Core Specifications Cores:  6 Threads:  12 Base Clock:  3.6 GHz Max Boost Clock:  Up to 4.2 GHz L1 Cache:  384KB L2 Cache:  3MB L3 Cache:  16MB Total Cache:  19MB (384KB + 3MB + 16MB) TDP:  65W  Platform and Connectivity Socket:  AM4 Architecture:  Zen 3 PCI Express Version:  PCIe 3.0 Max Memory Speed:  DDR4-3200 Number of Memory Channels: 2 Other Features Integrated Graphics:  No, a discrete GPU is required Unlocked for Overclocking:  Yes Thermal Solution:  AMD Wraith Stealth cooler included Supported Chipsets:  X570, X470, X370, B550, B450, B350, A520 OS Support:  Windows 11, 64-Bit Edition; Windows 10, 64-Bit Edition; RHEL x86 64-Bit; Ubuntu x86 64-Bit

Read more less

Supports AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series and Ryzen™ 3000 and Ryzen™ 3000 G-Series Processors Dual Channel ECC/ Non-ECC Unbuffered DDR4, 2 DIMMs PCIe Gen3 x4 M.2 with PCIe NVMe & SATA mode support GbE LAN with Bandwidth Management 8-Channel HD Audio with High Quality Audio Capacitors Rear HDMI and D-sub for Multi-display Support Smart Fan 5 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP GIGABYTE APP Center, Simple and Easy Use SPECIFICATION CPU AMD Socket AM4, support for: AMD Ryzen™ 5000 G-Series Processors/ AMD Ryzen™ 5000 Series Processors/ AMD Ryzen™ 4000 G-Series Processors/ AMD Ryzen™ 3000 and Ryzen™ 3000 G-Series Processors (Please refer "CPU Support List" for more information.) Chipset AMD A520 Memory 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory Support for DDR4 5100(O.C.) / 4800(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules (Please refer "Memory Support List" for more information.) Onboard Graphics Integrated Graphics Processor with AMD Radeon™ Graphics support: 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version, HDCP 2.3, and HDR. Maximum shared memory of 16 GB Audio Realtek® Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. LAN Realtek® GbE LAN chip (1 Gbps/100 Mbps) Expansion Slots CPU: 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16 Chipset: 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 Storage Interface CPU: 1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 3.0 x4/x2 SSD support) Chipset: 4 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, and RAID 10 USB CPU: 4 x USB 3.2 Gen 1 ports on the back panel Chipset: 2 x USB 3.2 Gen 1 ports available through the internal USB header 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers) Internal I/O Connectors 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 1 x system fan header 1 x M.2 Socket 3 connector 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only) 1 x speaker header 1 x Clear CMOS jumper 1 x chassis intrusion header Back Panel Connectors 1 x PS/2 keyboard/mouse port 1 x D-Sub port 1 x HDMI port 4 x USB 3.2 Gen 1 ports 2 x USB 2.0/1.1 ports 1 x RJ-45 port 3 x audio jacks I/O Controller iTE® I/O Controller Chip H/W Monitoring Voltage detection Temperature detection Fan speed detection Fan fail warning Fan speed control * Whether the fan speed control function is supported will depend on the cooler you install. BIOS 1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. @BIOS EasyTune Smart Backup System Information Viewer Support for Q-Flash Operating System Support for Windows 11 64-bit Support for Windows 10 64-bit Form Factor Micro ATX Form Factor; 23.3cm x 19.8cm

