Appearance
|
|
Type
|
· M.2 2280
|
|
Dimensions
|
Single-sided: 80 mm x 22 mm x 2.23 mm (3.15" x 0.87" x 0.09")
Double-sided: 80 mm x 22 mm x 3.58 mm (3.15" x 0.87" x 0.14")
|
|
Weight
|
8 g (0.28 oz)
|
|
Interface
|
|
Bus Interface
|
· NVMe PCIe Gen3 x4
|
|
Storage
|
|
Flash Type
|
· 3D NAND flash
|
|
Capacity
|
· 128 GB/ 256 GB/ 512 GB/ 1 TB/ 2 TB
|
|
Operating Environment
|
|
Operating Temperature
|
0°C (32°F) ~ 70°C (158°F)
|
|
Operating Voltage
|
· 3.3V±5%
|
|
Performance
|
|
Sequential Read/Write (CrystalDiskMark)
|
2 TB Up to 2,500/1,700 MB/s
1 TB Up to 1,700/1,400 MB/s
512 GB Up to 1,700/1,400 MB/s
256 GB Up to 1,600/1,100 MB/s
128 GB Up to 1,500/550 MB/s
|
|
4K Random Read/Write (IOmeter)
|
2 TB Up to 200,000/250,000 IOPS
1 TB Up to 200,000/250,000 IOPS
512 GB Up to 160,000/250,000 IOPS
256 GB Up to 90,000/250,000 IOPS
128 GB Up to 95,000/130,000 IOPS
|
|
Terabytes Written (TBW)
|
2 TB 800 TBW
1 TB 400 TBW
512 GB 200 TBW
256 GB 100 TBW
128 GB 50 TBW
|
|
Mean Time Between Failures (MTBF)
|
2,000,000 hour(s)
|
|
Drive Writes Per Day (DWPD)
|
0.2 (5 yrs)
|
|
Note
|
· Speed may vary due to host hardware, software, usage, and storage capacity.
· The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity.
· Terabytes Written (TBW) expresses the endurance under the highest capacity.
· Some motherboards only provide PCIe x2 connections for the M.2 slot, creating a bottleneck on even the fastest drives.
|
|
System Requirement
|
|
Operating System
|
· Microsoft Windows 7 or later
· Linux Kernel 2.6.31 or later
|
|
Note
|
· Systems for use with the PCIe M.2 SSD must have an M.2 connector with only an M key. B-key connectors are not compatible. Improper insertion may lead to damage. Please click here for more information.
|
