Schneider Enclosure Resi9 MP Surface 2 Rows of 12 Modules IP40 White Door 1 Earth + 1 Neutral Terminal Blocks MIP12212

PCWORX

Schneider Enclosure Resi9 MP Surface 2 Rows of 12 Modules IP40 White Door 1 Earth + 1 Neutral Terminal Blocks MIP12212

(0)

₱1,996.68

Main Specifications

Category	Details
Range	Resi9
Product Name	Resi9 MP
Product / Component Type	Enclosure
Enclosure Type	Modular Enclosure
Modules per Row (18 mm)	12
Number of Horizontal Rows	2
Door Type	Plain
Total Number of Modules (18 mm)	24
9 mm Pitches	24
Rated Current	63 A
Market Segment	Small Commercial, Residential

Dimensions

Dimension	Size
Width (Outside)	268 mm
Height (Outside)	353 mm
Depth (Outside)	102 mm
Internal Depth	80 mm

Mounting & Construction

Category	Details
Enclosure Mounting	Surface
Type of Rail	35 mm Asymmetrical Rail
Mounting Plate	Without Mounting Plate
Cable Entry	1 Trunking Flange, 1 Bare Flange
Enclosure Material	Back Part: Technoplastic Door: Technoplastic Front Face: Technoplastic

Terminal Blocks & Distribution

Category	Details
Terminal Block Function	Earth / Neutral
Number of Terminal Blocks	1 Earth (Screwed) with 16 Outgoers 1 Neutral (Screwed) with 16 Outgoers
Distribution Block Outgoers	Earth: 2 × 16 mm², 6 × 6 mm², 8 × 10 mm² Neutral: 2 × 16 mm², 6 × 6 mm², 8 × 10 mm²

Standards & Protection

Category	Details
Standards	IEC 60670-1, IEC 60670-24
Quality Labels	IMQ
Fire Resistance	Door: 650 °C Back Part: 650 °C Front Face: 650 °C
IP Protection Rating	IP40
IK Protection Rating	IK07
Operating Temperature	-25 °C to +60 °C

Color

Component	Color
Door	White (RAL 9003)
Front Face	White (RAL 9003)

Packaging Information

Package 1

Category	Details
Unit Type	PCE
Units per Package	1
Dimensions (H×W×L)	10.2 × 26.8 × 35.3 cm
Weight	1.194 kg

In stock

Receives in 5 days.

Schneider Enclosure Resi9 MP Surface Mounting 1 Row of 12 Modules IP40 White Door 1 Earth + 1 Neutral Terminal Blocks (MIP12112)

PCWORX

Schneider Enclosure Resi9 MP Surface Mounting 1 Row of 12 Modules IP40 White Door 1 Earth + 1 Neutral Terminal Blocks (MIP12112)

(0)

₱1,106.65

Category	Parameter	Specification
Main	Range	Resi9
	Product name	Resi9 MP
	Product or component type	Enclosure
	Enclosure type	Modular enclosure
	Number of 18 mm modules per row	12
	Number of horizontal rows	1
	Type of door	Plain
Dimensions (Outside)	Width	268 mm
	Height	228 mm
	Depth	101.5 mm
Complementary	Enclosure mounting	Surface
	Number of 9 mm pitches	24
	Total number of 18 mm modules	12
	Rated current [In]	63 A
	Type of rail	35 mm asymmetrical rail
	Mounting plate description	Without mounting plate
	Cable entry	1 bare flange, 1 trunking flange
	Terminal block function	Earth / Neutral
	Number of terminal blocks	1 earth (screwed) with 8 outgoers
		1 neutral (screwed) with 8 outgoers
	Distribution block outgoers	Earth: 1×16 mm², 3×6 mm², 4×10 mm²
		Neutral: 1×16 mm², 3×6 mm², 4×10 mm²
	Enclosure material	Back part: technoplastic
		Door: technoplastic
		Front face: technoplastic
	Internal depth	80 mm
	Colour	Door: White (RAL 9003)
		Front face: White (RAL 9003)
	Market segment	Residential, Small commercial
Environment	Standards	IEC 60670-1, IEC 60670-24
	Quality labels	IMQ
	Fire resistance	650 °C (door, back part, front face)
	IP degree of protection	IP40
	IK degree of protection	IK07
	Operating temperature	-25…60 °C
Packing Units	Unit type of Package 1	PCE
	Number of units in Package 1	1
	Package 1 height	10.0 cm
	Package 1 width	23.0 cm
	Package 1 length	26.5 cm
	Package 1 weight	808 g

In stock

Receives in 5 days.

Schneider Enclosure, Resi9 MP Flush Mounting 1 Row of 8 Modules IP40 White Door 1 Earth + 1 Neutral Terminal Blocks MIP22108

PCWORX

Schneider Enclosure, Resi9 MP Flush Mounting 1 Row of 8 Modules IP40 White Door 1 Earth + 1 Neutral Terminal Blocks MIP22108

(0)

₱999.60

Main Specifications

Parameter	Value
Range	Resi9
Product name	Resi9 MP
Product or component type	Enclosure
Enclosure type	Modular enclosure
Number of 18 mm modules per row	8
Number of horizontal rows	1
Type of door	Plain

Dimensions

Parameter	Value
Width (Wall)	198 mm
Width (Outside)	222 mm
Height (Wall)	228 mm
Height (Outside)	252 mm
Depth (Wall)	80 mm
Depth (Outside)	18 mm
Total depth	98 mm
Internal depth	76 mm

Complementary Characteristics

Parameter	Value
Enclosure mounting	Flush
9 mm pitches	16
Total number of 18 mm modules	8
Rated current $[In]$	63 A
Type of rail	35 mm asymmetrical rail
Mounting plate	Without mounting plate
Cable entry	Pre-cutted holes

Terminal Blocks & Distribution

Parameter	Value
Terminal block function	Earth / Neutral
Number of terminal blocks	1 earth (screwed) with 8 outgoers 1 neutral (screwed) with 8 outgoers
Distribution block outgoers	Earth: 1 × 16 mm², 3 × 6 mm², 4 × 10 mm² Neutral: 1 × 16 mm², 3 × 6 mm², 4 × 10 mm²

Materials & Colour

Parameter	Value
Enclosure material	Back part: technoplastic Door: technoplastic Front face: technoplastic
Colour	Door: White (RAL 9003) Front face: White (RAL 9003)

Market & Environment

Parameter	Value
Market segment	Small commercial, Residential
Standards	IEC 60670-1 IEC 60670-24
Quality labels	IMQ
Fire resistance	Door: 650 °C Back part: 650 °C Front face: 650 °C
IP degree of protection	IP40
IK degree of protection	IK07
Ambient operating temperature	-25…60 °C

Packing Units

Package	Details
Package 1	Type: PCE Units: 1 Height: 9.7 cm Width: 22.2 cm Length: 25.2 cm Weight: 620 g

Out of stock

Receives in 5 days.

