GV-N3050WF2OCV2-8GD

SPECIFICATIONS:

The Palit GeForce RTX™ 5060 Dual offers classic cooling efficiency in a sleek, modern black design. Twin 95mm fans provide competitive cooling and quiet operation, while a compact 2-slot design suits small form factor builds. A sturdy backplate adds structural integrity. Enjoy subtle RGB lighting for a refined aesthetic and customize your shroud with Palit Maker support without voiding your warranty. Powered by NVIDIA Blackwell, GeForce RTX™ 50 Series GPUs bring game-changing AI capabilities to gamers and creators.

The Palit RTX 5060 Dual is a compact and efficient graphics card built on NVIDIA’s Blackwell architecture, designed for gamers and creators seeking reliable 1080p and 1440p performance. With 8GB of ultra-fast GDDR7 memory, it offers next-gen features like ray tracing, DLSS 4, and AI-enhanced rendering in a sleek dual-fan design.

Specifications:

Cooling & Design:

• Dual 95mm fans
• Composite heat pipes with copper base
• 0-dB TECH for silent operation under low loads
• RGB lighting
• Dimensions: 262.1 × 126.3 × 40.1 mm
• Slot Width: Dual-slot
• Backplate: Included for structural integrity

Display Outputs:

• 1 × HDMI 2.1b
• 3 × DisplayPort 2.1b
• Max Resolution: 4K @ 480Hz or 8K @ 120Hz with DSC

Advanced Features:

• Ray Tracing Cores: 4th Gen
• Tensor Cores: 5th Gen
• DLSS 4: AI-powered rendering and frame generation
• DirectX 12 Ultimate, Vulkan 1.4, OpenGL 4.6
• NVENC/NVDEC: 9th/6th Gen
• AV1 Encode/Decode
• NVIDIA Reflex 2, Broadcast, Studio Drivers, RTX Remix, Omniverse, G-SYNC, and more

Ideal For:

• Smooth 1080p and 1440p gaming
• AI-enhanced creative workflows
• Compact builds with efficient cooling

GV-N3050WF2OCV2-6GD

Specification:

The ASUS Dual RTX 5060 OC Edition is a compact and powerful graphics card built on NVIDIA’s Blackwell architecture, designed for gamers and creators who want high performance in a space-efficient form factor. With 8GB of GDDR7 memory, advanced cooling, and factory overclocking, it’s ideal for smooth 1080p and 1440p gaming.

Specifications:

GeForce RTX™ 5060 8G VENTUS 2X OC

Specifications:

The GIGABYTE GeForce RTX 5060 Ti WINDFORCE OC SFF 8G (GV-N506TWF2OC-8GD) is a compact, factory-overclocked graphics card designed for small form factor builds that still demand serious performance.

• GPU Architecture: NVIDIA Blackwell (GB206), 5nm process
• CUDA Cores: 4608, with 5th-gen Tensor Cores and 4th-gen Ray Tracing Cores
• Clock Speeds: Base 2407 MHz, Boost up to 2587 MHz (OC mode)
• Memory: 8GB GDDR7 on a 128-bit interface, 28 Gbps effective speed, 448 GB/s bandwidth
• Cooling: WINDFORCE dual-fan system with Hawk fans, copper heat pipes, screen cooling, and server-grade thermal gel
• Design: Dual-slot, 208mm length—ideal for SFF cases; reinforced backplate for durability
• Power: 180W TDP, single 8-pin connector, 450W PSU recommended
• Outputs: 1x HDMI 2.1b, 3x DisplayPort 2.1b
• Features: DLSS 4, NVIDIA Reflex 2, ACE, Studio support, and 9th-gen NVENC for creators

It’s a sleek, efficient card that balances size, thermals, and next-gen performance—perfect for gamers and creators working with limited space but unlimited ambition.

Experience exceptional gaming performance with the Gigabyte GV-R9070XTAORUS-E-16GD, featuring 16GB of GDDR6 memory and a premium design that elevates your gaming setup.

Key Features:

• 16GB GDDR6 Memory: Provides ample capacity for high-resolution gaming and multitasking across demanding applications.
• AORUS Elite Design: Combines sleek aesthetics with RGB lighting, enhancing the visual appeal of your gaming rig.
• Advanced Cooling Technology: Equipped with a sophisticated cooling system to maintain optimal performance during intense gaming sessions.
• Factory Overclocked: Optimized clock speeds for superior graphics performance and smoother gameplay.
• Ray Tracing Support: Delivers stunning visuals with real-time ray tracing, bringing your games to life with realistic lighting and reflections.

How to Use:

1. Installation: Open your PC case and locate the PCIe slot. Remove any existing GPU and securely install the Gigabyte GV-R9070XTAORUS-E.
2. Power Connection: Connect the necessary PCIe power cables from your power supply to the graphics card.
3. Driver Installation: Download and install the latest drivers from the Gigabyte website for optimal performance.
4. Configuration: Use gaming or performance software to adjust settings according to your preferences for the best experience.

Single-Fan Option for Mini-ITX Power Station

Designed specifically for small PC users, the Palit GeForce RTX™ 3050 StormX boasts a compact yet powerful single-fan design. With a board size of 170mm in length, the StormX graphics cards are Mini-ITX supported, making them perfect for space-conscious gamers and creators.

Silent Performance When It Matters

The fans remain off during lighter tasks, delivering a silent operation. They activate only when needed.

Activation Conditions: GPU reaches ~60°C, or TGP exceeds ~150W
Deactivation Conditions: GPU drops below ~50°C, memory below ~80°C, and TGP below ~60W

Honeycomb Bracket

The design of honeycomb bracket increases airflow by up to 15%, allowing the heat generated from GPU to be exhausted via the honeycomb design bracket. This enables more efficient cooling effects.