Read more less

Essentials Product Collection Intel® Core™ i9 Processors (14th gen) Code Name Products formerly Raptor Lake Vertical Segment Desktop Processor Number i9-14900K Lithography Intel 7 CPU Specifications Total Cores 24 # of Performance-cores 8 # of Efficient-cores 16 Total Threads 32 Max Turbo Frequency 6 GHz Intel® Thermal Velocity Boost Frequency 6 GHz Intel® Turbo Boost Max Technology 3.0 Frequency ‡ 5.8 GHz Performance-core Max Turbo Frequency 5.6 GHz Efficient-core Max Turbo Frequency 4.4 GHz Performance-core Base Frequency 3.2 GHz Efficient-core Base Frequency 2.4 GHz Cache 36 MB Intel® Smart Cache Total L2 Cache 32 MB Processor Base Power 125 W Maximum Turbo Power 253 W Supplemental Information Marketing Status Launched Launch Date Q4'23 Embedded Options Available No Memory Specifications Max Memory Size (dependent on memory type) 192 GB Memory Types Up to DDR5 5600 MT/s Up to DDR4 3200 MT/s Max # of Memory Channels 2 Max Memory Bandwidth 89.6 GB/s ECC Memory Supported   ‡ Yes GPU Specifications GPU Name‡ Intel® UHD Graphics 770 Graphics Base Frequency 300 MHz Graphics Max Dynamic Frequency 1.65 GHz Graphics Output eDP 1.4b |  DP 1.4a |  HDMI 2.1 Execution Units 32 Max Resolution (HDMI)‡ 4096 x 2160 @ 60Hz Max Resolution (DP)‡ 7680 x 4320 @ 60Hz Max Resolution (eDP - Integrated Flat Panel)‡ 5120 x 3200 @ 120Hz DirectX* Support 12 OpenGL* Support 4.5 OpenCL* Support 3 Multi-Format Codec Engines 2 Intel® Quick Sync Video Yes Intel® Clear Video HD Technology Yes # of Displays Supported ‡ 4 Device ID 0xA780 Expansion Options Direct Media Interface (DMI) Revision 4 Max # of DMI Lanes 8 Scalability 1S Only PCI Express Revision 5.0 and 4.0 PCI Express Configurations ‡ Up to 1x16+4 |  2x8+4 Max # of PCI Express Lanes 20 Package Specifications Sockets Supported FCLGA1700 Max CPU Configuration 1 Thermal Solution Specification PCG 2020A TJUNCTION 100°C Package Size 45.0 mm x 37.5 mm Advanced Technologies Intel® Gaussian & Neural Accelerator 3 Intel® Thread Director Yes Intel® Deep Learning Boost (Intel® DL Boost) on CPU Yes Intel® Speed Shift Technology Yes Intel® Adaptive Boost Technology Yes Intel® Thermal Velocity Boost Yes Intel® Turbo Boost Max Technology 3.0 ‡ Yes Intel® Turbo Boost Technology ‡ 2 Intel® Hyper-Threading Technology ‡ Yes Intel® 64 ‡ Yes Instruction Set 64-bit Instruction Set Extensions Intel® SSE4.1 |  Intel® SSE4.2 |  Intel® AVX2 Idle States Yes Enhanced Intel SpeedStep® Technology Yes Thermal Monitoring Technologies Yes Intel® Volume Management Device (VMD) Yes Security & Reliability Intel® Standard Manageability (ISM) ‡ Yes Intel® Control-Flow Enforcement Technology Yes Intel® AES New Instructions Yes Secure Key Yes Intel® OS Guard Yes Execute Disable Bit ‡ Yes Intel® Boot Guard Yes Mode-based Execute Control (MBEC) Yes Intel® Virtualization Technology (VT-x) ‡ Yes Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes Intel® VT-x with Extended Page Tables (EPT) ‡ Yes

