Specifications
Graphics Processing:
GeForce RTX™ 5070 Ti
Core Clock:
2542 MHz (Reference: 2452 MHz)
CUDA® Cores:
8960
Memory Clock:
28 Gbps
Memory Size:
16GB
Memory Type:
GDDR7
Memory Bus:
256 bit
Card Bus:
PCI-E 5.0
Digital Max Resolution:
7680 x 4320
Card Size:
L=304 W=126 H=50 mm
PCB Form:
ATX
Recommended PSU:
750W
Power Connectors:
1x 12V-2x6
Output:
3x DisplayPort 2.1b, 1x HDMI 2.1b
Key Features:
16GB GDDR7 Memory: Provides ample memory for high-resolution gaming and demanding applications.
Factory Overclocked: Optimized for maximum performance, delivering smooth gameplay and faster rendering.
Eagle Cooling Design: Advanced cooling technology ensures optimal thermal performance and quieter operation.
Compact Form Factor: Specifically designed to fit in smaller builds without sacrificing power or performance.
Ray Tracing Support: Enjoy stunning visuals with real-time ray tracing capabilities for immersive gaming experiences.
How to Use:
Installation: Open your case and locate the PCIe slot. Remove any existing GPU and insert the Gigabyte GV-N507TEAGLE securely.
Power Connection: Attach the required PCIe power connectors from your power supply to the graphics card.
Driver Installation: Download the latest drivers from the Gigabyte website for optimal performance.
Configuration: Use your favorite software to adjust settings for gaming or productivity tasks as needed.
Specifications
Graphics Processing:
NVIDIA GeForce RTX™ 5080
Core Clock:
2730 MHz (Reference: 2617 MHz)
CUDA® Cores:
10752
Memory Clock:
30 Gbps
Memory Size:
16GB
Memory Type:
GDDR7
Memory Bus:
256-bit
Card Bus:
PCI Express 5.0
Digital Max Resolution:
7680 x 4320
Key Features:
16GB GDDR7 Memory: Provides fast and efficient performance for demanding applications and games.
Factory Overclocked: Enhanced clock speeds for superior graphics performance.
Compact Design: Specifically designed for small form factor (SFF) systems without compromising power.
Advanced Cooling: Unique cooling solutions ensure optimal temperature management for long-lasting performance.
Ray Tracing Technology: Delivers stunning visuals with realistic lighting and reflections.
How to Use:
Installation: Open your PC case and remove the existing GPU. Insert the Gigabyte GV-N5080AERO-OC into the PCIe slot.
Connect Power: Use the appropriate PCIe power connectors from your power supply to power the GPU.
Driver Installation: Download the latest drivers from the Gigabyte website for optimal performance and features.
Configuration: Adjust settings through your preferred software for gaming, streaming, or creative tasks.
Specifications
GPU:
GeForce RTX™ 5080
Core Clock:
2670 MHz (Reference: 2617 MHz)
CUDA Cores:
10752
Memory Size:
16GB
Memory Type:
GDDR7
Memory Clock:
30 Gbps
Memory Bus:
256-bit
PCIe Interface:
PCI-E 5.0
Max Resolution:
7680 x 4320
Output Ports:
3x DisplayPort 2.1b, 1x HDMI 2.1b
Power Connectors:
1x 16-pin
Recommended PSU:
850W
Key Features:
16GB GDDR7 Memory: Ensures top-tier performance for modern gaming and creative applications.
Factory Overclocked: Optimized clock speeds for enhanced graphics rendering and smoother gameplay.
WINDFORCE Cooling System: Advanced cooling solution for effective thermal management, keeping your GPU cool under pressure.
Compact Design: Ideal for small form factor builds without sacrificing performance.
Ray Tracing and AI Features: Experience cutting-edge graphics with real-time ray tracing and DLSS support.
How to Use:
Installation: Open your PC case and locate the PCIe slot. Remove any existing GPU and insert the Gigabyte GV-N5080WF3OC securely.
Power Connection: Connect the necessary PCIe power cables from your power supply to the GPU.
Driver Setup: Download and install the latest drivers from the Gigabyte website for optimal functionality.
Configuration: Use gaming or graphics software to adjust settings according to your needs for the best performance.