Schneider Enclosure, Resi9 MP Surface 1 Row of 8 Modules IP40 White Door 1 Earth + 1 Neutral Terminal Blocks MIP12108

PCWORX

Schneider Enclosure, Resi9 MP Surface 1 Row of 8 Modules IP40 White Door 1 Earth + 1 Neutral Terminal Blocks MIP12108

(0)

₱942.48

Main

Parameter	Specification
Range	Resi9
Product name	Resi9 MP
Product or component type	Enclosure
Enclosure type	Modular enclosure
Nb of 18 mm modules per row	8
Nb of horizontal rows	1
Type of door	Plain

Dimensions

Parameter	Specification
Width	Outside: 196 mm
Height	Outside: 198 mm
Depth	Outside: 101.5 mm
Internal depth	80 mm

Complementary

Parameter	Specification
Enclosure mounting	Surface
9 mm pitches	16
Total number of 18 mm modules	8
Rated current $[In]$	63 A
Type of rail	35 mm asymmetrical rail
Mounting plate description	Without mounting plate
Cable entry	1 bare flange, 1 trunking flange
Terminal block function	Earth / Neutral

Terminal Blocks & Distribution

Parameter	Specification
Number of terminal blocks	1 earth (screwed) with 8 outgoers 1 neutral (screwed) with 8 outgoers
Distribution block outgoers	1 × 16 mm² (earth) 1 × 16 mm² (neutral) 3 × 6 mm² (earth) 3 × 6 mm² (neutral) 4 × 10 mm² (earth) 4 × 10 mm² (neutral)

Materials

Parameter	Specification
Enclosure material	Back part: technoplastic Door: technoplastic Front face: technoplastic

Colour

Parameter	Specification
Door	White (RAL 9003)
Front face	White (RAL 9003)

Market Segment

Parameter	Specification
Market segment	Residential Small commercial

Environment

Parameter	Specification
Standards	IEC 60670-1 IEC 60670-24
Quality labels	IMQ
Fire resistance	Door: 650 °C Back part: 650 °C Front face: 650 °C
IP degree of protection	IP40
IK degree of protection	IK07
Ambient air temperature for operation	−25…60 °C

Packing Units

Package	Details
Package 1	Unit type: PCE Units: 1 Height: 10.0 cm Width: 19.5 cm Length: 23.0 cm Weight: 636 g

In stock

Receives in 5 days.

Schneider EZ9F56110 Mini Circuit Breaker EASY9 MCB 1P 10A C 6000A 230V MINIATURE

PCWORX

Schneider EZ9F56110 Mini Circuit Breaker EASY9 MCB 1P 10A C 6000A 230V MINIATURE

(0)

₱168.00

DESCRIPTIONS

This Easy9 product is a low voltage miniature circuit breaker (MCB). It is a 1P circuit breaker with 1 protected pole and 10A In rated current and C tripping curve. The rated short circuit breaking capacity goes up to 6000A at 230VAC conforming to IEC 60898-1 standard. It is compliant with IEC 60898-1 standard. This product has a protection against short circuit and a protection of cable against overloads. It has a fault tripping indication on the front panel by the position of the handle (O-I engraved). This product is dedicated for residential and small commercial buildings. It has an electrical endurance going up to 4000 cycles and a mechanical endurance going up to 10000 cycles. The Ue operational voltage is 230VAC. The Ui rated insulation voltage is 500VAC. The Uimp rated impulse withstand voltage is 4kV. The operating frequency is 50Hz. It can be mounted on DIN rail for modular installation. Its width is 2 pitches of 9mm. The product colour is light grey (RAL7035). The dimensions are (W) 18mm x (H) 81mm x (D) 66.5mm. According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure. The operating temperature is -5°C to 60°C. The storage temperature is -40°C to 85°C.

SPECIFICATIONS

Main
Range	Easy9
Device application	Distribution
Product or component type	Miniature circuit-breaker
Device short name	Easy9 MCB
Poles	1P
Number of protected poles	1
[In] rated current	10:00 AM
network type	AC
Trip unit technology	Thermal-magnetic
Curve code	C
Breaking capacity	6000 A Icn at 230 V AC 50/60 Hz conforming to IEC 60898-1
	10000 A Icn at 127 V AC 50/60 Hz conforming to IEC 60898-1
Suitability for isolation	Yes conforming to IEC 60898-1
Complementary
Network frequency	50 Hz
[Ue] rated operational voltage	230 V AC 50 Hz
	127 V AC 50 Hz
Magnetic tripping limit	5...10 x In
[Ics] rated service breaking capacity	6 kA 100 % x Icn at 230 V AC 50/60 Hz conforming to IEC 60898-1
[Ui] rated insulation voltage	500 V AC 50/60 Hz conforming to IEC 60898-1
[Uimp] rated impulse withstand voltage	4 kV conforming to IEC 60898-1
Contact position indicator	Yes
control type	Toggle
Local signalling	Without
Mounting mode	Clip-on
Mounting support	DIN rail
9 mm pitches	2
Height	81 mm
Width	18 mm
Depth	66.5 mm
Colour	Grey (RAL 7035)
Mechanical durability	10000 cycles
Electrical durability	4000 cycles
Connections - terminals	Tunnel type terminal (top or bottom) 1…25 mm² rigid
	Tunnel type terminal (top or bottom) 1…16 mm² flexible
Tightening torque	2 N.m top or bottom
Environment
Standards	IEC 60898-1
Product certifications	VDE
	CE
IP degree of protection	IP20 conforming to IEC 60529
Pollution degree	2
Tropicalisation	2
Relative humidity	95 % at -5…60 °C
Ambient air temperature for operation	-5…60 °C
Ambient air temperature for storage	-40…85 °C
Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	7.4 cm
Package 1 Width	1.8 cm
Package 1 Length	8.5 cm
Package 1 Weight	102 g
Unit Type of Package 2	BB1
Number of Units in Package 2	12
Package 2 Height	8.2 cm
Package 2 Width	9 cm
Package 2 Length	22.6 cm
Package 2 Weight	1.292 kg
Unit Type of Package 3	S03
Number of Units in Package 3	144
Package 3 Height	30 cm
Package 3 Width	30 cm
Package 3 Length	40 cm
Package 3 Weight	14.688 kg

In stock

Receives in 5 days.

Schneider EZ9F56225 Mini Circuit Breaker Easy9 MCB 2P 25A C 6000A 400V Miniature

PCWORX

Schneider EZ9F56225 Mini Circuit Breaker Easy9 MCB 2P 25A C 6000A 400V Miniature

(0)

₱306.00

Description

This Easy9 product is a low voltage miniature circuit breaker (MCB). It is a 2P circuit breaker with 2 protected poles and 25A In rated current and C tripping curve. The rated short circuit breaking capacity goes up to 10000A at 220VAC conforming to IEC 60898-1 standard. It is compliant with IEC 60898-1 standard. This product has a protection against short circuit and a protection of cable against overloads. It has a fault tripping indication on the front panel by the position of the handle (O-I engraved). This product is dedicated for residential and small commercial buildings. It has an electrical endurance going up to 4000 cycles and a mechanical endurance going up to 10000 cycles. The Ue operational voltage is 220VAC. The Ui rated insulation voltage is 500VAC. The Uimp rated impulse withstand voltage is 4kV. The operating frequency is 50Hz or 60Hz. It can be mounted on DIN rail for modular installation. Its width is 4 pitches of 9mm. The product colour is light grey (RAL7035). The dimensions are (W) 36mm x (H) 81mm x (D) 66.5mm. According to IEC 60529 standard, the degree of protection is IP20 and IP40 in enclosure. The operating temperature is -5°C to 60°C. The storage temperature is -40°C to 85°C.

