| Category | Parameter | Specification |
|---|---|---|
| Main | Range | AvatarOn A |
| Product or component type | Switched socket | |
| Device application | Power supply | |
| Device presentation | Complete product | |
| Colour tint | Grey | |
| Complementary | Socket number | 2 |
| Outlet standard description | 3 pins | |
| Outlet standard deviation | Universal | |
| Switch function | 1-way | |
| Number of gangs | 2 gangs | |
| Connections β terminals | Push-in | |
| Number of terminals | 3 | |
| Clamping connection capacity | Solid cable: 2 Γ 1.5β¦2 Γ 4 mmΒ² | |
| Stranded cable: 2 Γ 1.5β¦2 Γ 4 mmΒ² | ||
| Wire stripping length | 13 mm | |
| Material | Polycarbonate | |
| Surface finish | Glossy / Matt | |
| Device mounting | Flush | |
| Fixing mode | By 2 screws | |
| Dimensions & Weight | Height | 70 mm |
| Width | 120 mm | |
| Depth | 30.3 mm | |
| Embedding depth | 19.3 mm | |
| Net weight | 0.118 kg | |
| Electrical | Rated current | 16 A at 250 V AC 50/60 Hz |
| Environment | IP degree of protection | IP20 |
| Operating temperature | -5β¦45 Β°C | |
| Storage temperature | -5β¦60 Β°C | |
| Relative humidity | 0β¦95 % | |
| Standards | IEC 60884-2-3 | |
| Packing Units | Unit type of Package 1 | PCE |
| Number of units in Package 1 | 1 | |
| Package 1 height | 3.6 cm | |
| Package 1 width | 7 cm | |
| Package 1 length | 12 cm | |
| Package 1 weight | 117 g |