AMD A520 Ultra Durable Motherboard with GbE LAN with Bandwidth Management, PCIe 3.0 x4 M.2, Smart Fan 5, Anti-Sulfur Resistors Design
Brand
Gigabyte
Memory Type
DDR4
Form Factor
mATX
Socket
AM4
CPU
AMD Socket AM4, support for: AMD Ryzen™ 5000 G-Series Processors/ AMD Ryzen™ 5000 Series Processors/ AMD Ryzen™ 4000 G-Series Processors/ AMD Ryzen™ 3000 and Ryzen™ 3000 G-Series Processors
Chipset
AMD A520
Memory
2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
Onboard Graphics
Integrated Graphics Processor:1 x D-Sub port, supporting a maximum resolution of 1920×1200@60 Hz1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz* Support for HDMI 2.1 version, HDCP 2.3, and HDR.
Audio
Realtek® Audio CODECHigh Definition Audio2/4/5.1/7.1-channel
LAN
Realtek® GbE LAN chip (1 Gbps/100 Mbps)
Expansion Slots
CPU:1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16Chipset:1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
Storage Interface
CPU:1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 3.0 x4/x2 SSD support)Chipset:4 x SATA 6Gb/s connectors
USB
CPU:4 x USB 3.2 Gen 1 ports on the back panelChipset:2 x USB 3.2 Gen 1 ports available through the internal USB header6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
Internal I/O Connectors
1 x 24-pin ATX main power connector1 x 8-pin ATX 12V power connector1 x CPU fan header1 x system fan header1 x M.2 Socket 3 connector4 x SATA 6Gb/s connectors1 x front panel header1 x front panel audio header1 x USB 3.2 Gen 1 header2 x USB 2.0/1.1 headers1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only)1 x speaker header1 x Clear CMOS jumper1 x chassis intrusion header
Back Panel Connectors
1 x PS/2 keyboard/mouse port1 x D-Sub port1 x HDMI port4 x USB 3.2 Gen 1 ports2 x USB 2.0/1.1 ports1 x RJ-45 port3 x audio jacks
Form Factor
Micro ATX Form Factor; 23.3cm x 19.8cm
AMD A520 Ultra Durable Motherboard with Digital VRM Solution, GbE LAN, Smart Fan 5 with FAN STOP
Supports AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series and Ryzen™ 3000 and Ryzen™ 3000 G-Series Processors
Dual Channel ECC/ Non-ECC Unbuffered DDR4, 4 DIMMs
Ultra Durable™ PCIe 3.0 x16 Slot
NVMe PCIe 3.0 M.2 Connectors
High Quality Audio Capacitors and Audio Noise Guard for Ultimate Audio Quality
GbE LAN with Bandwidth Management
Rear DisplayPort and HDMI for Multi-display Support
Smart Fan 5 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
Anti-Sulfur Resistors Design
PERFORMANCE
GIGABYTE UD series motherboards use pure digital PWM + Low RDS (on) MOSFETs design to support the 3rd Gen AMD Ryzen™ CPUs by offering incredible precision in delivering power to the motherboard's most power-hungry and energy-sensitive components as well as delivering enhanced system performance and ultimate hardware scalability.
CONNECTIVITY
NVMe PCIe Gen3 x4 M.2 Connector GIGABYTE Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their system’s potential.
GbE LAN with Bandwidth Management
GbE LAN features a network bandwidth management application which helps to improve network latency and maintain low ping times to deliver better responsiveness in crowded LAN environments.
SPECIFICATIONS
CPU
AMD Socket AM4, support for: AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series and Ryzen™ 3000 and Ryzen™ 3000 G-Series Processors
(Please refer "CPU Support List" for more information.)
Chipset
AMD A520
Memory
4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
(Please refer "Memory Support List" for more information.)
Onboard Graphics
Integrated Graphics Processor:
1 x DisplayPort, supporting a maximum resolution of 5120x2880@60 Hz
Support for DisplayPort 1.4 version, HDCP 2.3, and HDR.
1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
Support for HDMI 2.1 version, HDCP 2.3, and HDR.
