Specifications:
Form Factor:
Micro-ATX (m-ATX)
Socket:
AMD AM4
Chipset:
AMD B450
CPU Support:
Compatible with AMD Ryzen™ processors (5000, 4000, 3000, 2000, 1000 series) and Athlon™ processors
Memory:
Four DDR4 DIMM sockets
Up to 128GB system memory
Dual-channel memory architecture
Supports DDR4 2933/2667/2400/2133 MT/s and XMP profiles
Expansion Slots:
1x PCIe 3.0 x16 slot
Additional PCIe slots for expansion
Storage:
1x M.2 slot (PCIe 3.0 x4) for high-speed SSDs, supporting up to 32Gb/s
4x SATA 6Gb/s ports
Supports RAID 0, 1, and 10
Networking:
Realtek® GbE LAN chip (1 Gbps)
Audio:
Realtek® Audio codec for 2/4/5.1/7.1-channel high definition audio
Rear Panel Ports:
HDMI (HDMI 2.1) for video output
USB 3.0 ports
USB 2.0 ports
Audio and LAN ports
Specifications
Form Factor:
Micro-ATX
CPU Socket:
LGA 1200
Chipset:
Intel® H510 Express Chipset
Processor Support:
11th Gen (Core™ i9/i7/i5) and 10th Gen (Core™ i9/i7/i5/i3, Pentium®, Celeron®) Intel® processors
Memory:
2 x DDR4 DIMM sockets, supporting up to 64GB, dual-channel architecture, and speeds up to DDR4 3200 MHz (with 11th Gen)
Expansion Slots:
1 x PCI Express x16 (PCIe 3.0 x16), 1 x PCI Express x1 (PCIe 3.0 x1)
Storage:
1 x M.2 connector (SATA & PCIe Gen3 x4 SSD support)
Onboard Graphics:
Integrated Graphics Processor with Intel® HD Graphics support, 1 x HDMI port (up to 4096x2160@30 Hz)
Audio:
Realtek® 8-channel HD Audio
LAN:
Realtek® GbE LAN chip
USB Ports:
2 x USB 3.2 Gen 1, 4 x USB 2.0/1.1 ports (on back panel), with additional ports available via internal headers
Unique Features:
Smart Fan 5 with multiple temperature sensors and hybrid fan headers for advanced fan control
GIGABYTE APP Center for easy system management
Anti-Sulfur Resistors for enhanced protection against environmental damage
Specification
Detail
Interface
PCIe 3.0x4, NVMe 1.3
Form Factor
M.2 2280
Capacity
1TB
Sequential Read Speed
Up to 2400 MB/s
Sequential Write Speed
Up to 1800 MB/s
Random Read IOPS
Up to 130K
Random Write IOPS
Up to 350K
External DDR Cache
N/A
Host Memory Buffer (HMB)
Supported
Other Features
TRIM, S.M.A.R.T.
Mean Time Between Failure (MTBF)
1.5 million hours
Operating Temperature
0∘C0 raised to the composed with power cap C
0∘𝐶
to
Free Aula S11 PRO with 6 Keys Wired Gaming MouseGraphics ProcessingGeForce® GTX 1650Core Clock1590 MHzCUDA® Cores896Memory Clock12000 MHzMemory Size4 GBMemory TypeGDDR6Memory Bus128 bitMemory Bandwidth (GB/sec)192 GB/sCard BusPCI-E 3.0 x 16Digital max resolution7680x4320@60HzMulti-view3Card sizeL=172 W=122 H=40 mmPCB FormATXDirectX12OpenGL4.6NVIDIA Encoder (NVENC)Yes (Turing)Recommended PSU300WPower Connectors6 Pin*1OutputDisplayPort 1.4 *1HDMI 2.0b *1DVI-D *1SLI SupportNoAccessoriesQuick guide_____________________________________________________Warranty Information:• Item compatibility is buyer’s responsibility.• For security purposes: Kindly secure unboxing video incase wrong item and defective upon received.• Check all items upon receipt.• All items/claims for warranty are carry-in.• Tampered warranty sticker voids the warranty.• Overclocking may void the warranty.• Items for warranty must be complete with original contents/packaging and accompanied by warranty receipt.• Defective items for warranty are subject for pull out and RMA services. (Shipping fee should be shoulder by customer)
KEY FEATURES
80 PLUS Bronze certified
120mm Silent Hydraulic Bearing (HYB) Fan
Reliable flat cable
Single +12V rail
OVP/OPP/SCP/UVP/OCP/OTP protection
80 PLUS BRONZE CERTIFIED
80 Plus Bronze certified ensures to deliver 85% efficiency at 50% load. The better power efficiency leads to less power waste, less heat and less fan noise.
Reliable Flat Cable
P550B provides the best solution for the system builds. The flat cable reduces the clutter and improves the airflow in the case.
120mm Silent Hydraulic Bearing (HYB) Fan
120mm Silent Hydraulic Bearing fan optimizes the noise reduction and the thermal performance. The fan speed is adjusted according to the automatic power detection. The Hydraulic Bearing fan provides longer and more stable lifetime.
SINGLE +12V RAIL
Single +12V rail provides the best power output, stability and compatibility for the hardware. It provides the easiest way to install the power cable. And it is the best design for overclocking.
PROTECTION
In order to make sure the entire computer system to operate stably under any conditions, we not only added protection designs such as OCP, OTP, OVP, OPP, UVP and SCP, but also ensured the stable operation of your system through the safety certification of various countries.