Specification:

Range:	Easy9
Device application:	Distribution
Product or component type:	Miniature circuit-breaker
Device short name:	Easy9 MCB
Poles:	2P
Number of protected poles:	2
[In] rated current:	25 A
network type:	AC
Trip unit technology:	Thermal-magnetic
Curve code:	C
Breaking capacity:	10000 A Icn at 220 V AC 50/60 Hz conforming to IEC 60898-1
	6000 A Icn at 400 V AC 50/60 Hz conforming to IEC 60898-1
Suitability for isolation:	Yes conforming to IEC 60898-1
Complementary
Network frequency:	50/60 Hz
[Ue] rated operational voltage:	220 V AC 50/60 Hz
	400 V AC 50/60 Hz
Magnetic tripping limit:	5...10 x In
[Ics] rated service breaking capacity:	6 kA 100 % x Icn at 230 V AC 50/60 Hz conforming to IEC 60898-1
[Ui] rated insulation voltage:	500 V AC 50/60 Hz conforming to IEC 60898-1
[Uimp] rated impulse withstand voltage:	4 kV conforming to IEC 60898-1
Contact position indicator:	Yes
Control type:	Toggle
Local signalling:	Without
Mounting mode:	Clip-on
Mounting support:	DIN rail
Mounting support:	9 mm pitches
DIN rail:	4
Height:	81 mm
Width:	36 mm
Depth:	66.5 mm
Colour:	Grey (RAL 7035)
Mechanical durability:	10000 cycles
Electrical durability:	4000 cycles
Connections - terminals:	Tunnel type terminal (top or bottom) 1…25 mm² rigid
	Tunnel type terminal (top or bottom) 1…16 mm² flexible
Tightening torque:	2 N.m top or bottom
Earth-leakage protection:	Without
Environment
Standards:	IEC 60898-1
Product certifications:	CE
IP degree of protection:	IP20 conforming to IEC 60529
Pollution degree:	2
Tropicalisation:	2
Relative humidity:	95 % at -5…60 °C
Ambient air temperature for operation:	-5…60 °C
Ambient air temperature for storage:	-40…85 °C
-40…85 °C:
Packing Units:
Unit Type of Package 1:	PCE
Number of Units in Package 1:	1
Package 1 Height:	7.6 cm
Package 1 Width:	3.6 cm
Package 1 Length:	8.5 cm
Package 1 Weight:	210 g
Unit Type of Package 2:	BB2
Number of Units in Package 2:	6
Package 2 Height:	8.5 cm
Package 2 Width:	9 cm
Package 2 Length:	22 cm
Package 2 Weight:	1368 g

Out of stock

Receives in 5 days.

Schneider EZ9XPE210 Easy9 Comb Busbar 10 End Cap 2P

PCWORX

Schneider EZ9XPE210 Easy9 Comb Busbar 10 End Cap 2P

(0)

₱229.00

In stock

Receives in 5 days.

Schneider EZ9XPH257 Easy9 Comb busbar 2P 57 modules

PCWORX

Schneider EZ9XPH257 Easy9 Comb busbar 2P 57 modules

(0)

₱1,341.48

This Easy9 product is a horizontal comb busbar 57 modules. It is dedicated to 2L installations. It is a set of 1 device. It is suitable for 28 devices (1P+N or 2P). This comb busbar is compatible with Easy9 MCB, RCCB, RCBO and switch products. The total number of modules of 18mm is 57. The Ue rated operational voltage is 230VAC (phase to neutral) and 400VAC (phase to phase). The Ui rated insulation voltage is 500VAC. The operating frequency is 50Hz. Its width is 114 pitches of 9mm. The color is light grey (RAL7035). The degree of protection is IP20. The pollution degree is 3. According to IEC 60695-2-1 standard, the fire resistance is self-extinguishing at 850°C within 30s.

SPECIFICATIONS

Range	Easy9
Product or component type	Comb busbar
Mounting mode	Horizontal
Accessory / separate part category	Connection accessory
Lines description	2L
Length in 18 mm modules	57
Standards	IEC 60439-1 IEC 60664

Complementary
Number of ways	28 ways 2 L
Poles configuration for 1 way	1 x 2P
Connection pitch	18 mm
Connector type	Tooth
Distance between way	36 mm
Insulation	Insulated
Device presentation	Cuttable
Provided equipment	2 end piece
[Ie] rated operational current	63 A at 40 °C
[Ue] rated operational voltage	230 V AC 50 Hz Ph/N 400 V AC 50 Hz Ph/Ph
[Ui] rated insulation voltage	500 V AC conforming to IEC 61439-1
Mounting location	Top on tunnel type terminals
9 mm pitches	114
Width	1000 mm
Colour	Light grey (RAL 7035)
Range compatibility	Easy9 Easy9 XP

Environment
Fire resistance	850 °C ( 30 s ) conforming to IEC 60695-2-1
Pollution degree	2

Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	1.000 cm
Package 1 Width	2.500 cm
Package 1 Length	100.000 cm
Package 1 Weight	300.000 g

Out of stock

Receives in 5 days.

Schneider Flood Light Mureva 100W 4000K IP65 230V IMT47214

PCWORX

Schneider Flood Light Mureva 100W 4000K IP65 230V IMT47214

(0)

₱3,488.75

Mureva LED Floodlight 100 W Specifications

Category	Feature	Specification
Main	Range	Mureva
	Product Type	Floodlight
	Device Application	Warehouses, Parking garages, Residential, Public areas, Secure lighting, Stadiums, Arenas
Complementary	Type of Installation	Outdoor
	Total System Power	100 W
	Light Source	LED
	Rated Operational Voltage [Ue]	230 V AC
	Power Factor	0.9
	Colour Rendering Index	Ra = 80
	Luminous Flux	10,000 lm
	Bulb Lifespan	50,000 h
	Colour Temperature	4000 K
	Colour Tint	Black
	Electrical Insulation Class	Class F
	Beam Angle	110°
	Shape	Rectangular
	Height	288.4 mm
	Width	216.4 mm
	Depth	39.3 mm
	Net Weight	1.95 kg
Environment	Environmental Characteristic	Weatherproof
	IP Degree of Protection	IP65
	IK Degree of Protection	IK05
	Ambient Air Temperature for Operation	-30…45 °C
Packing Units	Unit Type Package 1	PCE
	Number of Units in Package 1	1
	Package 1 Height	6.0 cm
	Package 1 Width	23.5 cm
	Package 1 Length	30.0 cm
	Package 1 Weight	2.058 kg

In stock

Receives in 5 days.

Schneider Flood Light Mureva 100W 6500K IP65 230V IMT47215

PCWORX

Schneider Flood Light Mureva 100W 6500K IP65 230V IMT47215

(0)

₱4,289.00

Out of stock

Receives in 5 days.

