5 Gbps Dual-Band WiFi – 4324 Mbps (5 GHz) + 688 Mbps (2.4 GHz).†
2.5 Gbps Wired Connections – 2× 2.5 Gbps ports ensure max flexibility and boosted throughput.§
Wireless and Wired Combined Backhaul – Connects a wireless and wired backhaul with each unit simultaneously to improve overall throughput and reduce latency.
Multi-Link Operation (MLO) – Simultaneously send and receive data across different bands and channels to increase throughput, reduce latency, and improve reliability.△
Seamless AI-Driven Roaming – Forms a unified netwok with built-in AI-Roaming creating the ideal Wi-Fi solution for your home.
TP-Link HomeShield – Provides comprehensive network protection, robust parental controls, and real-time IoT security.*
Universal Compatibility – Backward compatible with all WiFi generations and works with any internet service provider (ISP) and modem.☆
Key specifications
Wireless Connectivity:
Wi-Fi 6 (IEEE 802.11ax) with AX3000 capabilities, including OFDMA and MU-MIMO.
LTE Connectivity:
4G LTE with speeds up to 150Mbps.
Battery:
10,000mAh.
Power Bank Function:
Can be used as a power bank.
Number of Connected Devices:
Supports up to 32 devices simultaneously.
Display:
1.77" TFT color display for monitoring data usage, signal strength, and network status.
Antennas:
Built-in LTE/Wi-Fi antennas for optimal performance.
Frequency:
Supports worldwide 4G LTE bands.
Additional features
Easy to Use:
Plug and play functionality with a SIM card.
Worldwide Coverage:
Openline for use in many countries.
Power Saving:
Long-lasting battery life for extended use on the go.
Network Management:
Web-based UI for easy configuration and remote management.
Advanced Features:
QoS, firewall, and other advanced networking features.
Fast and Stable 100Mbps Wired Network
Easily Read 8TB Hard Drives with Power Supply
Responsive Keyboard and Mouse Connection
Supports Emergency Charging for Phones
Soft Blue Indicator Light for Real-Time Status Feedback
Compatible with Multiple Systems Plug and Play
3-Port Expansion No More Repeated Plugging and Unplugging
Fast Networking Made Easy
With data transfer speeds of up to 200 Mbps at full duplex, these switches are ideal for quick file transfers, online gaming and smooth streaming media. They feature easy-to-access Ethernet ports with LED indicators per port to easily distinguish link status. Auto MDI/MDIX crossover makes connection a cinch; just plug in your cables and you’re ready to go.
Economical, Plug-and-play Networking Switch
The DES-1005C 10/100 Mbps Unmanaged Switch is an economical, plug-and-play networking switch for SOHO and small and medium businesses wanting to benefit from the increased bandwidth of Fast Ethernet. It gives you five 10/100 Mbps ports that enable you to easily expand your network and provide a quick way to upgrade your network to fast connectivity.
Conserve Energy
The DES-1005C implements 802.3az Energy Efficient Ethernet, which saves energy and reduces heat automatically without sacrificing performance or functionality. The switches can detect when a connected computer is shut down or when there is no Ethernet traffic, and will put the port in standby mode, saving a substantial amount of power. In addition, the switch optimizes power usage for each port for the length of cable connected to it, using only as much power as is required. Both of these features work together to help you save power automatically.
Reliable Plug and Play Installation
The DES-1005C is a Plug-and-Play device that requires no configuration, so setup is simple and hassle-free, and you can easily connect multiple computers, share files, music, and video across your home or small office network, or even create a multiplayer gaming environment. 802.3x flow control on each port minimizes dropped packets when the port’s receiving buffer is full, giving you a more reliable connection for all of your connected devices.
Specification
Auto MDI/MDIX:
Yes
Control:
802.3x Flow
Dimensions:
88x48x21.45mm
Energy Efficiency Ethernet (EEE):
Yes
FAN:
Fanless
Head-of-line (HOL) Blocking Prevention:
Yes
Interfaces:
5 x 100Base-TX
Jumbo Frame:
2048 Bytes
MAC Address Table Size:
2,000
Max. Packet Forwarding Rate:
0.74 Mpps
Maximum Heat Dissipation:
0.406 BTU/h
Maximum Power Consumption:
0.784 W
MTBF:
1,785,631 hours
Operating Humidity:
10% ~ 90% RH
Operating Temperature:
0 ~ 40 °C
Packet Buffer Size:
96KBytes
Power Input:
DC: 5V, 0.55A
Power Saving by Link Status:
YES
Standby Power Consumption:
0.4 W
Storage Humidity:
5% ~ 95% RH
Storage Temperature:
- 40 ~ 70 °C
Store & Forwarding Forwarding:
Yes
Switching Capacity:
1 Gbps
Weight:
434 g
RE315
AC1200 Mesh Wi-Fi Range Extender
Eliminate weak signal areas with whole home WiFi coverage.
