₱871.20
| Specification | Details |
|---|---|
| Range | Easy9 |
| Product Type | Comb busbar |
| Mounting Mode | Horizontal |
| Accessory / Separate Part Category | Connection accessory |
| Lines Description | 1L |
| Length in 18 mm Modules | 57 |
| Standards | IEC 60439-1, IEC 60664 |
| Number of Ways | 57 ways 1L |
| Poles Configuration for 1 Way | 1 × 1P |
| Connection Pitch | 18 mm |
| Connector Type | Tooth |
| Distance Between Ways | 18 mm |
| Insulation | Insulated |
| Device Presentation | Cuttable |
| Provided Equipment | 2 end pieces |
| Rated Operational Current [Ie] | 63 A at 40 °C |
| Rated Operational Voltage [Ue] | 230 V AC 50 Hz Ph/N |
| Rated Insulation Voltage [Ui] | 500 V AC (IEC 61439-1) |
| Mounting Location | Top on tunnel type terminals |
| 9 mm Pitches | 114 |
| Width | 1000 mm |
| Colour | Light grey (RAL 7035) |
| Range Compatibility | Easy9, Easy9 XP |
| Fire Resistance | 850 °C (30 s, IEC 60695-2-1) |
| Pollution Degree | 2 |
| Packing Units – PCE | 1 unit, 1.5 × 1.5 × 101.5 cm, 170 g |
| Packing Units – BB1 | 10 units, 5.2 × 8.8 × 106.5 cm, 1.916 kg |
| Packing Units – P12 | 270 units, 75 × 80 × 120 cm, 50.5 kg |
