The Palit GeForce RTX™ 5060 Dual offers classic cooling efficiency in a sleek, modern black design. Twin 95mm fans provide competitive cooling and quiet operation, while a compact 2-slot design suits small form factor builds. A sturdy backplate adds structural integrity. Enjoy subtle RGB lighting for a refined aesthetic and customize your shroud with Palit Maker support without voiding your warranty. Powered by NVIDIA Blackwell, GeForce RTX™ 50 Series GPUs bring game-changing AI capabilities to gamers and creators.
The Palit RTX 5060 Dual is a compact and efficient graphics card built on NVIDIA’s Blackwell architecture, designed for gamers and creators seeking reliable 1080p and 1440p performance. With 8GB of ultra-fast GDDR7 memory, it offers next-gen features like ray tracing, DLSS 4, and AI-enhanced rendering in a sleek dual-fan design.
Specifications:
| Memory Amount |
8 GB |
| Memory Interface |
128 bits |
| DRAM Type |
GDDR7 |
| Graphics Clock |
2280 MHz |
| Boost Clock |
2497 MHz |
| Memory Clock |
28 Gbps |
| CUDA Cores |
3840 |
| Memory Bandwidth (GB/sec) |
448 |
| Microsoft DirectX |
Microsoft DirectX® 12 Ultimate |
| OpenGL |
4.6 |
| Bus Support |
PCI-E 5.0 |
| HDMI |
HDMI 2.1b |
| DisplayPort |
DP2.1b x 3 |
| Maximum Digital Resolution |
4K at 480Hz or 8K at 120Hz with DSC |
| Height |
2 Slot |
| Board Size |
262.1 x 126.3 x 40.1 mm |
| Graphics Card Power |
145 W |
| Recommended System Power |
550 W |
| Supplementary Power Connectors |
8-pin x 1 |
| Composite Heat Pipe |
Yes |
| Copper Base |
Yes |
| DrMOS |
Yes |
| 0-dB TECH |
Yes |
| NVIDIA Architecture |
Blackwell |
| Ray Tracing Cores |
4th Generation |
| Tensor Cores |
5th Generation |
| NVIDIA DLSS 4 |
Yes |
| NVIDIA Reflex 2 |
Yes |
| NVIDIA Broadcast |
Yes |
| Resizable BAR |
Yes |
| NVIDIA App |
Yes |
| NVIDIA Ansel |
Yes |
| NVIDIA FreeStyle |
Yes |
| NVIDIA ShadowPlay |
Yes |
| NVIDIA® Highlights |
Yes |
| NVIDIA G-SYNC |
Yes |
| Game Ready Drivers |
Yes |
| NVIDIA Studio Drivers |
Yes |
| NVIDIA Omniverse |
Yes |
| RTX Remix |
Yes |
| NVIDIA GPU Boost |
Yes |
| Vulkan 1.4, OpenGL 4.6 |
Yes |
| NVIDIA Encoder (NVENC) |
1x 9th Generation |
| NVIDIA Decoder (NVDEC) |
1 x 6th Generation |
| AV1 Encode |
Yes |
| AV1 Decode |
Yes |
| CUDA Capability |
12.8 |
| VR Ready |
Yes |
| Multi Monitor |
4 |
Cooling & Design:
- Dual 95mm fans
- Composite heat pipes with copper base
-
0-dB TECH for silent operation under low loads
- RGB lighting
-
Dimensions: 262.1 × 126.3 × 40.1 mm
-
Slot Width: Dual-slot
-
Backplate: Included for structural integrity
Display Outputs:
- 1 × HDMI 2.1b
- 3 × DisplayPort 2.1b
-
Max Resolution: 4K @ 480Hz or 8K @ 120Hz with DSC
Advanced Features:
-
Ray Tracing Cores: 4th Gen
-
Tensor Cores: 5th Gen
-
DLSS 4: AI-powered rendering and frame generation
- DirectX 12 Ultimate, Vulkan 1.4, OpenGL 4.6
-
NVENC/NVDEC: 9th/6th Gen
- AV1 Encode/Decode
- NVIDIA Reflex 2, Broadcast, Studio Drivers, RTX Remix, Omniverse, G-SYNC, and more
Ideal For:
- Smooth 1080p and 1440p gaming
- AI-enhanced creative workflows
- Compact builds with efficient cooling
