Specifications
Model Parameters - C6N
Model
CS-C6N-A0-1C2WFR
Camera
Image Sensor
1/4" Progressive Scan CMOS
Shutter Speed
Self-adaptive shutter
Lens
4mm@ F2.4, view angle: 85° diagonal, 75° horizontal, 45° vertical
Lens Mount
M12
Day & Night
IR-cut filter with auto-switching
DNR
3D DNR
WDR
Digital WDR
Compression
Video Compression
H.264
Video Bit Rate
Full HD, HD, Standard. Adaptive bit rate.
Max. Resolution
1920 × 1080
Frame Rate
Max. 15fps; Self-adaptive during network transmission
Network
Smart Alarm
Motion detection
Wi-Fi Pairing
AP Pairing
Protocol
EZVIZ Cloud Proprietary Protocol
Interface Protocol
EZVIZ Cloud Proprietary Protocol
Interface
Storage
MicroSD card slot (Max. 256 GB)
Power
Micro USB
Wired Network
RJ45 X 1 (10M/100M self-adaptive Ethernet port)
Wi-Fi
Standard
IEEE802.11 b/g/n
Frequency Range
2.4 GHz ~ 2.4835 GHz
Channel Bandwidth
Supports 20MHz
Security
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate
11b: 11 Mbps, 11g: 54 Mbps, 11n: 72 Mbps
General
Power Supply
DC 5V/1A
Power Consumption
5W max
IR Range
MAX. 10m (32.81 fts)
Dimensions
88 mm x 88.2 mm x 119 mm (3.46” x 3.47” x 4.69”)
Packaging Dimensions
103 mm x 103 mm x 168 mm (4.06” x 4.06” x 6.61”)
Bare Weight
218g (0.48lb)
Packaging Contents
Packaging Contents
C6N camera; Base; Screw Kit; Power Cable 3m (9.8 ft.); Drill Template; Power Adapter; Quick Start Guide
Operating Environment
Temperature
-10° C to 45° C (14° F to 113° F)
Humidity
95% or less (non-condensing)
Certifications
Certifications
FCC / UL / CE / WEEE / REACH / RoHS
Key specifications
Feature
Specification
Model
DS-2CE16D0T-EXIPF
Image Sensor
2 MP CMOS
Resolution
1920×10801920 cross 1080
1920×1080
Lens
2.8 mm fixed lens
Field of View (2.8mm)
Horizontal:
96.5∘96.5 raised to the composed with power
96.5∘
, Vertical:
48.9∘48.9 raised to the composed with power
48.9∘
, Diagonal:
120.5∘120.5 raised to the composed with power
120.5∘
IR Distance
Up to 20 m
White Light Distance
Up to 20 m
Night Vision
Smart Hybrid Light (IR, White Light, Smart Mode)
Video Output
Switchable TVI/AHD/CVI/CVBS
Weather Resistance
IP66 or IP67
Power Supply
12 VDC
±plus or minus
±
25%
Dimensions
138.8138.8
138.8
mm
×60.9cross 60.9
×60.9
mm
×57.9cross 57.9
×57.9
mm
Operating Temperature
-40∘negative 40 raised to the composed with power
−40∘
C to
60∘60 raised to the composed with power
60∘
C (
-40∘negative 40 raised to the composed with power
−40∘
F to
140∘140 raised to the composed with power
140∘
F)
Image Sensor2 MP CMOS
Signal SystemPAL/NTSC
Max. Resolution1920 (H) × 1080 (V)
Min. Illumination0.02 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
Day & NightIR Cut Filter
Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
Lens
Lens Type2.8 mm, 3.6 mm Fixed Lens
Focal Length & FOV
2.8 mm, horizontal FOV: 96.5°, vertical FOV: 48.9°, diagonal FOV: 120.5°
3.6 mm, horizontal FOV: 76.9°, vertical FOV: 40.6°, diagonal FOV: 92.0°
Lens MountM12
Illuminator
Supplement Light RangeUp to 20 m
Frame Rate
TVI: 1080p@25fps/30fps
AHD: 1080p@25fps/30fps
CVI: 1080p@25fps/30fps
CVBS: PAL/NTSC
Wide Dynamic Range (WDR)Digital WDR
Image Parameters SwitchSTD/HIGH-SAT
Day/Night ModeAuto/Color/BW (Black and White)
White BalanceAuto
Image EnhancementDWDR, BLC, Global
Noise Reduction2D DNR
Image SettingsBrightness, Mirror, Smart IR, Sharpness, AGC
Interface
Video OutputSwitchable TVI/AHD/CVI/CVBS
General
LanguageEnglish
Operating Condition-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
MaterialPlastic
CommunicationHIKVISION-C
Dimension138.8 mm × 60.9 mm × 57.9 mm (5.465" × 2.389" 2.278")
WeightApprox. 145 g (0.32 lb.)
