Description
A950RG
A950RG wireless router complies with the latest IEEE 802.11ac wave2 Wi-Fi standard, with MU-MIMO technology offering continual high speed data transmission for multiple devices at the same time.
Built-in 1GHz processor provides powerful data handling capacity to improve Wi-Fi transfer efficiency.
Meanwhile, simultaneous dual band with middle power design on both bands make wireless connection more flexible and stable, especially over long distance.
Generally, A950RG is designed for medium-size homes with increasing demand of high-speed Wi-Fi network.
FEATURES:
- Complies with the next generation IEEE 802.11ac Wi-Fi standard.
- 867Mbps on 5GHz and 300Mbps on 2.4GHz band for total 1167Mbps simultaneously.
- Middle power design on both bands is perfect for long distance wireless transmission.
- MU-MIMO technology allows data transfer to multiple devices at the same time.
- Gigabit WAN ensures high speed Internet access and Wi-Fi speed.
- Supports DHCP, Static IP, PPPoE, PPTP and L2TP broadband functions.
- Provides 64/128-bit WEP, WPA, WPA2 and WPA/WPA2 (TKIP+AES) security.
- Connects to secure network easily and fast using WPS.
- QoS: Bandwidth Control based on IP.
- Supports IP, MAC, URL filtering and Port Forwarding.
- Universal Repeater and WDS function for easy Wi-Fi extension.
- Multi-SSID function enables users to create multiple Wi-Fi networks.
- Supports easy and fast IPTV settings.
SPECIFICATIONS:
| HARDWARE |
|
| Interface: |
- 4 * 100Mbps LAN Ports |
|
- 1 * 100Mbps WAN Port |
| Power Supply: |
- DC 9V/0.8A
|
| Button: |
1 * RST/WPS Button |
| LED Indicators: |
1 * Status,
|
|
4 * LAN,
|
|
1 * WAN |
| Antenna: |
- 4 * 5dBi fixed antennas |
| Dimensions (L x W x H): |
- 170.2 x 138.0 x 40.6 mm (not including antennas) |
| WIRELESS |
|
| Standards: |
IEEE 802.11ac,
|
|
IEEE 802.11a,
|
|
IEEE 802.11b,
|
|
IEEE 802.11g, |
|
IEEE 802.11n |
| RF Frequency: |
- 2.4GHz/5GHz |
| Data Rate: |
2.4GHz: Up to 300Mbps |
|
5GHz: Up to 867Mbps |
| EIRP: |
2.4GHz < 22dBm
|
|
5GHz < 20dBm |
| Wireless Security: |
64/128-bit WEP, WPA, WPA2 and WPA-Mixed |
| Reception Sensitivity: |
- 2.4G: 11b: <-81dbm. |
|
11g: <-68dbm. |
|
11n: HT20<-65dbm HT40: <-62dbm |
|
- 5G: 11a:<-68dbm: |
|
11n: HT20<-65dbm HT40: <-62dbm
|
|
11ac: <-51dbm |
| SOFTWARE |
|
| Operation Mode: |
Gateway Mode Bridge Mode |
|
Repeater Mode |
|
WISP Mode |
| Network: |
Static DHCP Setting, IPTV, IPV6 |
| WAN Type: |
Static IP, DHCP, PPPoE/Russia PPPoE, PPTP/Russia PPTP, L2TP/Russia L2TP |
| Wireless Functions: |
Multiple SSID,
|
|
MAC Authentication,
|
|
Universal Repeater,
|
|
WDS,
|
|
WPS |
| QoS: |
QoS Setup,
|
|
Connect Limit Control |
| Schedule: |
Reboot Schedule,
|
|
Wireless Schedule |
| Firewall: |
MAC Filtering,
|
|
IP Filtering,
|
|
Port Filtering,
|
|
URL Filtering Port Forwarding,
|
|
DMZ |
| Management: |
Administrator Setting,
|
|
Time Setting,
|
|
DDNS, Remote Management,
|
|
UPnP,
|
|
Upgrade Firmware,
|
|
System Configuration,
|
|
System Log, and more |
| OTHERS |
|
| Package Contents: |
A950RG Wireless Router *1 |
|
Power Adapter *1 |
|
Ethernet Cable *1 |
|
Quick Installation Guide *1 |
| Environment: |
Operating Temperature: 0℃~50 ℃ (32 ℉~122℉) |
|
Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉) |
|
Operating Humidity: 5%~95% non-condensing |
|
Storage Humidity: 5%~95% non-condensing |