Maximum shared memory:
16 GB
Audio
Realtek® Audio CODEC
High-Definition Audio
2/4/5.1/7.1-channel
* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
LAN
Realtek® GbE LAN chip (1 Gbps/100 Mbps)
Expansion Slots
1 x PCI Express x16 slot, integrated in the CPU:
Supporting PCIe 3.0 x16 mode
1 x PCI Express x1 slot, integrated in the Chipset:
Supporting PCIe 3.0 x1 mode
Storage Interface
1 x M.2 connector, integrated in the CPU, supporting Socket 3, M key, type 2280 SSDs:
Supporting SATA and PCIe 3.0 x4/x2 SSDs
4 x SATA 6Gb/s connectors, integrated in the Chipset:
Supporting for RAID 0, RAID 1, and RAID 10
USB
CPU:
4 x USB 3.2 Gen 1 ports on the back panel
Chipset:
2 x USB 3.2 Gen 1 ports available through the internal USB header
6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
Internal I/O Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
1 x system fan header
1 x M.2 Socket 3 connector
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
1 x Clear CMOS jumper
Back Panel Connectors
1 x PS/2 keyboard/mouse port
1 x DisplayPort
1 x HDMI port
4 x USB 3.2 Gen 1 ports
2 x USB 2.0/1.1 ports
1 x RJ-45 port
3 x audio jacks
I/O Controller
iTE® I/O Controller Chip
H/W Monitoring
Voltage detection
Temperature detection
Fan speed detection
Fan fail warning
Fan speed control
* Whether the fan speed control function is supported will depend on the cooler you install.
BIOS
1 x 128 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features
Support for APP Center
* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
@BIOS
EasyTune
Smart Backup
System Information Viewer
Support for Q-Flash
Support for Xpress Install
Bundled Software
Norton® Internet Security (OEM version)
LAN bandwidth management software
Operating System
Support for Windows 11 64-bit
Support for Windows 10 64-bit
Form Factor
Micro ATX Form Factor; 24.4cm x 24.4cm
AMD A520 Motherboard with Pure Digital VRM Solution, High Quality Audio, GIGABYTE Gaming LAN with Bandwidth Management, PCIe 3.0 x4 M.2, Intel Dual Band 802.11ac WIFI, RGB FUSION 2.0, Smart Fan 5, Q-Flash Plus
Supports AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series and Ryzen™ 3000 and Ryzen™ 3000 G-Series Processors
Dual Channel ECC/ Non-ECC Unbuffered DDR4, 4 DIMMs
5+3 Phases Pure Digital VRM Solution with Low RDS(on) MOSFETs
Ultra-Fast NVMe PCIe 3.0 x4 M.2 Connector
Onboard Intel® Dual Band 802.11ac Wireless & BT 4.2 with WIFI Antenna
GIGABYTE Exclusive 8118 Gaming LAN with Bandwidth Management
HDMI, DVI-D, Display Ports for Multiple Display
RGB FUSION 2.0 Supports Addressable LED & RGB LED Strips
Smart Fan 5 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card
Category
Specification
CPU
AMD Socket AM4, support for Ryzen™ 5000 Series / Ryzen™ 5000 G-Series / Ryzen™ 4000 G-Series / Ryzen™ 3000 / Ryzen™ 3000 G-Series Processors (Refer to CPU Support List)
Chipset
AMD A520
Memory
4 x DDR4 DIMM sockets, up to 128 GB total (32 GB per DIMM); Dual channel; Supports ECC and non-ECC unbuffered memory; XMP supported
Supported Memory Speeds
Up to DDR4 4733(O.C.) depending on CPU model
Onboard Graphics
1 x DVI-D (1920x1200@60Hz), 1 x DisplayPort (5120x2880@60Hz), 1 x HDMI (4096x2160@60Hz); Supports up to 3 displays
Audio
Realtek® Audio CODEC, High Definition Audio, 2/4/5.1/7.1-channel support
LAN
Realtek® GbE LAN (1 Gbps / 100 Mbps)
Wireless Communication
Intel® Wireless-AC 3168 (Wi-Fi 5, Bluetooth 4.2) or Intel® Wireless-AC 9260 (Wi-Fi 5, Bluetooth 5.1) or Realtek® RTL8821CE (Wi-Fi 5, Bluetooth 5.0) depending on PCB revision
Expansion Slots
1 x PCIe 3.0 x16 slot (CPU), 2 x PCIe 3.0 x1 slots (Chipset)
Storage Interface
1 x M.2 (PCIe 3.0 x4/x2 & SATA), 4 x SATA 6Gb/s ports, supports RAID 0/1/10
USB Ports
Rear: 4 x USB 3.2 Gen 1, 2 x USB 2.0; Internal: 2 x USB 3.2 Gen 1, 2 x USB 2.0