Power12 VDC ± 25%, Max. 3.3 W
Approval
ProtectionIP67
DS-2CE56D0T-IRPF(C)
Camera
Image Sensor2 MP CMOS
Max. Resolution1920 (H) × 1080 (V)
Min. Illumination0.01Lux @ (F2.0, AGC ON), 0 Lux with IR
Shutter TimePAL: 1/25 s to 1/50,000 s NTSC: 1/30 s to 1/50,000 s
Day & NightICR
Angle AdjustmentPan: 0 to 360°, Tilt: 0 to 75°, Rotation: 0 to 360°
Signal SystemPAL/NTSC
Lens
Lens Type2.8 mm, 3.6 mm, 6 mm fixed lens
Focal Length & FOV
2.8 mm, horizontal FOV: 101°, vertical FOV: 60°, diagonal FOV: 122°
3.6 mm, horizontal FOV: 79.6°, vertical FOV: 43.5°, diagonal FOV: 93.7°
6 mm, horizontal FOV: 51.9°, vertical FOV: 30°, diagonal FOV: 58.8°
Lens MountM12
Image Parameters SwitchSTD/HIGH-SAT
Image SettingsBrightness, Sharpness, Smart IR
Frame RateTVI: 1080P@30fps, 1080P@25fps CVI: 1080P@30fps, 1080P@25fps AHD: 1080P@30fps, 1080P@25fps CVBS: PAL/NTSC
Day/Night ModeAuto/Color/BW (Black and White)
Wide Dynamic Range (WDR)Digital WDR
Image EnhancementBLC, HLC
White BalanceAuto/Manual
AGCYes
Interface
Video OutputSwitchable TVI/AHD/CVI/CVBS
General
MaterialPlastic
DimensionΦ 89.9 mm × 70.1 mm (Φ 3.54" × 2.76")
WeightApprox. 130 g (0.29 lb.)
Operating Condition‘-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
CommunicationHIKVISION-C
LanguageEnglish
Power Supply12 VDC ± 25%
ConsumptionMax. 2.2 W
IR RangeUp to 20 m
Product properties
Camera
Appearance :
Bullet
Image Sensor :
1/2.8" progressive scan CMOS
Min. Illumination :
Color: 0.01 Lux @(F1.2, AGC ON), 0.028 Lux @ (F2.0, AGC ON)
Shutter Speed :
1/3 s to 1/100, 000 s
Slow Shutter :
Yes
Auto-Iris :
No
Day & Night :
IR cut filter
Digital Noise Reduction :
3D DNR
WDR :
DWDR
Angle Adjustment :
Pan: 0° to 360°, tilt: 0° to 180°, rotation: 0° to 360°
Lens
Focal Length :
2.8 mm, 4 mm
Aperture :
F2.0
Focus :
Fixed
Angle of view :
2.8 mm, horizontal FOV 114.8°, vertical FOV 62°, diagonal FOV 135.5°
4 mm, horizontal FOV 86°, vertical FOV 46.5°, diagonal FOV 102.5°
Lens Mount :
M12
IR
IR Range :
Up to 30 m
Wavelength :
850 nm
Compression Standard
Video Compression
Main stream:
H.265+/H.265/H.264+/H.264
Sub stream:
H.265/H.264/MJPEG
H.264 Type :
Main Profile/High Profile/Baseline Profile
H.265 Type :
Main Profile
Video Bit Rate :
32 Kbps to 8 Mbps
Smart Feature-Set
Region of Interest :
1 fixed region for main stream
Resolution :
2MP
Main Stream Max. Frame Rate
50Hz:
25fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz:
30fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-stream Max. Frame Rate
50Hz:
25fps (640 × 480, 640 × 360, 320 × 240)
60Hz:
30fps (640 × 480, 640 × 360, 320 × 240)
Image Enhancement :
BLC, 3D DNR
Image Setting :
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
Day/Night Switch :
Auto, scheduled, day, night
Network
Alarm Trigger :
Motion detection, video tampering alarm, illegal login
Protocols :
TCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, UDP
General Function :
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark
API :
ONVIF (PROFILE S), ISAPI
Simultaneous Live View Up to 6 channels
User/Host
Up to 32 users
3 levels: Administrator, Operator, and User
Client :
iVMS-4200, Hik-Connect
Web Browser :
IE8+, Chrome 31.0-44, Firefox 30.0-51
Interface