Schneider Flood Light Mureva 20W 4000K IP65 230V IMT47208

PCWORX

Schneider Flood Light Mureva 20W 4000K IP65 230V IMT47208

(0)

₱825.72

Mureva LED Floodlight Specifications

Category	Feature	Specification
Main	Range	Mureva
	Product Type	Floodlight
	Device Application	Warehouses, Parking garages, Residential, Public areas, Secure lighting, Stadiums, Arenas
Complementary	Type of Installation	Outdoor
	Total System Power	20 W
	Light Source	LED
	Rated Operational Voltage [Ue]	230 V AC
	Power Factor	0.7
	Colour Rendering Index	Ra = 80
	Luminous Flux	2000 lm
	Bulb Lifespan	50,000 h
	Colour Temperature	4000 K
	Colour Tint	Black
	Electrical Insulation Class	Class F
	Beam Angle	110°
	Shape	Rectangular
	Height	163.4 mm
	Width	121.4 mm
	Depth	26.0 mm
	Net Weight	530 g
Environment	Environmental Characteristic	Weatherproof
	IP Degree of Protection	IP65
	IK Degree of Protection	IK05
	Ambient Air Temperature for Operation	-30…45 °C
Packing Units	Unit Type Package 1	PCE
	Number of Units in Package 1	1
	Package 1 Height	5.0 cm
	Package 1 Width	13.5 cm
	Package 1 Length	17.4 cm
	Package 1 Weight	620 g

Low in stock

Receives in 5 days.

Schneider Flood Light Mureva 20W 6500K IP65 230V IMT47209

PCWORX

Schneider Flood Light Mureva 20W 6500K IP65 230V IMT47209

(0)

₱836.25

Mureva lights, LED Floodlight equipped with the latest Led technology and infrared sensor to offer energy efficiency up to 100 lm/W. High light quality with a luminous flux 5000 lm, color temperature 4000 K and a long lifetime of 50000 h without getting hot. Compact design product with a beam angle of 110 degrees, rectangular shape (height 189,4 mm, width 201,4 mm and depth 26,5 mm) and a weight of 1,06 kg. With a high IP rating IP44, it is suitable to be installed in all types of weather conditions, indoor or outdoor. Easy Installation and mounting thanks to the bracket position. It can be hanged and mounted in all types of walls, or to be used on a Tripod. This LED floodlight is optimized for the most cost sensitive applications, helping to ensure highly competitive system lumen per dollar (W) performance. It addresses the stringent efficacy and reliability standards required for modern lighting applications, well suited for both commercial and residential lighting applications.

Specifications

Range	Mureva
Range of product	Mureva lights
Product or component type	Floodlight
Device application	Ware-houses and parking garages Residential Media device support Public areas Secure lighting Stadiums and arenas

Complementary
Type of installation	Outdoor
Total system power	20 W
Light source	LED
[Ue] rated operational voltage	230 V AC
Power factor	0.7
Colour rendering index	R_a=80
Luminous flux	2000 lm
Bulb lifespan	50000 h
Colour temperature	6500 K
Colour tint	Black
Electrical insulation class	Class F
Beam angle	110 °
Shape	Rectangular
Height	163.4 mm
Width	121.4 mm
Depth	26.0 mm
Net weight	530 g

Environment
Environmental characteristic	Weatherproof
IP degree of protection	IP65
IK degree of protection	IK05
Ambient air temperature for operation	-30…45 °C

Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	5.000 cm
Package 1 Width	13.500 cm
Package 1 Length	17.500 cm
Package 1 Weight	617.000 g

In stock

Receives in 5 days.

Schneider Flood Light Mureva 30W 4000K IP65 230V IMT47210

PCWORX

Schneider Flood Light Mureva 30W 4000K IP65 230V IMT47210

(0)

₱1,300.00

Mureva lights, LED Floodlight equipped with the latest Led technology and infrared sensor to offer energy efficiency up to 100 lm/W. High light quality with a luminous flux 5000 lm, color temperature 6500 K and a long lifetime of 50000 h without getting hot. Compact design product with a beam angle of 110 degrees, rectangular shape (height 189,4 mm, width 201,4 mm and depth 26,5 mm) and a weight of 1,06 kg. With a high IP rating IP44, it is suitable to be installed in all types of weather conditions, indoor or outdoor. Easy Installation and mounting thanks to the bracket position. It can be hanged and mounted in all types of walls, or to be used on a Tripod. This LED floodlight is optimized for the most cost sensitive applications, helping to ensure highly competitive system lumen per dollar (W) performance. It addresses the stringent efficacy and reliability standards required for modern lighting applications, well suited for both commercial and residential lighting applications.

Main Specifications

Parameter	Value
Range	Mureva
Range of product	Mureva lights
Product or component type	Floodlight
Device application	Warehouses and parking garages, Residential, Public areas, Secure lighting, Stadiums and arenas

Electrical & Lighting Characteristics

Parameter	Value
Type of installation	Outdoor
Total system power	30 W
Light source	LED
Rated operational voltage $[Ue]$	230 V AC
Power factor	0.9
Colour rendering index (CRI)	Ra = 80
Luminous flux	3000 lm
Colour temperature	4000 K
Bulb lifespan	50,000 h
Beam angle	110°

Mechanical & Design

Parameter	Value
Shape	Rectangular
Colour tint	Black
Electrical insulation class	Class F
Height	189.4 mm
Width	141.4 mm
Depth	26.5 mm
Net weight	780 g

Environmental Specifications

Parameter	Value
Environmental characteristic	Weatherproof
IP degree of protection	IP65
IK degree of protection	IK05
Operating temperature	-30…45 °C

Packing Units

Package 1

Parameter	Value
Unit type	PCE
Units per package	1
Dimensions (H × W × L)	5.5 × 15.5 × 20.0 cm
Weight	775 g

Low in stock

Receives in 5 days.

Schneider Flood Light Mureva 30W 6500K IP65 230V IMT47211

PCWORX

Schneider Flood Light Mureva 30W 6500K IP65 230V IMT47211

(0)

₱1,300.00

Out of stock

Receives in 5 days.

Schneider Flood Light Mureva 50W 4000K IP65 230V IMT47212

PCWORX

Schneider Flood Light Mureva 50W 4000K IP65 230V IMT47212

(0)

₱1,832.50

Mureva lights, LED Floodlight equipped with the latest Led technology to offer energy efficiency up to 100 lm/W. High light quality with a luminous flux 15000 lm, color temperature 6500 K and a long lifetime of 50000 h without getting hot. Compact design product with a beam angle of 110 degrees, rectangular shape (height 342 mm, width 278 mm and depth 61 mm) and a weight of 4,05 kg. With a high IP rating IP65, it is suitable to be installed in all types of weather conditions, indoor or outdoor. Easy Installation and mounting thanks to the bracket position. It can be hanged and mounted in all types of walls, or to be used on a Tripod. This LED floodlight is optimized for the most cost sensitive applications, helping to ensure highly competitive system lumen per dollar (W) performance. It addresses the stringent efficacy and reliability standards required for modern lighting applications, well suited for both commercial and residential lighting applications.