Read more less

Essentials Product Collection 13th Generation Intel® Core™ i5 Processors Code Name Products formerly Raptor Lake Vertical Segment Desktop Processor Number i5-13400 Lithography Intel 7 CPU Specifications Total Cores 10 # of Performance-cores 6 # of Efficient-cores 4 Total Threads 16 Max Turbo Frequency 4.60 GHz Performance-core Max Turbo Frequency 4.60 GHz Efficient-core Max Turbo Frequency 3.30 GHz Performance-core Base Frequency 2.50 GHz Efficient-core Base Frequency 1.80 GHz Cache 20 MB Intel® Smart Cache Total L2 Cache 9.5 MB Processor Base Power 65 W Maximum Turbo Power 148 W Supplemental Information Marketing Status Launched Launch Date Q1'23 Embedded Options Available Yes Datasheet View now Memory Specifications Max Memory Size (dependent on memory type) 192 GB Memory Types Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s Max # of Memory Channels 2 Max Memory Bandwidth 76.8 GB/s GPU Specifications GPU Name‡ Intel® UHD Graphics 730 Graphics Base Frequency 300 MHz Graphics Max Dynamic Frequency 1.55 GHz Graphics Output eDP 1.4b |  DP 1.4a |  HDMI 2.1 Execution Units 24 Max Resolution (HDMI)‡ 4096 x 2160 @ 60Hz Max Resolution (DP)‡ 7680 x 4320 @ 60Hz Max Resolution (eDP - Integrated Flat Panel)‡ 5120 x 3200 @ 120Hz DirectX* Support 12 OpenGL* Support 4.5 OpenCL* Support 3 Multi-Format Codec Engines 1 Intel® Quick Sync Video Yes Intel® Clear Video HD Technology Yes # of Displays Supported ‡ 4 Device ID 0x4682/0xA782 Expansion Options Direct Media Interface (DMI) Revision 4 Max # of DMI Lanes 8 Scalability 1S Only PCI Express Revision 5.0 and 4.0 PCI Express Configurations ‡ Up to 1x16+4 |  2x8+4 Max # of PCI Express Lanes 20 Package Specifications Sockets Supported FCLGA1700 Max CPU Configuration 1 Thermal Solution Specification PCG 2020C TJUNCTION 100°C Package Size 45.0 mm x 37.5 mm Advanced Technologies Intel® Gaussian & Neural Accelerator 3 Intel® Thread Director Yes Intel® Deep Learning Boost (Intel® DL Boost) on CPU Yes Intel® Speed Shift Technology Yes Intel® Turbo Boost Max Technology 3.0 ‡ No Intel® Turbo Boost Technology ‡ 2 Intel® Hyper-Threading Technology ‡ Yes Intel® 64 ‡ Yes Instruction Set 64-bit Instruction Set Extensions Intel® SSE4.1 |  Intel® SSE4.2 |  Intel® AVX2 Idle States Yes Enhanced Intel SpeedStep® Technology Yes Thermal Monitoring Technologies Yes Intel® Volume Management Device (VMD) Yes Security & Reliability Intel® Standard Manageability (ISM) ‡ Yes Intel® Control-Flow Enforcement Technology Yes Intel® AES New Instructions Yes Secure Key Yes Intel® OS Guard Yes Execute Disable Bit ‡ Yes Intel® Boot Guard Yes Mode-based Execute Control (MBEC) Yes Intel® Virtualization Technology (VT-x) ‡ Yes Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes Intel® VT-x with Extended Page Tables (EPT) ‡ Yes

Read more less

Essentials Product Collection 12th Generation Intel® Core™ i7 Processors Code Name Products formerly Alder Lake Vertical Segment Desktop Processor Number i7-12700 Lithography Intel 7 CPU Specifications Total Cores 12 # of Performance-cores 8 # of Efficient-cores 4 Total Threads 20 Max Turbo Frequency 4.90 GHz Intel® Turbo Boost Max Technology 3.0 Frequency ‡ 4.90 GHz Performance-core Max Turbo Frequency 4.80 GHz Efficient-core Max Turbo Frequency 3.60 GHz Performance-core Base Frequency 2.10 GHz Efficient-core Base Frequency 1.60 GHz Cache 25 MB Intel® Smart Cache Total L2 Cache 12 MB Processor Base Power 65 W Maximum Turbo Power 180 W Supplemental Information Marketing Status Launched Launch Date Q1'22 Embedded Options Available Yes Datasheet View now Memory Specifications Max Memory Size (dependent on memory type) 128 GB Memory Types Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s Max # of Memory Channels 2 Max Memory Bandwidth 76.8 GB/s ECC Memory Supported   ‡ Yes GPU Specifications GPU Name‡ Intel® UHD Graphics 770 Graphics Base Frequency 300 MHz Graphics Max Dynamic Frequency 1.50 GHz Graphics Output eDP 1.4b |  DP 1.4a |  HDMI 2.1 Execution Units 32 Max Resolution (HDMI)‡ 4096 x 2160 @ 60Hz Max Resolution (DP)‡ 7680 x 4320 @ 60Hz Max Resolution (eDP - Integrated Flat Panel)‡ 5120 x 3200 @ 120Hz DirectX* Support 12 OpenGL* Support 4.5 OpenCL* Support 3 Multi-Format Codec Engines 2 Intel® Quick Sync Video Yes Intel® Clear Video HD Technology Yes # of Displays Supported ‡ 4 Device ID 0x4680 Expansion Options Direct Media Interface (DMI) Revision 4 Max # of DMI Lanes 8 Scalability 1S Only PCI Express Revision 5.0 and 4.0 PCI Express Configurations ‡ Up to 1x16+4 |  2x8+4 Max # of PCI Express Lanes 20 Package Specifications Sockets Supported FCLGA1700 Max CPU Configuration 1 Thermal Solution Specification PCG 2020C TJUNCTION 100°C Package Size 45.0 mm x 37.5 mm Advanced Technologies Intel® Gaussian & Neural Accelerator 3 Intel® Thread Director Yes Intel® Deep Learning Boost (Intel® DL Boost) on CPU Yes Intel® Optane™ Memory Supported ‡ Yes Intel® Speed Shift Technology Yes Intel® Turbo Boost Max Technology 3.0 ‡ Yes Intel® Turbo Boost Technology ‡ 2 Intel® Hyper-Threading Technology ‡ Yes Intel® 64 ‡ Yes Instruction Set 64-bit Instruction Set Extensions Intel® SSE4.1 |  Intel® SSE4.2 |  Intel® AVX2 Idle States Yes Enhanced Intel SpeedStep® Technology Yes Thermal Monitoring Technologies Yes Intel® Volume Management Device (VMD) Yes Security & Reliability Intel vPro® Eligibility ‡ Intel vPro® Enterprise |  Intel vPro® Essentials Intel® Threat Detection Technology (TDT) Yes Intel® Active Management Technology (AMT) ‡ Yes Intel® Standard Manageability (ISM) ‡ Yes Intel® One-Click Recovery ‡ Yes Intel® Hardware Shield Eligibility ‡ Yes Intel® Control-Flow Enforcement Technology Yes Intel® Total Memory Encryption - Multi Key Yes Intel® Total Memory Encryption Yes Intel® AES New Instructions Yes Secure Key Yes Intel® OS Guard Yes Intel® Trusted Execution Technology ‡ Yes Execute Disable Bit ‡ Yes Intel® Boot Guard Yes Mode-based Execute Control (MBEC) Yes Intel® Stable IT Platform Program (SIPP) Yes Intel® Virtualization Technology with Redirect Protection (VT-rp) ‡ Yes Intel® Virtualization Technology (VT-x) ‡ Yes Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes Intel® VT-x with Extended Page Tables (EPT) ‡ Yes