Internal I/O
24-pin ATX, 8-pin CPU, CPU fan, 2 system fan headers, RGB/ARGB headers, front panel audio, SATA, USB headers, TPM, serial port, Q-Flash Plus button
Back Panel I/O
PS/2 combo, DVI-D, DisplayPort, HDMI, 2 x SMA antenna connectors, 4 x USB 3.2 Gen 1, 2 x USB 2.0, RJ-45, 3 x audio jacks
I/O Controller
iTE® I/O Controller Chip
H/W Monitoring
Voltage, temperature, and fan speed detection; Fan speed and failure warnings
BIOS
128 Mbit flash, AMI UEFI BIOS, supports Q-Flash and Q-Flash Plus
Unique Features
GIGABYTE APP Center, @BIOS, EasyTune, RGB Fusion, Smart Backup, System Information Viewer
Bundled Software
Norton® Internet Security (OEM), LAN Bandwidth Management Software
Operating System
Windows 10 64-bit, Windows 11 64-bit
Form Factor
Micro ATX (24.4 cm x 24.4 cm)
Form Factor: M.2 2280
Interface: PCI-Express 4.0x4, NVMe 1.3
Total Capacity: 2000GB*
Sequential Read Speed : up to 5000 MB/s**
Sequential Write speed : up to 4400 MB/s**
Wear Leveling, Over-Provision technologies
TRIM & S.M.A.R.T supported
Fully Body Copper Heat Spreader
World First PCIe 4.0x4 Controller
The World First PCIe 4.0x4 Controller, Phison PS5016-E16 controller, made by 28nm manufacturing technology. The advanced fabrication process ensures PS5016-E16 has enough compute power for ECC processing when adopting the latest 3D TLC NAND flash. PS5016-E16 also features eight NAND channels with 32 CE targets, DDR4 DRAM caching, and a PCIe 4.0x4 interface. As for features, the chip supports the NVMe 1.3 protocol, LDPC error correction, and Wear Leveling, Over-Provision technologies to improve reliability and durability of SSDs.
NAND Flash Selected for High Quality and Performance
TOSHIBA BiCS4 96 Layers 3D TLC (800MT/s)
Toshiba BiCS4 NAND Flash optimizes circuitry and architecture by increasing to 96 layers for higher storage space per unit area. 800MT/s throughput on the AORUS NVMe Gen 4 SSD far exceeds that of PCIe 3.0x4 devices for superior storage performance.
Specification
Details
Memory Type
DDR4
Capacity
16GB (8GBx2)
Multi-Channel Kit
Dual Channel Kit
OC Profile Support
Intel XMP 2.0
Tested Speed (Up To) (XMP)
3600 MT/s
Tested Latency (XMP)
18-22-22-42
Tested Voltage (XMP)
1.35V
Registered/Unbuffered
Unbuffered
Error Checking (ECC)
Non-ECC
SPD Speed (Default)
2133 MT/s
SPD Voltage (Default)
1.20V
Fan Included
No
Features
Intel XMP 2.0 (Extreme Memory Profile) Ready
Additional Notes
Do not mix memory kits. Memory kits are matched sets designed to run together.
Prior to enabling XMP, kits boot at SPD speed under default BIOS settings.
Enable XMP/DOCP/A-XMP in BIOS to reach rated speed with compatible hardware.
System stability depends on motherboard and CPU capability.
Usage outside specs may cause instability or damage.
Module height can be found in FAQ.
For support, contact G.SKILL technical support via email.
World First PCIe 4.0x4 Controller
The World First PCIe 4.0x4 Controller, Phison PS5016-E16 controller, made by 28nm manufacturing technology. The advanced fabrication process ensures PS5016-E16 has enough compute power for ECC processing when adopting the latest 3D TLC NAND flash. PS5016-E16 also features eight NAND channels with 32 CE targets, DDR4 DRAM caching, and a PCIe 4.0x4 interface. As for features, the chip supports the NVMe 1.3 protocol, LDPC error correction, and Wear Leveling, Over-Provision technologies to improve reliability and durability of SSDs.
NAND Flash Selected for High Quality and Performance
TOSHIBA BiCS4 96 Layers 3D TLC (800MT/s)
Toshiba BiCS4 NAND Flash optimizes circuitry and architecture by increasing to 96 layers for higher storage space per unit area. 800MT/s throughput on the AORUS NVMe Gen 4 SSD far exceeds that of PCIe 3.0x4 devices for superior storage performance.