Main Specifications

Parameter	Value
Range	Mureva
Range of product	Mureva lights
Product or component type	Floodlight
Device application	Warehouses and parking garages, Residential, Public areas, Secure lighting, Stadiums and arenas

Electrical & Lighting Characteristics

Parameter	Value
Type of installation	Outdoor
Total system power	50 W
Light source	LED
Rated operational voltage $[Ue]$	230 V AC
Power factor	0.9
Colour rendering index (CRI)	Ra = 80
Luminous flux	5000 lm
Colour temperature	4000 K
Bulb lifespan	50,000 h
Beam angle	110°

Mechanical & Design

Parameter	Value
Shape	Rectangular
Colour tint	Black
Electrical insulation class	Class F
Height	215.4 mm
Width	161.4 mm
Depth	31.0 mm
Net weight	1.02 kg

Environmental Specifications

Parameter	Value
Environmental characteristic	Weatherproof
IP degree of protection	IP65
IK degree of protection	IK05
Operating temperature	-30…45 °C

Packing Units

Package 1

Parameter	Value
Unit type	PCE
Units per package	1
Dimensions (H × W × L)	22.5 × 22.5 × 22.5 cm
Weight	1.15 kg

In stock

Receives in 5 days.

Schneider Flood Light Mureva 50W 6500K IP65 230V IMT47213

PCWORX

Schneider Flood Light Mureva 50W 6500K IP65 230V IMT47213

(0)

₱2,303.00

Category	Attribute	Specification
Main	Range	Mureva
	Range of Product	Mureva lights
	Product / Component Type	Floodlight
	Device Application	Warehouses and parking garages, Residential, Media device support, Public areas, Secure lighting, Stadiums and arenas
Complementary	Type of Installation	Outdoor
	Total System Power	50 W
	Light Source	LED
	Rated Operational Voltage [Ue]	230 V AC
	Power Factor	0.9
	Colour Rendering Index (CRI)	Ra = 80
	Luminous Flux	5000 lm
	Bulb Lifespan	50000 h
	Colour Temperature	6500 K
	Colour Tint	Black
	Electrical Insulation Class	Class F
	Beam Angle	110°
	Shape	Rectangular
	Height	215.4 mm
	Width	161.4 mm
	Depth	31.0 mm
	Net Weight	1.02 kg
Environment	Environmental Characteristic	Weatherproof
	IP Degree of Protection	IP65
	IK Degree of Protection	IK05
	Ambient Air Temperature (Operation)	-30…45 °C
Packing Units	Unit Type of Package 1	PCE
	Number of Units in Package 1	1
	Package 1 Dimensions (H × W × L)	4.8 × 17 × 22.5 cm
	Package 1 Weight	1.15 kg

In stock

Receives in 5 days.

Schneider HOM2100 MINIATURE CIRCUIT BREAKER 120/240V 100A

PCWORX

Schneider HOM2100 MINIATURE CIRCUIT BREAKER 120/240V 100A

(0)

₱1,618.68

Homeline miniature circuit breakers are engineered and designed for fast installation and superior circuit protection. Homeline circuit breakers are designed to plug into Homeline load centers to provide circuit protection. This circuit breaker provides standard circuit protection and is HACR rated. This 2 pole circuit breaker with plug in mounting is rated 100A at 120/240 VAC. HOM breakers provide 10 kA breaking capacity. The electrical connections are box lugs that will accept 1 wires. The box lugs will accept a wire range of 4 AWG to 2/0 AWG copper or aluminum wire. This circuit breaker has a height of 3.13 inches, a width of 2.0 inch and depth of 2.98 inches. HOM Homeline miniature circuit breakers are UL Listed.

Category	Attribute	Value
Main	Product	Miniature circuit-breaker
	Range	Homeline
	Current Rating	100 A
	Certifications	UL listed
	Voltage Rating	120/240 V AC
	Mounting Type	Plug-in
	Number of Poles	2P
	Short Circuit Current Rating	10 kA
	Number of Spaces	2
	Circuit Breaker Type	Standard
	Ratings	HACR rated
	Electrical Connection	Box lugs
	Wire Size	1 × AWG 4…AWG 2/0 (aluminium/copper)
Complementary	Tightening torque	4.8 N·m (AWG 4…2/0 kcmil)
	Height	79.50 mm
	Width	50.8 mm
	Depth	75.69 mm
Environment	Ambient air temperature for operation	40 °C
Packing Units	Unit Type of Package 1	PCE
	Number of Units in Package 1	1
	Package 1 Height	8.636 cm
	Package 1 Width	5.842 cm
	Package 1 Length	9.652 cm
	Package 1 Weight	430.913 g

In stock

Receives in 5 days.

Schneider HOM2150 QOB MINIATURE CIRCUIT BREAKER 120/240V 150A BO 2P

PCWORX

Schneider HOM2150 QOB MINIATURE CIRCUIT BREAKER 120/240V 150A BO 2P

(0)

₱316.68

Homeline miniature circuit breakers are engineered and designed for fast installation and superior circuit protection. Homeline circuit breakers are designed to plug into Homeline load centers to provide circuit protection. This circuit breaker provides standard circuit protection and is HACR rated. This 2 pole circuit breaker with plug in mounting is rated 150 A at 120/240 VAC. HOM breakers provide 10 kA breaking capacity. The electrical connections are box lugs that will accept 1 wires. The box lugs will accept a wire range of 4 AWG to 2/0 AWG copper or aluminum wire. This circuit breaker has a height of 3.13 inches, a width of 2.0 inch and depth of 2.98 inches. HOM Homeline miniature circuit breakers are UL Listed.

Specification:


Product	Miniature circuit-breaker
Range	Homeline
Current Rating	150 A
Certifications	UL listed
Voltage Rating	120/240 V AC
Mounting Type	Plug-in
Number of Poles	4P
Short Circuit Current Rating	10 kA
Number of Spaces	2
Circuit Breaker Type	Standard
Ratings	HACR rated
Electrical Connection	Box lugs
Wire Size	1 x AWG 4...300 kcmil ( aluminium/copper )

Complementary
Tightening torque	4.0 N.m (AWG 4...AWG 2/0)
Height	79.50 mm
Width	50.8 mm
Depth	75.69 mm

Environment
Ambient air temperature for operation	40 °C

Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	9.398 cm
Package 1 Width	8.382 cm
Package 1 Length	10.668 cm
Package 1 Weight	798.322 g

In stock

Receives in 5 days.

Schneider HOM220 MINIATURE CIRCUIT BREAKER 120/240V 20A

PCWORX

Schneider HOM220 MINIATURE CIRCUIT BREAKER 120/240V 20A

(0)

₱669.48

Specification	Detail
Product	Miniature circuit-breaker
Range	Homeline
Current Rating	20 A
Voltage Rating	120/240 V AC
Number of Poles	2P
Mounting Type	Plug-in
Circuit Breaker Type	Standard
Short-Circuit Current Rating	10 kA
Number of Spaces	2
Ratings	HACR rated
Certifications	UL Listed
Electrical Connection	Clamp terminal for 2 cables
Wire Size Compatibility	AWG 14–8 (aluminum/copper)AWG 14–10 (copper only)
Tightening Torque	35.40 lbf·in (4.0 N·m)AWG 16–14 (2.5–10 mm²)AWG 12–4 (4–20 mm²)
Height	3.13 in (79.50 mm)
Width	2.00 in (50.80 mm)
Depth	2.98 in (75.69 mm)
Ambient Air Temperature (Operation)	104 °F (40 °C)
Category	00046 – HOM/T 15–30A 1P; 15–60A 2P
Discount Schedule	DE3D
GTIN	00785901065289
Units per Package	1
Package Weight	1 lb (0.45 kg)
Returnability	Yes
Country of Origin	Mexico
Sustainable Offer Status	Green Premium product
REACh Regulation	REACh Declaration
REACh Free of SVHC	Yes
EU RoHS Directive	Compliant (RoHS Declaration)
Toxic Heavy Metal Free	Yes
Mercury Free	Yes
RoHS Exemption Information	Yes
China RoHS Regulation	China RoHS DeclarationPro-active China RoHS Declaration
Environmental Disclosure	Product Environmental Profile
Package Type	PCE
Package Dimensions (H × W × L)	2.00 × 3.00 × 3.00 in (5.08 × 7.62 × 7.62 cm)

In stock

Receives in 5 days.

