Archer BE230 New BE3600 Dual-Band Wi-Fi 7 Router
3.6 Gbps Dual-Band WiFi 7: Enables your devices to run at full speed. Enjoy fluent 4K/8K streaming, immersive AR/VR gaming, and blazing-fast downloads.
2× 2.5G Ports: 1× 2.5 Gbps WAN port, 1× 2.5 Gbps LAN port and 3× 1 Gbps LAN ports offer high-speed data transmissions.
Maximized Coverage: 4× external antennas along with Beamforming deliver more capacity, stronger and more reliable connections, and less interference.
EasyMesh-Compatible: Works with EasyMesh routers and range extenders to form seamless whole home Mesh WiFi, preventing drops and lag when moving between signals.
Easy Setup and Use: Network management has never been easier with the Tether app.
TP-Link HomeShield: Enhanced security defends against the latest cyber threats.
Great Compatibility: Supports all Wi-Fi generations and devices**and all internet providers.
WIRELESS
WiFi Speeds
BE3600
• 5 GHz: 2882 Mbps (802.11be)
• 2.4 GHz: 688 Mbps (802.11be)
WiFi Range
3 Bedroom Houses
4× External Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas
Beamforming
Concentrates wireless signal strength towards clients to expand WiFi range
WiFi Capacity
High
Dual-Band
Allocate devices to different bands for optimal performance
2×2 MU-MIMO
Simultaneously communicates with multiple MU-MIMO clients
OFDMA
Simultaneously communicates with multiple clients
Airtime Fairness
Improves network efficiency by limiting excessive occupation
DFS
Access an extra band to reduce congestion
4 Streams
Connect your devices to more bandwidth
Advanced Functions
• Multi-Link Operation (MLO)
• 4K-QAM
• Multi-RUs
• EasyMesh-Compatible
• Works with Alexa and Google Assistant
• IoT Network
Wireless Mode
• Router Mode
• Access Point Mode
SECURITY
Network Security
• SPI Firewall
• Access Control
• IP & MAC Binding
• Application Layer Gateway
• HomeShield Security
Real-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network Scanner
Guest Network
• 1× 5 GHz Guest Network
• 1× 2.4 GHz Guest Network
VPN Server
• OpenVPN Server
• PPTP VPN Server
• L2TP VPN Server
• WireGuard VPN Server
VPN Client
• Open VPN Client
• PPTP VPN Client
• L2TP VPN Client
• WireGuard VPN Client
WiFi Encryption
• WPA
• WPA2
• WPA3
• WPA/WPA2-Enterprise (802.1x)
HARDWARE
Ethernet Ports
• 1× 2.5 Gbps WAN
• 1× 2.5 Gbps LAN
• 3× 1 Gbps LAN
USB Support
1× USB 3.0
• Supported Partition Formats:
NTFS, exFAT, HFS+, FAT32
• Supported Functions:
FTP Server
Media Server
Samba Server
Buttons
• Power On/Off Button
• Wi-Fi On/Off Button
• LED Button
• WPS Button
• Reset Button
Power
12 V ? 2 A (US)
12 V ? 1.5 A (EU)
SOFTWARE
Protocol
• IPv4
• IPv6
Service Kit
HomeShield
EasyMesh
Compatible with EasyMesh
Parental Controls
HomeShield Parental Controls
Custom Profiles
Professional Content Filter Library
Family Time
Bedtime
Off Time
Time Rewards
Family Online Time Ranking
Pause the Internet
Weekly and Monthly Reports
WAN Type
• Dynamic IP
• Static IP
• PPPoE
• PPTP
• L2TP
Quality of Service
QoS by Device
Cloud Service
• Auto Firmware Upgrade
• TP-Link ID
• DDNS
NAT Forwarding
• Port Forwarding
• Port Triggering
• DMZ
• UPnP
IPTV
• IGMP Proxy
• IGMP Snooping
• Bridge
• Tag VLAN
DHCP
• Address Reservation
• DHCP Client List
• Server
DDNS
• TP-Link
• NO-IP
• DynDNS
Management
• Tether App
• Webpage
OTHER
System Requirements
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Cable or DSL Modem (if needed)
Subscription with an internet service provider (for internet access)
Certifications CE, FCC, RoHS
Environment
• Operating Temperature: 0?~40? (32? ~104?)