Read more less

Essentials Product Collection 12th Generation Intel® Core™ i5 Processors Code Name Products formerly Alder Lake Vertical Segment Desktop Processor Number i5-12400 Lithography Intel 7 CPU Specifications Total Cores 6 # of Performance-cores 6 # of Efficient-cores 0 Total Threads 12 Max Turbo Frequency 4.40 GHz Performance-core Max Turbo Frequency 4.40 GHz Performance-core Base Frequency 2.50 GHz Cache 18 MB Intel® Smart Cache Total L2 Cache 7.5 MB Processor Base Power 65 W Maximum Turbo Power 117 W Supplemental Information Marketing Status Launched Launch Date Q1'22 Embedded Options Available Yes Datasheet View now Memory Specifications Max Memory Size (dependent on memory type) 128 GB Memory Types Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s Max # of Memory Channels 2 Max Memory Bandwidth 76.8 GB/s GPU Specifications GPU Name‡ Intel® UHD Graphics 730 Graphics Base Frequency 300 MHz Graphics Max Dynamic Frequency 1.45 GHz Graphics Output eDP 1.4b |  DP 1.4a |  HDMI 2.1 Execution Units 24 Max Resolution (HDMI)‡ 4096 x 2160 @ 60Hz Max Resolution (DP)‡ 7680 x 4320 @ 60Hz Max Resolution (eDP - Integrated Flat Panel)‡ 5120 x 3200 @ 120Hz DirectX* Support 12 OpenGL* Support 4.5 OpenCL* Support 3 Multi-Format Codec Engines 1 Intel® Quick Sync Video Yes Intel® Clear Video HD Technology Yes # of Displays Supported ‡ 4 Device ID 0x4692 / 0x4682 Expansion Options Direct Media Interface (DMI) Revision 4 Max # of DMI Lanes 8 Scalability 1S Only PCI Express Revision 5.0 and 4.0 PCI Express Configurations ‡ Up to 1x16+4 |  2x8+4 Max # of PCI Express Lanes 20 Package Specifications Sockets Supported FCLGA1700 Max CPU Configuration 1 Thermal Solution Specification PCG 2020C TJUNCTION 100°C Package Size 45.0 mm x 37.5 mm Advanced Technologies Intel® Gaussian & Neural Accelerator 3 Intel® Thread Director No Intel® Deep Learning Boost (Intel® DL Boost) on CPU Yes Intel® Optane™ Memory Supported ‡ Yes Intel® Speed Shift Technology Yes Intel® Turbo Boost Max Technology 3.0 ‡ No Intel® Turbo Boost Technology ‡ 2 Intel® Hyper-Threading Technology ‡ Yes Intel® 64 ‡ Yes Instruction Set 64-bit Instruction Set Extensions Intel® SSE4.1 |  Intel® SSE4.2 |  Intel® AVX2 Idle States Yes Enhanced Intel SpeedStep® Technology Yes Thermal Monitoring Technologies Yes Intel® Volume Management Device (VMD) Yes Security & Reliability Intel® Threat Detection Technology (TDT) Yes Intel® Standard Manageability (ISM) ‡ Yes Intel® Control-Flow Enforcement Technology Yes Intel® AES New Instructions Yes Secure Key Yes Intel® OS Guard Yes Execute Disable Bit ‡ Yes Intel® Boot Guard Yes Mode-based Execute Control (MBEC) Yes Intel® Virtualization Technology (VT-x) ‡ Yes Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes Intel® VT-x with Extended Page Tables (EPT) ‡ Yes