2.4 GHz (300 Mbps) and 5 GHz (867 Mbps) dual-band Wi-Fi connection ensures more stable wireless experience.
EasyMesh-Compatible - Flexibly creates a Mesh network by connecting to an EasyMesh-compatible router for seamless whole-home coverage
Adaptive Path Selection – connects to the fastest connection path to the router automatically and runs at top-speed.
AP Mode – create a new Wi-Fi access point to enhance your wired network with Wi-Fi capability.
Smart signal indicator helps to find the best location for optimal Wi-Fi coverage by showing the signal strength.
Push the WPS button to easily connect to the router and you can uniformly manage from the Tether app or Web UI.
Works with any Wi-Fi router or wireless access point.
SPECIFICATIONS:
HARDWARE FEATURES
Ports:
1 x 10/100Mbps Ethernet Port (RJ45)
Button:
WPS Button, Reset Button
Input Power:
100-240V~50/60Hz
Power Consumption:
9.5W（max power consumption）
Dimensions (W x D x H):
3.5×1.4×4.9 in. (89×35.0×124.1 mm)
Antenna:
2 External Antennas
WIRELESS FEATURES
Wireless Standards:
IEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n 2.4 GHz
Frequency:
2.4GHz and 5GHz
Signal Rate:
300Mbps at 2.4GHz, 867Mbps at 5GHz
Working Modes:
Range Extender/Access Point
Reception:
5 GHz:
11a 6Mbps: -94dBm
11a 54Mbps: -77dBm
11ac HT20 MCS0: -94dBm
11ac HT20 MCS8: -71dBm
11ac HT40 MCS0: -92dBm
11ac HT40 MCS9: -66dBm
11ac HT80 MCS0: -87dBm
11ac HT80 MCS9: -62dBm
2.4 GHz:
11g 54Mbps: -78dBm
11n HT20 MCS7: -76dBm
11n HT40 MCS7: -74dBm
Wireless Functions:
Enable/Disable Wireless Radio
DFS (the latest firmware and hardware version is required)
Access Control
LED Control
Power Schedule
Wi-Fi Coverage
Wireless Security:
64/128-bit WEP, WPA/WPA2-PSK/WPA2-PSK2 encryptions
Transmission Power:
2.4 GHz ≤20dBm, 5 GHz ≤30dBm
OTHERS
Certification:
CE, RoHS
Package Contents:
Wi-Fi Range Extender RE315
Quick Installation Guide
System Requirements:
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or another Java-enabled browser
Environment:
Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
AX3000 Wi-Fi 6 Smart Mesh Router M30
Dual-Band AX3000 Wi-Fi 6
Ultra-Fast Connectivity – Speeds up to 3 Gbps with an extra antenna on the faster 5 GHz band
Uninterrupted Wi-Fi Everywhere – Advanced antenna design offers 360° spherical coverage plus advanced AI technology
Scale-as-you-need Mesh – Create a robust mesh network with other AQUILA PRO AI routers and extenders
Multi-Gigabit Wired Connections – 1× Gigabit WAN port + 4× Gigabit LAN ports
Help Protect Your Home Network – Advanced parental controls, IoT cybersecurity certification and WPA3 encryption
Easy Setup and Management – The intuitive AQUILA PRO AI app guides you through setup step-by-step
Refined Aesthetics – Boasting an eagle-inspired form and a unique feather-patterned ventilation design
Eco-friendly Design – Made with Post-Consumer Recycled case and packed in recyclable packaging
Specifications:
Antenna:
5 x internal dual band antennas
Certifications:
CE
FCC
IC
Device Management:
AQUILA PRO AI app (iOS and android)
Web UI
Dimensions:
181.6 x 129. 2 x 661.1 mm (7.15 x 5.0 x 2.60 in)
Firewall:
1 x DMZ
Anti- spoofing checking
DoS
IP/MAC Address Filtering
Stateful Packet Inspection
Interfaces:
1 x Gigabit Ethernet WAN port
1 x power connector
1 x power on/off button
1 x WPS button
4 x Gigabit Ethernet LAN port
LED Status Indicators:
Power/Status
Maximum Power Consumption:
14.54W
Memory:
128MB Flash
512MB RAM
Operating Temperature:
0 to 40 °C (32 to 104 °F)
Power Input:
12V
1A
Security Protocol:
WPA/WPA2-Personal
WPA2/WPA3- Personal (WPS Not supported)
WPA2- Personal
WPA3 Only (WPS Not supported)
Voice Assistant:
Amazon Alexa
Google Assistant
Weight:
295g (0.65 lb)
Wireless Standard:
IEEE 802.11ax/ac/n/g/b/k/w/a/h IEEE 802.3U/ab
Wi-Fi Data Rate:
2.4 GHz Up to1200 Mbps
5 GHz Up to 1800 Mbps
