IMPROVE YOUR PRODUCTIVITY WITH OUR ALL-PURPOSE WORKFORCE SCANNERS
Focus on work that matters with the high-speed and all-purpose Epson WorkForce DS-530II scanner. Designed to handle a wide variety of media, you will be able to scan media printed on different mediums from fragile paper documents to plastic cards, and even thick books with its flatbed option.
Scanning speed of up to 35 ppm / 70 ipm
Automatic Document Feeder (ADF) of up to 50 sheets
Daily duty cycle of up to 5,500 sheets
One-pass duplex scanning
Paper protection function and image sensor glass dirt detection
Power:
Rated Voltage:AC 100 - 240 VRated Frequency:50 - 60 HzPower Consumption:Operating: 11WReady Mode: 5.4WSleep Mode: 1.0WPower Off: 0.1W
Supported OS and Applications:
Supported OS:Windows XP / Vista / 7 / 8 / 8.1 / 10 / Server 2003 / Server 2008 / Server 2012 / Server 2016Mac OS X 10.6.8 or laterScanner Driver Compatibility:TWAIN, SANE, WIA, ICA, ISISBundled Applications:Epson Scan 2, ISIS Driver (Web Download), Epson Scan OCR Component, Epson Scan PDF Extensions, Document Capture Pro (Win), Document Capture (Mac)
Scanning:
Scanner Type:A4 sheet-fed, one-pass duplex colour scannerSensor Type:Colour Contact Image SensorScanning Method:Fixed carriage and moving documentLight Source:RGB LEDOptical Resolution:600 x 600 dpiOutput Resolution:50 - 1,200 dpi (1 dpi increments)Bit Depth:Each colour (RGB): 10 bit input / 8 bit outputMin Document Size:50.8 x 50.8 mmMax Document Size:215.9 x 6096 mmSupported Paper Weight:27 - 413 g/m2 (A8 or less 127 - 413 g/m2)Output File Formats:Epson Scan 2: JPEG, TIFF, Multi-TIFF, PDF, Searchable PDF, BMP, PNGDocument Capture Pro (Win): JPEG, BMP, PDF, Searchable PDF, TIFF, Multi-TIFF, PNG, DOCX, XLSX, PPTXADF Capacity:50 sheets (80g/m2)Daily Scan Volume:Up to 5,500 sheets / dayMulti-feed Detection:Ultrasonic Sensor and Length Detection
Scan Speed:
Resolution (Colour/Greyscale/Mono):200 dpi: 35 ppm / 70 ipm*2300 dpi: 35 ppm / 70 ipm*2600 dpi: 12 ppm / 24 ipm*2
Dimensions and Weight:
Dimensions (W x D x H):296 x 169 x 176 mm
Weight:3.7 kg
Options:
Options:Flatbed Dock - B12B819011Roller Assembly Kit: 200,000 scans - B12B819671Carrier Sheet - B12B819051Cleaning Kit - B12B819291
Environmental Conditions:
Temperature:Operating:5 - 35°CStorage: -25 - 60°CHumidity:Operating: 15 - 80% (No condensation)Storage: 15 - 85% (No condensation)
Key specifications
Specification
Detail
Scanning Speed
30 ppm / 60 ipm (2-sided) at 300 dpi
ADF Capacity
20 sheets
Wireless Connectivity
Yes
Duplex Scanning
Yes
Optical Resolution
Up to 600 x 600 dpi
Interpolated Resolution
Up to 1200 x 1200 dpi
Color Depth
48-bit input, 24-bit output
Paper/Card Handling
20-sheet ADF, includes a dedicated slot for plastic cards
Mobile Connectivity
Yes, with the Brother Mobile Connect app
Scan Destinations
PC, USB memory stick, cloud services (via software)
Dimensions
288 mm (W) x 101 mm (D) x 85 mm (H)
Weight
1.37 kg
Scanning:
Scanner Type: A4 sheet-fed, one-pass duplex colour scanner
Sensor Type:Contact Image Sensor (CIS)
Scanning Method:Fixed carriage & moving document
Light Source:RGB LED
Optical Resolution:600 x 600 dpi
Output Resolution: 50 - 1,200 dpi (in 1 dpi increments)
Bit Depth: Each colour (RGB): 10 bit input / 8 bit output
Min Document Size: 50.8 x 50.8 mm
Max Document Size: 215.9 x 6,096 mm
Supported Paper Weight: 27 - 413 g/m2 (A8 or less 127 - 413 g/m2)
ADF Capacity: 100 sheets (80g/m2)
Daily Scan Volume: Up to 10,000 sheets / day
Multi-feed Detection:Ultrasonic Sensor and Length Detection]
Interface:USB 3.0
General specifications
Scanner Type:
Automatic Document Feeder (ADF)
ADF Capacity:
Up to 80 sheets (80 g/m²)
Scanning Speed:
Up to 40 ppm
2-Sided (Duplex) Scan:
Yes, up to 80 images per minute
Product Dimensions:
299.5 mm (W) x 190.5 mm (D) x 215.9 mm (H)