Capacity
Model
Sequential Read MB/s
Sequential Write MB/s
Random Read IOPS
Random Write IOPS
500GB
AORUS NVMe Gen4 SSD 500GB (GP-ASM2NE6500GTTD)
5000 MB/s
2500 MB/s
400k
550k
1000GB
AORUS NVMe Gen4 SSD 1TB (GP-ASM2NE6100TTTD)
5000 MB/s
4400 MB/s
750k
700k
2000GB
AORUS NVMe Gen4 SSD 2TB (GP-ASM2NE6200TTTD)
5000 MB/s
4400 MB/s
750k
700k
Key specifications
Processor:
Intel Core i5-11400H (2.7 GHz base clock, up to 4.5 GHz turbo)
Graphics:
NVIDIA GeForce RTX 3050 Ti with 4GB GDDR6 memory
Display:
15.6-inch Full HD (1920x1080) IPS, 144Hz refresh rate
Memory:
16GB DDR4-3200 RAM (2 x 8GB)
Storage:
512GB PCIe NVMe SSD
Operating System:
Windows 10 Home
Keyboard:
All-zone single-color backlit keyboard with 15 color options
Battery:
48.96Wh Li-ion battery
Weight:
Approximately 2.2 kg (4.85 lbs)
Ports and connectivity
USB: 1x USB 2.0 Type-A, 1x USB 3.2 Gen 1 Type-A, 1x USB 3.2 Gen 2 Type-A, 1x USB 3.2 Gen 2 Type-C
Video:
1x HDMI 2.0, 1x mini DisplayPort 1.4
Audio:
1x Audio combo jack, 1x Microphone jack
Other:
1x SD Card Reader, 1x RJ-45 LAN port, 1x DC-in Jack
Wireless:
Wi-Fi 6 and Bluetooth 5.2
AMD A520 Mini-ITX Ultra Durable Motherboard with Direct 6 Phases Digital VRM, Onboard 802.11ac WIFI, Realtek GbE LAN with Bandwidth Management, PCIe 3.0 x4 M.2, Smart Fan 5 with FAN STOP, RGB FUSION 2.0, Q-Flash Plus
Supports AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series and Ryzen™ 3000 and Ryzen™ 3000 G-Series Processors
Dual Channel ECC/ Non-ECC Unbuffered DDR4, 2 DIMMs
Direct 6 Phases Digital VRM Solution with 55A DrMOS
Ultra-Fast NVMe PCIe 3.0 x4 M.2
Onboard Dual Band 802.11ac WIFI & BT 4.2 with Ultra Durable™ Antenna
Realtek GbE LAN with Bandwidth Management
DisplayPort, Dual HDMI for for Multiple Display
RGB FUSION 2.0 with Addressable LED & RGB LED Strips Support
Smart Fan 5 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card
Anti-Sulfur Resistors Design
Direct 6 Phases Digital VRM Solution with 55A DrMOS
A520I AC motherboard uses a Direct 6 phases digital CPU power design which includes both digital PWM Controller and DrMOS. These 100% digital controller offer incredible precision in delivering power to the motherboard's most power-hungry and energy-sensitive components, allowing enthusiasts to get the absolute maximum performance from 3rd Gen AMD Ryzen™ processors.
Digital PWM Controller delivers appropriate voltage to the CPU.
Direct 6 Phases DrMOS, each power phase connects directly to the CPU. With capability to handle up to 330 Amps current in total.
All-solid capacitors to improve Transient response and minimize oscillation.
8pin Solid Pin CPU Power Connector.
Faster and Better Coverage with Dual Band 802.11ac WIFI & BT4.2 Module
The onboard 802.11ac WIFI module supports the Dual Band and up to 433 Mbps transition speed, 3x faster than 802.11n and also support BLUETOOTH 4.2.The brand new of Ultra Durable™ Antenna supports Dual Band 802.11ax/ac 2.4GHz & 5GHz with 4dBi signal gained. It featured with better signal strength as compared to traditional antenna design and the magnetic base is the best design for signal strength direction and location.
Realtek GbE LAN with Bandwidth Management
Realtek Gigabit LAN features a network bandwidth management application which helps to improve network latency and maintain low ping times to deliver better responsiveness in crowded LAN environments.
