The GV-N506TWF2-8GD is a compact, high-performance graphics card from GIGABYTE’s WINDFORCE series, designed for small form factor (SFF) builds. It leverages NVIDIA’s latest Blackwell architecture and DLSS 4 technology to deliver stunning visuals, fast frame rates, and AI-enhanced performance for gaming and creative workloads.
Specifications:
GPU Architecture
:NVIDIA Blackwell
CUDA Cores:
4608
Core Clock:
2572 MHz
Memory:
8GB GDDR7
Memory Interface:
128-bit
Memory Speed:
28 Gbps
Bus Interface:
PCIe 5.0 x8
Max Resolution:
7680 × 4320 (8K)
Cooling System:
WINDFORCE dual-fan cooling
Video Outputs:
1 × HDMI 2.1b
3 × DisplayPort 2.1b
Form Factor:
ATX (Compact dimensions: 8.19 x 4.72 x 0.1 inches)
Power Connector:
8-pin
TDP:~
180W
Advanced Features:
DLSS 4: AI-powered Multi Frame Generation for higher FPS and improved image quality
1
Ray Tracing: Real-time ray tracing with enhanced RT Cores for cinematic visuals
NVIDIA Reflex 2: Frame Warp technology for ultra-low latency in competitive gaming
NVIDIA Studio Support: Optimized for creative applications like video editing and 3D rendering
AI Enhancements: Voice and video improvements for streaming and conferencing
Ideal Use Cases:
Compact gaming PCs
Creative workstations with limited space
Users seeking next-gen performance and efficiency
The GIGABYTE RTX 5060 Ti WINDFORCE OC is a compact yet powerful graphics card built for gamers and creators who need high performance in a small form factor (SFF). It features the latest NVIDIA Blackwell architecture and is equipped with 8GB of ultra-fast GDDR7 memory, making it ideal for demanding applications and modern games.
Specifications:
GPU:
NVIDIA GeForce RTX 5060 Ti (GB206)
CUDA Cores:
4608
Core Clock:
2587 MHz (OC Mode)
Memory:
8GB GDDR7
Memory Interface:
128-bit
Effective Memory Clock:
28 GHz
Bus Interface:
PCI Express 5.0 x8
Cooling System:
WINDFORCE dual-fan cooling
Max Resolution:
7680 x 4320 (8K)
Ports:
1 × HDMI 2.1b
3 × DisplayPort 2.1b
Form Factor:
ATX, compact design (208 x 120 x 40 mm)
Slot Width:
2 slots
Power Connector:
8-pin
TDP:
180W
DirectX/OpenGL Support:
DirectX 12 Ultimate, OpenGL 4.6
HDCP Ready:
Yes
Features:
DLSS 4: AI-powered rendering for higher FPS and better image quality
Ray Tracing: Real-time ray tracing for cinematic visuals
NVIDIA Reflex 2: Enhanced responsiveness with Frame Warp technology
NVIDIA Studio Support: Optimized for creative workflows like video editing and 3D rendering
Ideal For:
Compact gaming builds
Creative professionals needing high GPU performance in limited space
Users looking for next-gen features like DLSS 4 and advanced ray tracing
Overview: The GIGABYTE RTX 5060 Ti GAMING OC is a high-performance graphics card designed for gamers and creators who demand smooth gameplay, fast rendering, and advanced features. With 8GB of ultra-fast GDDR7 memory, this GPU delivers exceptional performance in modern AAA titles and creative applications.
Key Features:
GPU Model:
NVIDIA GeForce RTX 5060 Ti
Memory:
8GB GDDR7
Cooling:
WINDFORCE cooling system with alternate spinning fans for efficient heat dissipation
Core Clock:
Factory overclocked for enhanced performance
Bus Interface:
PCI Express
CUDA Cores:
Optimized for parallel processing and AI workloads
Video Outputs:
Supports multiple high-resolution displays
Ray Tracing & DLSS:
Real-time ray tracing and AI-powered upscaling for immersive visuals
Build Quality:
Durable backplate and reinforced design for long-term reliability
Additional Info:
Category: Video Cards & Adapters
Interface: High-speed connectivity for seamless integration
Power Consumption (TDP): Efficient power usage with optimized thermal performance
Compatibility: Ideal for gaming rigs, workstations, and high-performance PCs