Schneider HOM230 MINIATURE CIRCUIT BREAKER 120/240V 30A

PCWORX

Schneider HOM230 MINIATURE CIRCUIT BREAKER 120/240V 30A

(0)

₱669.48

Homeline miniature circuit breakers are engineered and designed for fast installation and superior circuit protection. Homeline circuit breakers are designed to plug into Homeline load centers to provide circuit protection. This circuit breaker provides standard circuit protection and is HACR rated. This 2 pole circuit breaker with plug in mounting is rated 30A at 120/240 VAC. HOM breakers provide 10 kA breaking capacity. The electrical connection is a clamp terminal that will accept 2 wires. The clamp terminal will accept a wire range of 14 AWG to 8 AWG copper or aluminum wire. This circuit breaker has a height of 3.13 inches, a width of 1.0 inch and depth of 2.98 inches. HOM Homeline miniature circuit breakers are UL Listed.

Category	Attribute	Value
Main	Product	Miniature circuit-breaker
	Range	Homeline
	Current Rating	30 A
	Certifications	UL listed
	Voltage Rating	120/240 V AC
	Mounting Type	Plug-in
	Number of Poles	2P
	Short Circuit Current Rating	10 kA
	Number of Spaces	2
	Circuit Breaker Type	Standard
	Ratings	HACR rated
	Electrical Connection	Clamp terminal for 2 cables
	Wire Size	1 × AWG 14…AWG 8 (aluminium/copper)2 × AWG 14…AWG 10 (copper)
Complementary	Tightening torque	4.0 N·m for 2.5…10 mm² (AWG 16…AWG 14)4.0 N·m for 4…20 mm² (AWG 12…AWG 4)
	Height	79.50 mm
	Width	50.8 mm
	Depth	75.69 mm
Environment	Ambient air temperature for operation	40 °C
Packing Units	Unit Type of Package 1	PCE
	Number of U

Out of stock

Receives in 5 days.

Schneider HOM240 MINIATURE CIRCUIT BREAKER 120/240V 40A

PCWORX

Schneider HOM240 MINIATURE CIRCUIT BREAKER 120/240V 40A

(0)

₱780.36

Homeline miniature circuit breakers are engineered and designed for fast installation and superior circuit protection. Homeline circuit breakers are designed to plug into Homeline load centers to provide circuit protection. This circuit breaker provides standard circuit protection and is HACR rated. This 2 pole circuit breaker with plug in mounting is rated 40A at 120/240 VAC. HOM breakers provide 10 kA breaking capacity. The electrical connections are box lugs. The box lugs will accept a wire range of 8 AWG to 2 AWG copper or aluminum wire. This circuit breaker has a height of 3.13 inches, a width of 2.0 inch and depth of 2.98 inches. HOM Homeline miniature circuit breakers are UL Listed.

Category	Attribute	Value

Main

Product

Miniature circuit-breaker

Main

Range

Homeline

Main

Current Rating

40 A

Main

Certifications

UL listed

Main

Voltage Rating

120/240 V AC

Main

Mounting Type

Plug-in

Main

Number of Poles

2P

Main

Short Circuit Current Rating

10 kA

Main

Number of Spaces

2

Main

Circuit Breaker Type

Standard

Main

Ratings

HACR rated

Main

Electrical Connection

Box lugs

Main

Wire Size

1 × AWG 8…AWG 2 (aluminium/copper)

Complementary

Tightening torque

4.6 N·m (AWG 8…AWG 2)

Complementary

Height

79.50 mm

Complementary

Width

50.8 mm

Complementary

Depth

75.69 mm

Environment

Ambient air temperature for operation

40 °C

Packing Units

Unit Type of Package 1

PCE

Packing Units

Number of Units in Package 1

1

Packing Units

Package 1 Height

4.06 cm

Packing Units

Package 1 Width

6.6 cm

Packing Units

Package 1 Length

7.87 cm

Packing Units

Package 1 Weight

317.52 g

Packing Units

Unit Type of Package 2

BB1

Packing Units

Number of Units in Package 2

5

Packing Units

Package 2 Height

8.128 cm

Packing Units

Package 2 Width

6.604 cm

Packing Units

Package 2 Length

25.908 cm

Packing Units

Package 2 Weight

1.624 kg

Packing Units

Unit Type of Package 3

CAR

Packing Units

Number of Units in Package 3

50

Packing Units

Package 3 Height

26.416 cm

Packing Units

Package 3 Width

17.526 cm

Packing Units

Package 3 Length

42.164 cm

Packing Units

Package 3 Weight

16.624 kg

In stock

Receives in 5 days.

Schneider HOM250 MINIATURE CIRCUIT BREAKER 120/240V 50A

PCWORX

Schneider HOM250 MINIATURE CIRCUIT BREAKER 120/240V 50A

(0)

₱780.36

Homeline miniature circuit breakers are engineered and designed for fast installation and superior circuit protection. Homeline circuit breakers are designed to plug into Homeline load centers to provide circuit protection. This circuit breaker provides standard circuit protection and is HACR rated. This 2 pole circuit breaker with plug in mounting is rated 50A at 120/240 VAC. HOM breakers provide 10 kA breaking capacity. The electrical connections are box lugs that will accept 1 wires. The box lugs will accept a wire range of 8 AWG to 2 AWG copper or aluminum wire. This circuit breaker has a height of 3.13 inches, a width of 2.0 inch and depth of 2.98 inches. HOM Homeline miniature circuit breakers are UL Listed.

Category	Specification	Detail
Main	Product	Miniature circuit-breaker
Main	Range	Homeline
Main	Current Rating	50 A
Main	Voltage Rating	120/240 V AC
Main	Number of Poles	2P
Main	Mounting Type	Plug-in
Main	Circuit Breaker Type	Standard
Main	Short-Circuit Current Rating	10 kA
Main	Number of Spaces	2
Main	Ratings	HACR rated
Main	Certifications	UL Listed
Main	Electrical Connection	Box lugs
Main	Wire Size	1 × AWG 8…AWG 2 (aluminum/copper)
Complementary	Tightening Torque	4.6 N·m (AWG 8…AWG 2)
Complementary	Height	79.50 mm (3.13 in)
Complementary	Width	50.8 mm (2.0 in)
Complementary	Depth	75.69 mm (2.98 in)
Environment	Ambient Air Temperature (Operation)	40 °C
Packing Units	Unit Type of Package 1	PCE
Packing Units	Units per Package 1	1
Packing Units	Package 1 Dimensions (H × W × L)	5.080 × 7.620 × 7.874 cm
Packing Units	Package 1 Weight	317.514 g

In stock

Receives in 5 days.