Read more less

Essentials Product Collection 10th Generation Intel® Core™ i5 Processors Code Name Products formerly Comet Lake Vertical Segment Desktop Processor Number i5-10400 Lithography 14 nm CPU Specifications Total Cores 6 Total Threads 12 Max Turbo Frequency 4.30 GHz Intel® Turbo Boost Technology 2.0 Frequency‡ 4.30 GHz Processor Base Frequency 2.90 GHz Cache 12 MB Intel® Smart Cache Bus Speed 8 GT/s TDP 65 W Supplemental Information Marketing Status Launched Launch Date Q2'20 Embedded Options Available No Datasheet View now Memory Specifications Max Memory Size (dependent on memory type) 128 GB Memory Types DDR4-2666 Max # of Memory Channels 2 Max Memory Bandwidth 41.6 GB/s ECC Memory Supported   ‡ No GPU Specifications GPU Name‡ Intel® UHD Graphics 630 Graphics Base Frequency 350 MHz Graphics Max Dynamic Frequency 1.10 GHz Graphics Video Max Memory 64 GB 4K Support Yes |  at 60Hz Max Resolution (HDMI)‡ 4096 x 2160@30Hz Max Resolution (DP)‡ 4096 x 2304@60Hz Max Resolution (eDP - Integrated Flat Panel)‡ 4096 x 2304@60Hz DirectX* Support 12 OpenGL* Support 4.5 Intel® Quick Sync Video Yes Intel® InTru™ 3D Technology Yes Intel® Clear Video HD Technology Yes Intel® Clear Video Technology Yes # of Displays Supported ‡ 3 Device ID 0x9BC8 / 0x9BC5 Expansion Options Scalability 1S Only PCI Express Revision 3 PCI Express Configurations ‡ Up to 1x16 |  2x8 |  1x8+2x4 Max # of PCI Express Lanes 16 Package Specifications Sockets Supported FCLGA1200 Max CPU Configuration 1 Thermal Solution Specification PCG 2015C TJUNCTION 100°C Package Size 37.5mm x 37.5mm Advanced Technologies Intel® Optane™ Memory Supported ‡ Yes Intel® Thermal Velocity Boost No Intel® Turbo Boost Max Technology 3.0 ‡ No Intel® Turbo Boost Technology ‡ 2 Intel® Hyper-Threading Technology ‡ Yes Intel® Transactional Synchronization Extensions No Intel® 64 ‡ Yes Instruction Set 64-bit Instruction Set Extensions Intel® SSE4.1 |  Intel® SSE4.2 |  Intel® AVX2 Idle States Yes Enhanced Intel SpeedStep® Technology Yes Thermal Monitoring Technologies Yes Intel® Identity Protection Technology ‡ Yes Security & Reliability Intel® AES New Instructions Yes Secure Key Yes Intel® Software Guard Extensions (Intel® SGX) Yes with Intel® ME Intel® OS Guard Yes Intel® Trusted Execution Technology ‡ No Execute Disable Bit ‡ Yes Intel® Boot Guard Yes Intel® Stable IT Platform Program (SIPP) No Intel® Virtualization Technology (VT-x) ‡ Yes Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