• Operating Humidity: 10%~90% non-condensing
APARTMENT WI-FI. PALM-SIZED.
DOUBLING BANDWIDTH WITH DUAL BAND
AC Dual-band WiFi allows you to connect your demanding devices to the faster and clearer 5 GHz band, while a tradition 2.4 GHz
band provides a far-reaching, stable connection to the rest of your devices.
STABLE AND FAR-REACHING
Featuring 4× diagonally-distributed antennas, Archer C24 cover more direction and expand the WiFi coverage,
supporting buffer-free surfing and stalling-free downloading.
VERSATILE MANAGEMENT
Easily manage your home network with versatile built-in tools, including Parental Controls, Guest Network, QoS, and more.
ROUTER MODE (DEFAULT)
Plug in an Ethernet cable to instantly create a private wireless network and share internet access with all your Wi-Fi devices.
ACCESS POINT MODE
Transform your existing wired network into a wireless one.
RANGE EXTENDER MODE
Boost the existing wireless coverage in your house.
HIGH INTEGRATION, COMPACT SIZE
Archer C24's system structure focuses on creating optimal WiFi. The advanced semiconductor technology helps integrate units including CPU, memory, and a 3-stream processing unit onto a single chip to achieve high compatibility, bringing you the same power with a compact design.
AS STABLE AS A LARGER ONE
Archer C24 goes through rigorous repeated testing to ensure a final product reliable under a number of strenuous environments. The final result: 8 randomly selected Archer C24 routers collectively tested for 1,936 hours.
EASY SETUP AT YOUR FINGERTIPS
Set up Archer C24 in minutes via its intuitive web interface or the powerful Tether app. Tether also lets you manage its network settings from any Android or iOS device.
TECHNICAL SPECIFICATION
WIRELESS
Standards
Wi-Fi 5
IEEE 802.11ac/n/a 5 GHz
IEEE 802.11n/b/g 2.4 GHz
WiFi Speeds
AC750
5 GHz: 433 Mbps (802.11ac)
2.4 GHz: 300 Mbps (802.11n)
WiFi Range
2 Bedroom Houses
4× Fixed Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas
WiFi Capacity
Medium
Dual-Band
Allocate devices to different bands for optimal performance
Working Modes
Router Mode
Access Point Mode
Range Extender Mode
HARDWARE
Processor
Single-Core CPU
Ethernet Ports
1× 10/100 Mbps WAN Port
4× 10/100 Mbps LAN Ports
Buttons
WPS/Reset Button
Power
9 V ⎓ 0.6 A
SECURITY
WiFi Encryption
WEP
WPA
WPA2
WPA/WPA2-Enterprise (802.1x)
Network Security
SPI Firewall
Access Control
IP & MAC Binding
Application Layer Gateway
Guest Network
1× 5 GHz Guest Network
1× 2.4 GHz Guest Network
SOFTWARE
Protocols
IPv4
IPv6
Parental Controls
URL Filtering
Time Controls
WAN Types
Dynamic IP
Static IP
PPPoE
PPTP
L2TP
Quality of Service
QoS by Device
NAT Forwarding
Port Forwarding
Port Triggering
DMZ
UPnP
IPTV
IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN
DHCP
Address Reservation
DHCP Client List
Server
DDNS
NO-IP
DynDNS
Management
Tether App
Webpage
Check Web Emulator>
PHYSICAL
Dimensions (W×D×H)
4.5 × 4.2 × 1.0 in
(115 × 106.7 × 24.3 mm)
Package Contents
Wi-Fi Router Archer C24
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
OTHER
System Requirements
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Cable or DSL Modem (if needed)
Subscription with an internet service provider (for internet access)
Certifications
FCC, CE, RoHS
Environment
Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~60℃ (-40℉ ~140℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
TEST DATA
WiFi Transmission Power
CE:
<20dBm(2.4GHz)
<23dBm(5GHz)
WiFi Reception Sensitivity
5GHz:
11a 54M: -76dBm;
11ac VHT20 MCS8: -71dBm;
11ac VHT40 MCS9: -66dBm;
11ac VHT80 MCS9: -62dBm
2.4GHz:
11g 54M: -76dBm;
11n HT20 MCS7: -73dBm;
11n HT40 MCS7: -71dBm
Faster AC Wi-Fi—AC1200 dual-band is ideal for 4K video streaming and high-speed downloading.