Schneider HOM260 MINIATURE CIRCUIT BREAKER 120/240V 60A

PCWORX

Schneider HOM260 MINIATURE CIRCUIT BREAKER 120/240V 60A

(0)

₱780.36

Homeline miniature circuit breakers are engineered and designed for fast installation and superior circuit protection. Homeline circuit breakers are designed to plug into Homeline load centers to provide circuit protection. This circuit breaker provides standard circuit protection and is HACR rated. This 2 pole circuit breaker with plug in mounting is rated 60A at 120/240 VAC. HOM breakers provide 10 kA breaking capacity. The electrical connection is a clamp terminal that will accept 1 wires. The box lugs will accept a wire range of 8 AWG to 2 AWG copper or aluminum wire. This circuit breaker has a height of 3.13 inches, a width of 2.0 inch and depth of 2.98 inches. HOM Homeline miniature circuit breakers are UL Listed.

Category	Attribute	Value
Main	Product	Miniature circuit-breaker
Main	Range	Homeline
Main	Current Rating	60 A
Main	Certifications	UL listed
Main	Voltage Rating	120/240 V AC
Main	Mounting Type	Plug-in
Main	Number of Poles	2P
Main	Short Circuit Current Rating	10 kA
Main	Number of Spaces	2
Main	Circuit Breaker Type	Standard
Main	Ratings	HACR rated
Main	Electrical Connection	Box lugs
Main	Wire Size	1 × AWG 8…AWG 2 (aluminium/copper)
Complementary	Tightening torque	4.6 N·m (AWG 8…AWG 2)
Complementary	Height	79.50 mm
Complementary	Width	50.8 mm
Complementary	Depth	75.69 mm
Environment	Ambient air temperature for operation	40 °C
Packing Units	Unit Type of Package 1	PCE
Packing Units	Number of Units in Package 1	1
Packing Units	Package 1 Height	7.950 cm
Packing Units	Package 1 Width	5.080 cm
Packing Units	Package 1 Length	7.620 cm
Packing Units	Package 1 Weight	317.514 g

In stock

Receives in 5 days.

Schneider HOM270 MINIATURE CIRCUIT BREAKER 120/240V 70A

PCWORX

Schneider HOM270 MINIATURE CIRCUIT BREAKER 120/240V 70A

(0)

₱1,371.72

Homeline miniature circuit breakers are engineered and designed for fast installation and superior circuit protection. Homeline circuit breakers are designed to plug into Homeline load centers to provide circuit protection. This circuit breaker provides standard circuit protection and is HACR rated. This 2 pole circuit breaker with plug in mounting is rated 70A at 120/240 VAC. HOM breakers provide 10 kA breaking capacity. The electrical connection is a clamp terminal that will accept 1 wires. The box lugs will accept a wire range of 8 AWG to 2 AWG copper or aluminum wire. This circuit breaker has a height of 3.13 inches, a width of 2.0 inch and depth of 2.98 inches. HOM Homeline miniature circuit breakers are UL Listed.

Category	Attribute	Value
Main	Product	Miniature circuit-breaker
Main	Range	Homeline
Main	Current Rating	70 A
Main	Certifications	UL listed
Main	Voltage Rating	120/240 V AC
Main	Mounting Type	Plug-in
Main	Number of Poles	2P
Main	Short Circuit Current Rating	10 kA
Main	Number of Spaces	2
Main	Circuit Breaker Type	Standard
Main	Ratings	HACR rated
Main	Electrical Connection	Box lugs
Main	Wire Size	1 × AWG 8…AWG 2 (aluminium/copper)
Complementary	Tightening torque	4.6 N·m (AWG 8…AWG 2)
Complementary	Height	79.50 mm
Complementary	Width	50.8 mm
Complementary	Depth	75.69 mm
Environment	Ambient air temperature for operation	40 °C
Packing Units	Unit Type of Package 1	PCE
Packing Units	Number of Units in Package 1	1
Packing Units	Package 1 Height	5.080 cm
Packing Units	Package 1 Width	8.128 cm
Packing Units	Package 1 Length	8.636 cm
Packing Units	Package 1 Weight	331.122 g
Packing Units	Unit Type of Package 2	CAR
Packing Units	Number of Units in Package 2	40
Packing Units	Package 2 Height	7.620 cm
Packing Units	Package 2 Width	37.084 cm
Packing Units	Package 2 Length	54.864 cm
Packing Units	Package 2 Weight	13.585 kg

In stock

Receives in 5 days.

Schneider HOM280 MINIATURE CIRCUIT BREAKER 120/240V 80A

PCWORX

Schneider HOM280 MINIATURE CIRCUIT BREAKER 120/240V 80A

(0)

₱1,618.68

Homeline miniature circuit breakers are engineered and designed for fast installation and superior circuit protection. Homeline circuit breakers are designed to plug into Homeline load centers to provide circuit protection. This circuit breaker provides standard circuit protection and is HACR rated. This 2 pole circuit breaker with plug in mounting is rated 80A at 120/240 VAC. HOM breakers provide 10 kA breaking capacity. The electrical connection is a clamp terminal that will accept 1 wires. The box lugs will accept a wire range of 4 AWG to 2/0 AWG copper or aluminum wire. This circuit breaker has a height of 3.13 inches, a width of 2.0 inch and depth of 2.98 inches. HOM Homeline miniature circuit breakers are UL Listed.

Category	Attribute	Value
Main	Product	Miniature circuit-breaker
Main	Range	Homeline
Main	Current Rating	80 A
Main	Voltage Rating	120/240 V AC
Main	Number of Poles	2P
Main	Mounting Type	Plug-in
Main	Circuit Breaker Type	Standard
Main	Short Circuit Current Rating	10 kA
Main	Number of Spaces	2
Main	Ratings	HACR rated
Main	Certifications	UL Listed
Main	Electrical Connection	Box lugs
Main	Wire Size	1 × AWG 4…AWG 2/0 (aluminium/copper)
Complementary	Tightening Torque	4.8 N·m (AWG 4…2/0 kcmil)
Complementary	Height	79.50 mm
Complementary	Width	50.8 mm
Complementary	Depth	75.69 mm
Environment	Ambient Air Temperature (Operation)	40 °C
Packing Units	Unit Type of Package 1	PCE
Packing Units	Units per Package 1	1
Packing Units	Package 1 Height	5.842 cm
Packing Units	Package 1 Width	8.636 cm
Packing Units	Package 1 Length	9.652 cm
Packing Units	Package 1 Weight	385.553 g (~0.386 kg)

Main

Product

Miniature circuit-breaker

Main

Range

Homeline

Main

Current Rating

80 A

Main

Certifications

UL listed

Main

Voltage Rating

120/240 V AC

Main

Mounting Type

Plug-in

Main

Number of Poles

2P

Main

Short Circuit Current Rating

10 kA

Main

Number of Spaces

2

Main

Circuit Breaker Type

Standard

Main

Ratings

HACR rated

Main

Electrical Connection

Box lugs

Main

Wire Size

1 × AWG 4…AWG 2/0 (aluminium/copper)

Complementary

Tightening torque

4.8 N·m (AWG 4…2/0 kcmil)

Complementary

Height

79.50 mm

Complementary

Width

50.8 mm

Complementary

Depth

75.69 mm

Environment

Ambient air temperature for operation

40 °C

Packing Units

Unit Type of Package 1

PCE

Packing Units

Number of Units in Package 1

1

Packing Units

Package 1 Height

5.842 cm

Packing Units

Package 1 Width

8.636 cm

Packing Units

Package 1 Length

9.652 cm

Packing Units

Package 1 Weight

385.553 g (~0.386 kg)

In stock

Receives in 5 days.

