected data loss
due to accidents or mechanical damage. The Rescue plan gives you access to a global team of
world-class data recovery experts with 95% customer satisfaction rating.
Purchase and register an IronWolf Pro drive to activate your free Rescue plan and y