Communication Interface :
1 RJ45 10M/100M self-adaptive Ethernet port
General
Operating Conditions :
-30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing)
Power Supply :
12 VDC ± 25%, 5.5 mm coaxial power plug
PoE (802.3af, class 3)
Power Consumption :
12 VDC, 0.3 A, Max: 3.5 W
PoE:
(802.3af, 36 V to 57 V), 0.2 A to 0.1 A, Max: 4.5 W
Ingress Protection level :
IP67
Material :
Front cover: metal, camera body: plastic, bracket: plastic
Dimensions :
Ø 70 mm × 181.6 mm (Ø 2.8" × 7.1")
Weight
Camera:
Approx. 270 g (0.6 lb.)
With package:
Approx. 510 g (1.1 lb.)
Warranty Information:
Item compatibility is buyer’s responsibility.
For security purposes: Kindly secure unboxing video incase wrong item and defective upon received.
Check all items upon receipt.
All items/claims for warranty are carry-in.
Tampered warranty sticker voids the warranty.
Overclocking may void the warranty.
Items for warranty must be complete with origina
HWI-B121H
Camera
Appearance
Bullet
Image Sensor
1/2.8" progressive scan CMOS
Min. Illumination
Color: 0.01 Lux @(F1.2, AGC ON), 0.028 Lux @ (F2.0, AGC ON)
Shutter Speed
1/3 s to 1/100, 000 s
Slow Shutter
Yes
Auto-Iris
No
Day & Night
IR cut filter
Digital Noise Reduction
3D DNR
WDR
DWDR
Angle Adjustment
Pan: 0° to 360°, tilt: 0° to 180°, rotation: 0° to 360°
Lens
Focal Length
2.8 mm, 4 mm
Aperture
F2.0
Focus
Fixed
Angle of view
2.8 mm, horizontal FOV 114.8°, vertical FOV 62°, diagonal FOV 135.5°4 mm, horizontal FOV 86°, vertical FOV 46.5°, diagonal FOV 102.5°
Lens Mount
M12
IR
IR Range
Up to 30 m
Wavelength
850 nm
Compression Standard
Video Compression
Main stream: H.265+/H.265/H.264+/H.264Sub stream: H.265/H.264/MJPEG
H.264 Type
Main Profile/High Profile/Baseline Profile
H.265 Type
Main Profile
Video Bit Rate
32 Kbps to 8 Mbps
Smart Feature-Set
Region of Interest
1 fixed region for main stream
Resolution
2MP
Main Stream Max. Frame Rate
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-stream Max. Frame Rate
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Image Enhancement
BLC, 3D DNR
Image Setting
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
Day/Night Switch
Auto, scheduled, day, night
Network
Alarm Trigger
Motion detection, video tampering alarm, illegal login
Protocols
TCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, UDP
General Function
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark
API
ONVIF (PROFILE S), ISAPI
Simultaneous Live View
Up to 6 channels
User/Host
Up to 32 users3 levels: Administrator, Operator, and User
Client
iVMS-4200, Hik-Connect
Web Browser
IE8+, Chrome 31.0-44, Firefox 30.0-51
Interface
Communication Interface
1 RJ45 10M/100M self-adaptive Ethernet port
General
Operating Conditions
-30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing)
Power Supply
12 VDC ± 25%, 5.5 mm coaxial power plugPoE (802.3af, class 3)
Power Consumption
12 VDC, 0.3 A, Max: 3.5 WPoE: (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, Max: 4.5 W
Ingress Protection level
IP67
Material
Front cover: metal, camera body: plastic, bracket: plastic
Dimensions
Ø 70 mm × 181.6 mm (Ø 2.8" × 7.1")
Weight
Camera: Approx. 270 g (0.6 lb.)With package: Approx. 510 g (1.1 lb.)
