| CPU |
AMD Socket AM4, supports Ryzen™ 5000/5000 G/4000 G/3000/3000 G-Series processors |
| Chipset |
AMD B550 |
| Memory |
4 x DDR4 DIMM sockets, up to 128 GB, DDR4 2133–4733 MHz (OC), dual channel, ECC & non-ECC support, XMP support |
| Onboard Graphics |
1 x DisplayPort 1.4 (max 5120x2880@60Hz), 1 x HDMI 2.1 (max 4096x2160@60Hz), max shared memory 16 GB |
| Audio |
Realtek® Audio CODEC, HD Audio, 2/4/5.1/7.1-channel, configurable via software |
| LAN |
Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps) |
| Expansion Slots |
1 x PCIe x16 (CPU), 1 x PCIe x1 (Chipset) |
| Storage Interface |
2 x M.2 (M2A_CPU PCIe 4.0/3.0, M2B_SB PCIe 3.0), 4 x SATA 6Gb/s (RAID 0/1/10) |
| USB Ports |
CPU: 4 x USB 3.2 Gen1 (back)
Chipset: 2 x USB 3.2 Gen1 (internal), 6 x USB 2.0/1.1 (4 back, 2 internal) |
| Internal I/O Connectors |
24-pin ATX, 8-pin CPU 12V, CPU/system fan headers, 2 x M.2 sockets, 4 x SATA, front panel & audio headers, USB 3.2/2.0 headers, TPM header, Clear CMOS jumper |
| Back Panel Connectors |
PS/2, DisplayPort, HDMI, 4 x USB 3.2 Gen1, 4 x USB 2.0/1.1, RJ-45, 3 x audio jacks |
| I/O Controller |
iTE® I/O Controller Chip |
| H/W Monitoring |
Voltage, Temperature, Fan speed, Fan fail warning, Fan speed control (depends on cooler) |
| BIOS |
128 Mbit Flash, AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SMBIOS 2.7, ACPI 5.0 |
| Unique Features |
APP Center, @BIOS, EasyTune, Smart Backup, System Info Viewer, Q-Flash |
| Bundled Software |
Norton® Internet Security (OEM), LAN bandwidth management software |
| Operating System Support |
Windows 11 64-bit, Windows 10 64-bit |
| Form Factor |
Micro ATX, 24.4 x 24.4 cm |
