| Category |
Specification |
| Model |
ASUS PRIME B760M-R D4 |
| Chipset |
Intel B760 |
| Socket |
LGA1700 |
| Supported CPUs |
Intel 12th / 13th / 14th Gen Core, Pentium Gold, Celeron |
| Form Factor |
Micro-ATX (24.4 × 21.1 cm) |
| Weight |
~0.55–0.65 kg (board only, estimated typical ASUS PRIME mATX DDR4 weight) |
| Memory Type |
DDR4 |
| RAM Slots |
2 × DIMM |
| Max Memory Capacity |
Up to 64 GB |
| Memory Speeds |
2133 MHz – 5333 MHz (OC, CPU dependent) |
| Memory Features |
Dual-channel, Intel XMP support, non-ECC UDIMM |
| Graphics Output | 1 × HDMI 2.1 |
| Max Resolution | Up to 4K @ 60Hz |
| PCIe Slots | 1 × PCIe 4.0 x16, 2 × PCIe 4.0 x1 |
| Storage | 2 × M.2 (PCIe 4.0 x4), 4 × SATA 6Gb/s |
| RAID Support | RAID 0 / 1 / 5 / 10 (Intel RST) |
| LAN | Realtek 2.5Gb Ethernet + ASUS LANGuard |
| WiFi / Bluetooth | None (no onboard WiFi or Bluetooth) |
| Rear USB Ports | 4 × USB 5Gbps (Type-A), 4 × USB 2.0 |
| Front USB Support | 1 × USB 5Gbps header (2 ports), 2 × USB 2.0 headers (4 ports) |
| Audio | Realtek 7.1 Surround HD Audio Codec |
| Audio Features | Audio shielding, premium capacitors, PCB isolation |
| Rear I/O Ports | HDMI ×1, USB ×8, LAN ×1, Audio jacks ×3 |
| Internal Headers | M.2 ×2, SATA ×4, USB headers, RGB + ARGB, TPM, COM, S/PDIF |
| Fan Headers | 1 × CPU fan, 2 × chassis fan |
| RGB Support | 1 × RGB + 2 × Addressable Gen 2 headers |
| Cooling | VRM heatsink, chipset heatsink, Fan Xpert 2+ |
| BIOS | 128Mb UEFI AMI BIOS |
| BIOS Features | EZ Flash 3, CrashFree BIOS 3, UEFI EZ Mode |
| Power Connectors | 24-pin ATX + 8-pin CPU |
| Protection Features | ASUS 5X Protection III (SafeSlot Core, LANGuard, Overvoltage protection) |
| Software | Armoury Crate, AI Suite 3, Fan Xpert 2+, Norton trial |
| OS Support | Windows 10 / Windows 11 (64-bit) |
| Accessories | SATA cables, I/O shield, M.2 screw kit |
| Networking Features | WOL, PXE boot |
| Special Features | ASUS Q-Design, EZ DIY, Aura Sync RGB |