HWI-D121H
Camera
Appearance
Dome
Image Sensor
1/2.8" progressive scan CMOS
Min. Illumination
Color: 0.01 Lux @(F1.2, AGC ON), 0.028Lux @ (F2.0, AGC ON)
Shutter Speed
1/3 s to 1/100, 000 s
Slow Shutter
Yes
Auto-Iris
No
Day & Night
IR cut filter
Digital Noise Reduction
3D DNR
WDR
DWDR
Angle Adjustment
Pan: 0° to 355°, tilt: 0° to 70°, rotate: 0° to 355°
Lens
Focal Length
2.8 mm, 4 mm
Aperture
F2.0
Focus
Fixed
Angle of view
2.8 mm, horizontal FOV 114.8°, vertical FOV 62°, diagonal FOV 135.5°4 mm, horizontal FOV 86°, vertical FOV 46.5°, diagonal FOV 102.5°
Lens Mount
M12
IR
IR Range
Up to 30 m
Wavelength
850 nm
Compression Standard
Video Compression
Main stream: H.265+/H.265/H.264+/H.264Sub stream: H.265/H.264/MJPEG
H.264 Type
Main Profile/High Profile/Baseline Profile
H.265 Type
Main Profile
Video Bit Rate
32 Kbps to 8 Mbps
Smart Feature-Set
Region of Interest
1 fixed region for main stream
Resolution
2MP
Main Stream Max. Frame Rate
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-stream Max. Frame Rate
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Image Enhancement
BLC, 3D DNR
Image Setting
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
Day/Night Switch
Auto, scheduled, day, night
Network
Alarm Trigger
Motion detection, video tampering alarm, illegal login
Protocols
TCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, UDP
General Function
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark
API
ONVIF (PROFILE S), ISAPI
Simultaneous Live View
Up to 6 channels
User/Host
Up to 32 users3 levels: Administrator, Operator, and User
Client
iVMS-4200, Hik-Connect
Web Browser
IE8+, Chrome 31.0-44, Firefox 30.0-51
Interface
Communication Interface
1 RJ45 10M/100M self-adaptive Ethernet port
General
Operating Conditions
-30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing)
Power Supply
12 VDC ± 25%, 5.5 mm coaxial power plugPoE (802.3af, class 3)
Power Consumption
12 VDC, 0.4 A, Max: 5 WPoE: (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, Max: 6.5 W
Ingress Protection level
IP67
Impact Protection
IK10
Material
Bubble: plastic, front cover: plastic, bottom base: metal
Dimensions
Camera: Ø 111 mm × 82.4 mm (Ø 4.4" × 3.2")With package: 134 mm × 134 mm × 108 mm (5.3" × 5.3" × 4.3")
Weight
Camera: Approx. 400 g (0.9 lb.)With package: Approx. 600 g (1.3 lb.)