Schneider HOM290 MINIATURE CIRCUIT BREAKER 120/240V 90A

PCWORX

Schneider HOM290 MINIATURE CIRCUIT BREAKER 120/240V 90A

(0)

₱1,618.68

Homeline miniature circuit breakers are engineered and designed for fast installation and superior circuit protection. Homeline circuit breakers are designed to plug into Homeline load centers to provide circuit protection. This circuit breaker provides standard circuit protection and is HACR rated. This 2 pole circuit breaker with plug in mounting is rated 90A at 120/240 VAC. HOM breakers provide 10 kA breaking capacity. The electrical connection is a clamp terminal that will accept 1 wires. The box lugs will accept a wire range of 4 AWG to 2/0 AWG copper or aluminum wire. This circuit breaker has a height of 3.13 inches, a width of 2.0 inch and depth of 2.98 inches. HOM Homeline miniature circuit breakers are UL Listed.

Product	Miniature circuit-breaker
Range	Homeline
Current Rating	90 A
Certifications	UL listed
Voltage Rating	120/240 V AC
Mounting Type	Plug-in
Number of Poles	2P
Short Circuit Current Rating	10 kA
Number of Spaces	2
Circuit Breaker Type	Standard
Ratings	HACR rated
Electrical Connection	Box lugs
Wire Size	1 x AWG 4...AWG 2/0 ( aluminium/copper )

Complementary
Tightening torque	4.8 N.m (AWG 4...2/0 kcmil)
Height	79.50 mm
Width	50.8 mm
Depth	75.69 mm

Environment
Ambient air temperature for operation	40 °C

Packing Units
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	5.842 cm
Package 1 Width	8.636 cm
Package 1 Length	9.652 cm
Package 1 Weight	387.821 g

In stock

Receives in 5 days.

Schneider M3T426_IS_WE Socket 16A 250V Intl Skt 2S sized, WE

PCWORX

Schneider M3T426_IS_WE Socket 16A 250V Intl Skt 2S sized, WE

(0)

₱242.40

Schneider Electric Avatar On socket-outlet M3T426_IS_WE is a complete product in color white. And its rated current is 16A. Its matching mounting box can be recessed into the surface of the wall with flush type. The connection terminals of this socket-outlet are screw terminal. It is 46.6 mm in width, 69.3 mm in height, and 33.85 mm in depth. It reaches IP20 degree of protection too. Being made of polycarbonate material, this socket-outlet is quite reliable and resistant. AvatarOn offers six fashionable, classic appearances, letting your home's details change, just like the changes in your colorful life. Unique, patented technology and exquisite manufacturing ensure comfortable operation, and the easy-mount design allows you to change the faceplates as quickly and easily as you wish.

SPECIFICATIONS

Category	Specification
Product Range	AvatarOn A
Product / Component Type	Socket-outlet
Device Presentation	Complete product
Colour Tint	White
Rated Current	16 A at 250 V AC, 50–60 Hz
Socket Number	1
Clamping Connection Capacity	Solid cables: 2 × 1.5–4 mm²Stranded cables: 2 × 1.5–4 mm²
Connections – Terminals	Screw terminal
Material	Polycarbonate coverPolycarbonate base
Device Mounting	Flush
Width	46.6 mm
Height	69.3 mm
Depth	33.85 mm
Embedding Depth	23.05 mm
IP Degree of Protection	IP20
Max. Operating Ambient Temperature	35 °C
Storage Ambient Temperature	-5 °C to 45 °C
Relative Humidity	0–95 %
Operating Altitude	< 2000 m
Standards	IEC 60884-1
Product Certifications	IEC
Package Unit Type	PCE
Units per Package	1
Package Dimensions (H × W × L)	3.4 × 4.7 × 7.0 cm
Package Weight	53.0 g

In stock

Receives in 5 days.

Schneider M3T_USB_BK Socket 1 port 2.1A USB S sized, BK

PCWORX

Schneider M3T_USB_BK Socket 1 port 2.1A USB S sized, BK

(0)

₱867.72

In stock

Receives in 5 days.

Schneider Mini Circuit Breaker QO 100 A 2P 120/240 V 10 kA Bolt On QOB2100

PCWORX

Schneider Mini Circuit Breaker QO 100 A 2P 120/240 V 10 kA Bolt On QOB2100

(0)

₱938.28

In stock

Receives in 5 days.

Schneider MIP12106 Enclosure MODULAR ENCL MINIPRAGMA 1R 6M SURF FD WI

PCWORX

Schneider MIP12106 Enclosure MODULAR ENCL MINIPRAGMA 1R 6M SURF FD WI

(0)

₱831.60

This Resi9 MP enclosure is a surface mounted modular enclosure. This plastic enclosure is composed of 1 row of 6 modules of 18mm. It can accommodate all types of modular switchgear. The IP degree of protection is IP40. It is provided with a plain white door. The color of the front face is white (RAL 9003). It is intended for new or renovated installation in residential. It is equipped with 35 mm asymmetrical rail. It comes with 1 earth and 1 neutral terminal blocks with screwed connection terminals. The earth terminal block provides 4 outgoers (1x16mm² + 2x10mm² + 1x6mm²). The neutral one provides 4 outgoers (1x16mm² + 2x10mm² + 1x6mm²). The In rated current is up to 63A. It complies with IEC 60439-1 and 3, IEC 60670-1 and 24 standards. The total dimensions are (W) 160mm x (H) 198mm x (D) 95mm. The enclosure is made from techno plastic (back part and front face). The door is made from techno plastic. The resistance of the plastic to flames and to abnormal heat is 650°C for the door, the back part and the front face. The IK degree of protection is IK07. The operating temperature is -25°C to 60°C.

SPECIFICATIONS

Range	Resi9
product name	Resi9 MP
Product or component typed	Enclosure
Enclosure type	Modular enclosure
Nb of 18 mm modules per row	6
Nb of horizontal rows	1
Type of door	Plain
Width	Outside: 160 mm
Height	Outside: 198 mm
Depth	Outside : 95 mm
Complementary
Enclosure mounting	Surface
9 mm pitches	12
Total number of 18 mm modules	6
[In] rated current	63 A
Type of rail	35 mm asymmetrical rail
Mounting plate description	Without mounting plate
cable entry	1 trunking flange
	1 bare flange
Terminal block function	Earth / neutral
Number of terminal blocks	1 earth (screwed) with 4 outgoers
	1 neutral (screwed) with 4 outgoers
Distribution block outgoers	1 x 16 mm² for earth
	1 x 16 mm² for neutral
	1 x 6 mm² for earth
	1 x 6 mm² for neutral
	2 x 10 mm² for earth
	2 x 10 mm² for neutral
Enclosure material	Back part: techno plastic
	Door: techno plastic
	Front face: techno plastic
Internal depth	74 mm
Color	Door: white (RAL 9003)
	Front face: white (RAL 9003)
Market segment	small commercial
	residential

In stock

Receives in 5 days.

Main menu

Product comparison

Main menu

MAXIMIZEBF

Explore Related Collections