Far-Reaching Coverage—4× antennas and Beamforming delivers extensive Wi-Fi coverage and reliable connections.
Multi-Mode 3-in-1—Supports Router, Access Point, and Range Extender modes for added flexibility.
Parental Controls—Manages when and how connected devices can access the internet.
Guest Network—Provides separate access for guests in order to secure the host network.
Smooth HD Streaming—Supports IGMP Proxy/Snooping, Bridge, and Tag VLAN to optimize IPTV streaming.
IPv6 Supported—Compatible with the IPv6 (the latest Internet Protocol version 6).
Compact and Mountable—Designed to conserve space and complement any décor.
SECURITY - Archer C54
Network Security
SPI FirewallAccess ControlIP & MAC BindingApplication Layer Gateway
Guest Network
1× 5 GHz Guest Network1× 2.4 GHz Guest Network
WiFi Encryption
WEPWPAWPA2WPA/WPA2-Enterprise (802.1x)
WIRELESS
Standards
Wi-Fi 5IEEE 802.11ac/n/a 5 GHzIEEE 802.11n/b/g 2.4 GHz
WiFi Speeds
AC12005 GHz: 867 Mbps (802.11ac)2.4 GHz: 300 Mbps (802.11n)
WiFi Range
3 Bedroom Houses4× Fixed AntennasMultiple antennas form a signal-boosting array to cover more directions and large areasBeamformingConcentrates wireless signal strength towards clients to expand WiFi range
WiFi Capacity
MediumDual-BandAllocate devices to different bands for optimal performanceMU-MIMOSimultaneously communicates with multiple MU-MIMO clients
Working Modes
Router ModeAccess Point ModeRange Extender Mode
HARDWARE
Processor
Single-Core CPU
Ethernet Ports
1× 10/100 Mbps WAN Port4× 10/100 Mbps LAN Ports
Buttons
WPS/Reset Button
Power
9 V ⎓ 0.85 A
SOFTWARE
Protocols
IPv4IPv6
Parental Controls
URL FilteringTime Controls
WAN Types
Dynamic IPStatic IPPPPoEPPTPL2TP
Quality of Service
QoS by Device
NAT Forwarding
Port ForwardingPort TriggeringDMZUPnP
IPTV
IGMP ProxyIGMP SnoopingBridgeTag VLAN
DHCP
Address ReservationDHCP Client ListServer
DDNS
NO-IPDynDNS
Management
Tether AppWebpageCheck Web Emulator>
OTHER
System Requirements
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browserCable or DSL Modem (if needed)Subscription with an internet service provider (for internet access)
Certifications
FCC, CE, RoHS
Environment
Operating Temperature: 0℃~40℃ (32℉ ~104℉)Storage Temperature: -40℃~60℃ (-40℉ ~140℉)Operating Humidity: 10%~90% non-condensingStorage Humidity: 5%~90% non-condensing
TEST DATA
WiFi Transmission Power
CE EIRP:<20dBm(2.4GHz)<23dBm(5GHz)FCC:<30dBm(2.4GHz & 5GHz)
WiFi Reception Sensitivity
5GHz:11a 6Mbps:-93dBm；11a 54Mbps:-78dBm；11ac HT20 mcs8:69dBm;11ac HT40 mcs9:-66dBm;11ac HT80 mcs9:-62dBm;2.4GHz:11g 54Mbps:-78dBm;11n HT20 mcs7:-74dBm;11n HT40 mcs7:-71dbm；
PHYSICAL
Dimensions (W×D×H)
4.5 × 4.2 × 1.0 in(115 × 106.7 × 24.3 mm)
Package Contents
Wi-Fi Router Archer C54Power AdapterRJ45 Ethernet CableQuick Installation Guide
Hardware specifications
Ports:
1 x 10/100Mbps LAN/WAN Port, 1 x 10/100Mbps LAN Port, 1 x Micro SIM Card Slot
Wireless speeds:
Up to 300 Mbps on 2.4 GHz