Weight:
2.64 kg (5.82 lbs)
Memory:
512MB
Scanning features
Optical Resolution:
Up to 600 x 600 dpi
Interpolated Resolution:
Up to 1,200 x 1,200 dpi
Color Depth (Input):
48-bit color processing
Color Depth (Output):
24-bit color processing
Scan Modes:
Color, Grayscale, Monochrome
Supported File Formats:
Searchable PDF, Secure PDF, Signed PDF, PDF/A, High Compression PDF, TIFF, Multi-page TIFF, JPEG, BMP, TEXT, Word, Excel, PowerPoint
Document and media handling
Multiple Papers - Width:
50.8 mm to 215.9 mm
Multiple Papers - Length:
50.8 mm to 355.6 mm
Single Paper - Width:
50.8 mm to 215.9 mm
Connectivity and compatibility
Interface:
Ethernet (10BASE-T, 100BASE-TX) and SuperSpeed USB 3.0
Operating Systems:
Windows:
Windows 7 SP1, 8.1, 10, and Server versions
macOS:
macOS v10.14.x and later
Cloud Services:
Google Drive, OneDrive, Dropbox
Mobile Connectivity:
Brother Mobile Connect App and AirPrint
Drivers:
TWAIN, WIA, ISIS, SANE
EMPOWERING BUSINESSES WITH EXCEPTIONAL PERFORMANCE
The WorkForce DS-730N simplifies and enhances business workflow with high scan speed performance and easy access to scan settings through the 1.44” LCD display. Users can scan to Network folder, email or send scan data to target destination without the use of a PC. In addition, the image sensor glass dirt detection reduces re-scanning due to bad image quality, improving workflow.
Scanning speeds of up to 40 ppm / 80 ipm
Automatic Document Feeder (ADF) of up to 100 sheets
Daily duty cycle of of up to 6,500 sheets
One-pass duplex scanning
Built in Ethernet
Paper protection function and image sensor glass dirt detection
Simplify data sharing with Epson ScanWay
Scanning:
Scanner Type:Sheet-fed, one pass duplex colour scannerSensor Type:Colour Contact Image Sensor (CIS)Scanning Method:Scanning Head Fixed (Document moving) Type scanningLight Source:RGB LEDOptical Resolution:600 x 600 dpi*1Output Resolution:50 - 1,200 dpi (in 1 dpi increments)Scanner Bit Depth (Colour):30-bit input, 24-bit outputScanner Bit Depth (Grayscale):10-bit input, 8-bit outputScanner Bit Depth (Black & White):10-bit input, 1-bit outputMin Document Size:50.8 x 50.8 mmMax Document Size:215.9 x 6096 mmSupported Paper Weight:27 - 413 g/m2Output File Formats:Document Capture Pro (Win): JPEG, BMP, PDF, Searchable PDF, TIFF, Multi-TIFF, PNG, DOCX, XLSX, PPTXScan to Destination:Folder, Email, FTP/SFTP, SharePoint
Scan Speed:
Resolution (Colour / Monochrome):300 dpi: 40 ppm / 80 ipm600 dpi: 12 ppm / 24 ipm
ADF Specifications:
ADF Capacity:100 sheets (80 g/m2)Daily Duty Cycle:Up to 6,500 sheets / day
Connectivity:
Interface:USB2.0 and Ethernet (1000BASE-T/100BASE-TX/10BASE-T)
Supported OS and Applications:
Supported OS:Windows XP SP3 / Vista / 7 / 8 / 8.1 / 10 / Server 2003 / Server 2008 / Server 2012 / Server 2016 / Server 2019Mac OS X 10.6.8 or laterScanner Driver Compatibility:TWAIN, SANE, WIA, ICA, ISISBundled Applications:Epson Scan 2, Epson Scan OCR Component, Epson Scan PDF Extensions, Document Captur e Pro (Windows / Mac), Document Capture Pro ServerFile Format:Standalone: JPEG, PDF, TIFFEpson Scan 2: JPEG, TIFF , Multi-TIFF, PDF, Searchable PDF, BMP, PNGDocument Captur e Pro (Win): JPEG, JPEG2000, BMP, PDF, TIFF
Dimensions and Weight:
Dimensions (W x D x H):296 x 169 x 167 mm
Weight:3.6 kg
Options:
Options:Carrier Sheet - B12B819051Cleaning Kit - B12B819291Roller Assembly Kit: 200,000 scans - B12B819671
Environmental Conditions:
Temperature:Operating: 5 - 35°CStorage: -25 - 60°CHumidity:Operating: 15 – 80% (No condensation)Storage: 15 – 85% (No condensation)
Power:
Rated Voltage:AC 100 - 240 VRated Frequency:50 - 60 HzPower Consumption:Operating: 13W (USB) / 14W (Ethernet)Ready Mode: 5.9WSleep Mode: 1.2W (USB) / 1.5W (Ethernet)Power Off: 0.1W
Control Panel:
LCD Screen:1.44” LCD