CAMERA - C110
Image Sensor
1/2.8’’
Lens
F/NO: 2.0, Focal Length: 3.3 mm
Night Vision
850 nm IR LED (up to 30 ft)
Resolution
3MP（2304 x 1296）
VIDEO
Video Streaming
3MP
Video Compression
H.264
AUDIO
Audio Communication
Two-Way Audio
Audio Input & Output:
Microphone and Speaker
NETWORK
Wireless Rate
11 Mbps (802.11 b)54 Mbps (802.11 g)72.2Mbps (802.11n)
Wireless Security
WPA, WPA2-PSK
Security
128 Bit AES Encryption with SSL/TLS
Frequency
2.4 GHz
POWER
Camera input
3 Meter Power Cable
ACTIVITY NOTIFICATIONS
Input Trigger
Motion Detection
Output Notification
Push Notification
SYSTEM
Regulatory Certification
CE, NCC
System Requirements
iOS 10+, Android 5.0+
ENVIRONMENT
Operating Temperature
0-40 °C (32-104 °F)
Storage Temperature
-40-70 °C (-40-158 °F)
Operating Humidity
10-90% RH Non-Condensing
Storage Humidity
5-90% RH Non-Condensing
PACKAGE CONTENTS
Package Contents
Tapo C110DC Power AdapterQuick Start GuideMounting ScrewsMounting Template
HARDWARE
Button
Reset Button
Indicator LED
System LED
Adapter Input
100-240V, AC, 50/60 Hz, 0.3 A
Adapter Output
9.0 V / 0.6 A
Dimensions (W x D x H)
2.7 x 2.1 x 3.9 in (67.6 x 54.8 x 98.9 mm)
Tapo Indoor/Outdoor Wi-Fi Home Security Camera
Indoor & Outdoor 24/7 Monitoring - Place it in your living room, bedroom, baby's room, backyard, or front door for round-the-clock coverage and IP66 weatherproof construction: day, night, rain, or shine
2K QHD During the Day & Night - Upgrade home security to 2K QHD clarity, surpassing 1080p for impeccable detail. The starlight sensor captures vibrant high-definition moments even in low light.
Built-In Dual Spotlights - In low-light conditions, the dual spotlights provide vivid full-color night vision, capturing every detail.
Invisible IR Mode - To avoid distractions caused by the red IR LEDs for your kids, or pets, switch to the invisible IR mode for uninterrupted night monitoring without the red IR indicator.
Effortless Installation - Effortless setup with C120's sturdy magnetic base and a generous 9.8 ft. power cord for flexible placement.
Crisp Two-Way Audio - Engage in clear conversations with your loved little ones, guests, and delivery drivers through the high-quality microphone and speakers.
Secured Local & Cloud Storage - Save up to 512 GB on a microSD card or choose Tapo Care Cloud for a 30-day video history and more benefits, including activity notifications with snapshots.
Free AI Detection - Smart AI tech detects and identifies people, pets, and vehicles, sending only relevant notifications, minimizing unnecessary alerts
Indoor/Outdoor Versatility. Almost anywhere
Exquisite Design
Exquisite design suitable for diversified indoor scenarios.
IP66 Weatherproof
Mounted even in extreme external weather conditions to keep an eye on your home.
Secure Installation with Weatherproof
Mounts securely in your desired placement under different weather condition with IP66 Weatherproofing.
Magnetic Mount for Easy Installation
A magnetic mount and a long 9.8ft. power cord provides flexible mounting options.
Free Smart AI Detection
With smart AI detection, choose to detect vehicles, pets, people, or all three.
IR Toggle (Red Lights) For Night Vision
IR LED On
The IR light assists in providing night vision visibility up to 30 ft. It is also a great deterrent to let passersby know that your home is being monitored.
Invisible IR On
If the red IR LEDs are a distraction, you can switch to invisible IR mode to monitor during the night without having the red IR indicator. Ideal for indoor scenarios with children and pets.
Dual-Spotlights for Improved Discovery
Better Visibility in Any Condition
With dual-spotlights the Tapo C120 provides a better viewing experience especially in low light conditions.
Light and Custom Sound Triggers
The camera can be set to have the spotlights turn on when motion is detected. You can also customize sound to play in the event of a motion trigger.