Antennas:
2 x Detachable external 4G LTE antennas
Buttons:
WPS/Reset button
Dimensions:
6.06 × 4.49 × 1.42 inches (154 × 114 × 36 mm)
Wireless features
Wireless standards:
IEEE 802.11b/g/n
Frequency:
2.4 GHz
Wireless security:
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Network type and software
Network type:
4G FDD-LTE/TDD-LTE and 3G HSPA/UMTS
Operating modes:
3G/4G Router, Wireless Router
Security:
IPv4 SPI Firewall, IP and MAC Address Binding
WAN type:
Dynamic IP/Static IP/PPPoE/PPTP (Dual Access)/L2TP (Dual Access)
Management:
Local and Remote Management, DHCP server, Dynamic DNS
Guest network:
Yes, 2.4 GHz guest network
LTE performance
Download speed:
Up to 150 Mbps
Upload speed:
Up to 50 Mbps
Additional features
Easy setup:
Plug-and-play with no configuration required when using a compatible SIM card
WAN failover:
Allows for a fallback to an Ethernet WAN connection if the 4G connection is lost
SIM card compatibility:
Works with SIM cards from over 100 countries
Network and connectivity
Ports:
1 Gigabit WAN Port, 3 Gigabit WAN/LAN Ports, 1 Gigabit LAN Port
WAN Options:
Supports multiple broadband connections, including a USB WAN port for a 4G/3G modem
Load Balancing:
Distributes data across multiple WAN ports to increase utilization
Networking Standards:
IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
VPN and security
VPN Tunnels:
20 IPsec VPN Tunnels (LAN-to-LAN)
16 OpenVPN Tunnels
16 L2TP VPN Tunnels
16 PPTP VPN Tunnels
Security Features:
Advanced firewall policies, DoS defense, IP/MAC/URL filtering, and IP-MAC binding
Simplified VPN:
One-click auto IPSec VPN function for easier setup
Management
Omada SDN Integration:
Supports centralized management via the Omada SDN Controller and Zero-Touch Provisioning
Management Tools:
Centralized management via cloud access or the Omada app
Designed for Remote Office or Small Office: Supports one of the tunnel type; 20× LAN-to-LAN IPsec, 16× OpenVPN***, 16× L2TP, and 16× PPTP VPN connections.
Reliable and Flexible: Up to 4 WAN connections connecting to 4 different Internet service providers and private links. Bandwidth based, app-based, or automatic line backup allow flexible and reliable use of your wide-area links.**
Gigabit Router: All (5) gigabit connecting ports provide high-speed wired connectivity.
Built-in Firewall: Built-in firewall and ACS filtering for easy penetration and blocking settings
VLAN and VLAN routing: Works with standard 802.1Q switches for multiple subnet separation and communication. Multi-Nets NAT for direct Internet access from any VLAN
Secured Router: Advanced ACS policies, DoS defense, IP/MAC/URL filtering, and more security functions protect your network and data.
Centralized Management**: Work with center control Omada SDN controller enables cloud access for easy management and deployment.
Omada Cloud-based SDN: Zero-Touch Provisioning (ZTP)‡ eliminates the installation and maintenance truckloads.