SPECIFICATIONS
Model
P550B
Type
Intel Form Factor ATX 12V v2.31
PFC
Active PFC (>0.9 typical)
Input Voltage
100-240 Vac (full range)
Input Current
8-4A
Input Frequency
60-50 Hz
Output Capacity
550W
Dimension
150 x 140 x 86 mm
Fan Type
120 mm Hydraulic Bearing (HYB) Fan
80 PLUS
Gold
Efficiency
85% at typical load
MTBF
>100,000 hours
Protection
OVP/OPP/SCP/UVP/OCP/OTP
Power Good Signal
100-150ms
Hold Up Time
>16ms
Cable Type
Flat, All black
Connectors
ATX/MB 20+4 Pin x 1: 550mm*1
CPU/EPS 4+4 Pin x 1: 600mm*2
PCI-e 6+2 Pin x 2: 550mm+150mm*1
SATA X 6: 500mm+120mm+120mm*2
4 Pin Peripheral x 3+4- Pin floppy x1: 500mm+120mm+120mm+120mm*1
AMD A520 Ultra Durable Motherboard with GbE LAN with Bandwidth Management, PCIe 3.0 x4 M.2, Smart Fan 5, Anti-Sulfur Resistors Design
Brand
Gigabyte
Memory Type
DDR4
Form Factor
mATX
Socket
AM4
CPU
AMD Socket AM4, support for: AMD Ryzen™ 5000 G-Series Processors/ AMD Ryzen™ 5000 Series Processors/ AMD Ryzen™ 4000 G-Series Processors/ AMD Ryzen™ 3000 and Ryzen™ 3000 G-Series Processors
Chipset
AMD A520
Memory
2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory
Onboard Graphics
Integrated Graphics Processor:1 x D-Sub port, supporting a maximum resolution of 1920×1200@60 Hz1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz* Support for HDMI 2.1 version, HDCP 2.3, and HDR.
Audio
Realtek® Audio CODECHigh Definition Audio2/4/5.1/7.1-channel
LAN
Realtek® GbE LAN chip (1 Gbps/100 Mbps)
Expansion Slots
CPU:1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16Chipset:1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
Storage Interface
CPU:1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 3.0 x4/x2 SSD support)Chipset:4 x SATA 6Gb/s connectors
USB
CPU:4 x USB 3.2 Gen 1 ports on the back panelChipset:2 x USB 3.2 Gen 1 ports available through the internal USB header6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
Internal I/O Connectors
1 x 24-pin ATX main power connector1 x 8-pin ATX 12V power connector1 x CPU fan header1 x system fan header1 x M.2 Socket 3 connector4 x SATA 6Gb/s connectors1 x front panel header1 x front panel audio header1 x USB 3.2 Gen 1 header2 x USB 2.0/1.1 headers1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only)1 x speaker header1 x Clear CMOS jumper1 x chassis intrusion header
Back Panel Connectors
1 x PS/2 keyboard/mouse port1 x D-Sub port1 x HDMI port4 x USB 3.2 Gen 1 ports2 x USB 2.0/1.1 ports1 x RJ-45 port3 x audio jacks
Form Factor
Micro ATX Form Factor; 23.3cm x 19.8cm
KEY FEATURES
80 PLUS Bronze certified
120mm Silent Hydraulic Bearing (HYB) Fan
Reliable flat cable
Single +12V rail
OVP/OPP/SCP/UVP/OCP/OTP protection
80 PLUS BRONZE CERTIFIED
80 Plus Bronze certified ensures to deliver 85% efficiency at 50% load. The better power efficiency leads to less power waste, less heat and less fan noise.
Reliable Flat Cable
P450B provides the best solution for the system builds. The flat cable reduces the clutter and improves the airflow in the case.
The life of the Hydraulic Bearing fan is more than 4 years
120mm Silent Hydraulic Bearing (HYB) Fan
120mm Silent Hydraulic Bearing fan optimizes the noise reduction and the thermal performance. The fan speed is adjusted according to the automatic power detection. The Hydraulic Bearing fan provides longer and more stable life time.
SINGLE +12V RAIL
Single +12V rail provides the best power output, stability and compatibility for the hardware. It provides the easiest way to install the power cable. And it is the best design for overclocking.
PROTECTION
In order to make sure the entire computer system to operate stably under any conditions, we not only added protection designs such as OCP, OTP, OVP, OPP, UVP and SCP, but also ensured the stable operation of your system through the safety certification of various countries.
SPECIFICATIONS
Model
P450B
Type
Intel Form Factor ATX 12V v2.31
PFC
Active PFC (>0.9 typical)
Input Voltage
100-240 Vac(full range)
Input Current
8-4 A
Input Frequency
60-50 Hz
Output Capacity
450W
Dimension
150 x 140 x 86 mm
Fan Type
120 mm Hydraulic Bearing (HYB) Fan
80 PLUS
Bronze
Efficiency
85% at typical load
MTBF
>100,000 hours
Protection
OVP/OPP/SCP/UVP/OCP/OTP
Power Good Signal
100-500ms
Hold Up Time
>16ms
Cable Type
Flat, All black
Connectors
ATX/MB 20+4 Pin x 1: 550 mm*1
CPU/EPS 4+4 Pin x1: 600 mm*1
PCI-e+2 Pin x2: 550 mm+150 mm*1
SATA x 6: 500mm+120mm+120mm*2
4 Pin Peripheral x 3 + 4-Pin floppy x 1: 500mm+120mm+120mm+120mm*1
