| GPU |
AMD Radeon™ RX 7800 XT |
| Process Node |
5nm |
| Architecture |
AMD RDNA™ 3 |
| Engine Clock |
Boost: Up to 2430 MHz
Game: Up to 2124 MHz |
| Stream Processors |
3840 |
| Compute Units |
60 CU (with RT+AI Accelerators) |
| Infinity Cache |
64MB |
| Ray Accelerators |
60 |
| Memory Size / Bus |
16GB / 256-bit GDDR6 |
| Memory Clock |
19.5 Gbps Effective |
| Displays Supported |
Maximum 4 Displays |
| Resolution |
HDMI™: 7680×4320
DisplayPort 2.1: 7680×4320 |
| Interface |
PCI-Express 4.0 x16 |
| Output Ports |
2 × HDMI, 2 × DisplayPort |
| BIOS Support |
UEFI |
| Game Index |
4K |
| Sapphire Features |
Digital Power Design, Ultra High Performance Conductive Polymer Aluminum Capacitors, Fuse Protection, High TG Copper PCB, Optimized Composite Heatpipe, Dual-X Cooling Technology, Intelligent Fan Control, Precision Fan Control, Metal Backplate, Angular Velocity Fan Blade, Dual-Ball Bearing Fans, TriXX Supported, TriXX Boost |
| AMD Features |
RDNA™ 3 Architecture, 60 Compute Units, 64MB Infinity Cache, DisplayPort 2.1 Support, Radiance Display Engine, 16GB GDDR6 on 256-Bit Memory Bus, PCI® Express 4.0 Ready, FidelityFX™ Super Resolution, DirectX® 12 Ultimate, DirectStorage, Vulkan® Optimized, AMD Smart Technologies, Adrenalin Edition Software, Noise Suppression, Privacy View, Radeon™ Super Resolution, AMD Link, FreeSync™ |
| Cooler Type |
2 Fans |
| Form Factor |
2.5-slot, ATX |
| Dimensions (L×W×H) |
280 × 128.75 × 52.57 mm |
| Power Consumption |
266W Total Board Power |
| OS Support |
Linux®, Windows® 10/11 64-bit |
| System Requirements |
Minimum 700W PSU, 2 × 8-pin Power Connector, PCIe x16 Slot, 8GB RAM (16GB Recommended) |