Specification
CAMERA
Image Sensor
1/2.9” Progressive Scan CMOS Starlight Sensor
Lens
Focal Length: 3.17mmAperture: 1.65Field of View: 120°(Diagonal), 103°(Horizontal), 55°(Vertical)
Motion Range
/
Night Vision
850 nm IR LED (30 ft / 9 m)940 nm IR LED (30 ft / 9 m)Full-Color Night Vision
Lighting
/
Interface & Button
1× RESET Button1× MicroSD Card Slot (Up to 512 GB)
Hub Compatibility
/
Resolution
2K QHD 4MP (2560 * 1440 px)
LENS
Focal Length
3.17mm
Aperture
1.65
FOV
120°(Diagonal), 103°(Horizontal), 55°(Vertical)
HUB
Device Compatibility
/
Connection Capacity
/
Interface & Button
/
VIDEO & AUDIO
Maximum Resolution
2K QHD 4MP (2560 × 1440 px)
Frame Rate
20 fps (Self-adaptive according brightness)
Digital Zoom
12x
Video Compression
H.264
Live View
Yes
Image Enhancement
3D DNRWDR
Audio Input & Output
Built-in Microphone and Speaker
Audio Communication
Two-Way Audio with Noise Cancellation
Siren Volume
96dB (Level measured at 4-inch/10-cm distance)
STORAGE
Local Storage
MicroSD Card Slot on Camera (Up to 512 GB)General Information about using MicroSD Cards >
Cloud Storage
Tapo Care Cloud Storage Services (Subscription required)
DETECTION and NOTIFICATIONS
Sensor
/
AI Detection
Motion DetectionPerson DetectionLine-Crossing DetectionBabyCry DetectionVehicle DetectionPet DetectionMeow DetectionBark DetectionGlass-Breaking Detection
Activity Zones
Yes
Output Notification
System NotificationSystem Notification with Snapshot (Tapo Care Services)
AUDIO
Audio Communication
Two-Way Audio
Audio Input & Output:
Microphone and Speaker
NETWORK
Network Connectivity
Connect via Wi-Fi
Wireless Connectivity
IEEE 802.11b/g/n, 2.4 GHz Wi-Fi
Protocol
2.4 GHz Wi-Fi, 802.11b/g/n
Wireless Rate
11 Mbps (802.11 b)54 Mbps (802.11 g)72.2Mbps (802.11n)
Ethernet Port
/
Wireless Security
WPA, WPA2-PSK
RTSP
/
ONVIF
/
Security
128 Bit AES Encryption with SSL/TLS
Frequency
2.4 GHz Wi-Fi
SECURITY
Security
On-Device Machine Learning128-bit AES Encryption with SSL/TLSWPA/WPA2-PSK
POWER
Power Source
5V DC Power Adapter
Input Voltage
100-240 V, 50/60 Hz
Output Voltage
5.0 V, 1.0 A (DC Power)
ACTIVITY NOTIFICATIONS
Input Trigger
Person/Pet/Vehicle/Motion Detection
Output Notification
Push Notification
ENVIRONMENT
Operating Temperature
0℃~40 ℃ (32 ℉~104℉)
Storage Temperature
-20℃~60 ℃ (-4 ℉~140℉)
Operating Humidity
10%~90% non-condensing
Storage Humidity
0%~90% non-condensing
PACKAGE CONTENTS
Package Contents
Tapo C120 Camera ×1Power Adapter ×13m Type-C Wire ×1Mounting Anchors ×4Mounting Screws ×4Cable Organizer ×2Mounting Template ×1Iron Camera Base ×13M Adhesive ×1Quick Start Guide ×1
HARDWARE
Button
Reset Button
Indicator LED
System LED
Adapter Input
100-240V, AC, 50/60 Hz, 0.3 A
Adapter Output
5.0 V / 1.0 A
Product Dimensions (W x D x H)
2.65*2.26*1.74 in67.4*57.4*64 mm
GENERAL
Smart Integration
Google Assistant, Amazon Alexa
Weather Resistance
/
Operating Temperature
-20℃~45℃
Storage Temperature
-20℃~60℃
Operating Humidity
10%~90% RH
Storage Humidity
5%~90% RH, Non-condensing
Charging Temperature
/
Dimensions
2.65 × 2.26 × 1.74 in (67.4 × 57.4 × 44.1mm)
Package Contents
Tapo C120 CameraUSB Power AdapterQuick Start GuideMounting ScrewsMounting TemplateMetal Plate3M AdhesiveMounting Anchors 3-Meter Type-C WireCable OrganizersDetaching Pin