NVMe PCIe Gen3 x4 M.2 Connector
GIGABYTE Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their system’s potential.
Dual HDMI 2.1 for 4K / 60P / 21:9 / HDCP 2.3 Support
HDMI 2.1, which is backwards compatible with HDMI 2.0/ 1.4 and offering 48 Gb/s of bandwidth – twice times more than previous generation. This unlocks the potential for users to transfer multiple video streams, as well as a native cinematic 21:9 ratio (which most movies are shot in), Full HDR and HDCP 2.3 support, to offer the best visual experience for viewers.
SPECIFICATIONS
CPU
AMD Socket AM4, support for: AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series and Ryzen™ 3000 and Ryzen™ 3000 G-Series Processors
(Please refer "CPU Support List" for more information.)
Chipset
AMD A520
Memory
2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
Support for DDR4 5300(O.C.) / 5200(O.C.) / 5100(O.C.) / 4800(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules*
* ECC memory (ECC mode) support varies by CPU
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
(Please refer "Memory Support List" for more information.)
Onboard Graphics
Integrated Graphics Processor with AMD Radeon™ Graphics support:
1 x DisplayPort port, supporting a maximum resolution of 5120x2880@60 Hz
* Support for DisplayPort 1.4 version, HDCP 2.3, and HDR.
2 x HDMI ports, supporting a maximum resolution of 4096x2160@60 Hz
* Support for HDMI 2.1 version, HDCP 2.3, and HDR.
Support for up to 3 displays at the same time
Maximum shared memory
16 GB
Audio
Realtek® Audio CODEC
High-Definition Audio
2/4/5.1/7.1-channel
* To configure 7.1-channel audio, you need to open the audio software and select Device advanced settings > Playback Device to change the default setting first. Please visit GIGABYTE's website for details on configuring the audio software.
LAN
Realtek® GbE LAN chip (10/100/1000 Mbit)
Wireless Communication module
Intel® Wi-Fi AC 3168 (For PCB rev. 1.0/1.2/1.3)/Intel® Wi-Fi AC 9260 (For PCB rev. 1.1)/ Realtek® Wi-Fi AzureWave Wi-Fi AW-CB304NF (Realtek® RTL8821CE) (For PCB rev. 1.4)
WIFI 802.11a/b/g/n/ac, supporting 2.4/5 GHz Dual-Band
BLUETOOTH 4.2
Support for 11ac wireless standard
* Actual data rate may vary depending on environment and equipment.
Expansion Slots
Integrated in the CPU:
1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16
Storage Interface
Integrated in the CPU:
1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe 3.0 x4/x2 SSD support)
Chipset:
4 x SATA 6Gb/s connectors
Support for RAID 0, RAID 1, and RAID 10
Chipset:
4 x SATA 6Gb/s connectors
USB
Integrated in the CPU:
4 x USB 3.2 Gen 1 ports on the back panel
Chipset:
2 x USB 3.2 Gen 1 ports available through the internal USB header
4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
Internal I/O Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
2 x system fan headers
1 x addressable LED strip header
1 x RGB LED strip header
1 x M.2 Socket 3 connector
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x speaker header
1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
1 x serial port header
1 x Clear CMOS jumper
＊All fan headers are subject to support AIO Pump, Pump and high-performance fan with the capability of delivering up to 2A/12V @ 24W.
Back Panel Connectors
1 x DisplayPort
2 x HDMI ports
4 x USB 3.2 Gen 1 ports
2 x USB 2.0/1.1 ports
1 x Q-Flash Plus button
1 x RJ-45 ports
2 x SMA antenna connectors (1T1R)
3 x audio jacks
I/O Controller
iTE® I/O Controller Chip
H/W Monitoring
Voltage detection
Temperature detection
Fan speed detection
Overheating warning
Fan fail warning
Fan speed control
* Whether the fan speed control function is supported will depend on the cooler you install.
BIOS
1 x 128 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features
Support for APP Center
* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
@BIOS
EasyTune
RGB Fusion
Smart Backup
System Information Viewer
Support for Q-Flash Plus
Support for Q-Flash
Bundled Software
Norton® Internet Security (OEM version)
LAN bandwidth management software
Operating System
Support for Windows 11 64-bit
Support for Windows 10 64-bit
Form Factor
Mini-ITX Form Factor; 17.0cm x 17.0cm
