OVERVIEW
Interface: PCIe Gen 4.0 x4, NVMe 2.0
Application: Client PCs, Game Consoles
Capacity: 1,000GB (1GB=1 Billion byte by IDEMA)
* Actual usable capacity may be less (due to
formatting, partitioning, operating system, applications
or otherwise)
Form Factor: M.2 (2280)
General Feature
Application:
Client PCs, Game Consoles
Capacity
1,000GB (1GB=1 Billion byte by IDEMA)
* Actual usable capacity may be
less (due to formatting, partitioning,
operating system, applications or otherwise)
Form Factor
M.2 (2280)
Interface
PCIe Gen 4.0 x4, NVMe 2.0
Dimension (WxHxD)
80 x 22 x 2.3 mm
Weight
Max 9.0g Weight
Storage Memory
Samsung V-NAND 3-bit MLC
Controller
Samsung in-house Controller
Cache Memory
Samsung 1GB Low Power DDR4 SDRAM
Special Feature
TRIM Support: Supported
S.M.A.R.T Support: Supported
GC (Garbage Collection): Auto Garbage Collection
Algorithm
Encryption Support: AES 256-bit Encryption
(Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN Support: Not supported
Device Sleep Mode Support: Yes
|
Performance
Sequential Read: Up to 7,450 MB/s * Performance
may vary based on system hardware & configuration
Sequential Write: Up to 6,900 MB/s * Performance
may vary based on system hardware & configuration
Random Read (4KB, QD32): Up to 1,200,000 IOPS
* Performance may vary based on system hardware &
configuration
Random Write (4KB, QD32): Up to 1,550,000 IOPS
* Performance may vary based on system hardware &
configuration
Random Read (4KB, QD1): Up to 22,000 IOPS
* Performance may vary based on system hardware
& configuration
Random Write (4KB, QD1): Up to 80,000 IOPS
* Performance may vary based
on system
hardware & configuration
Environment
Average Power Consumption (system level):
*Average: 5.4 W*Maximum: 7.8 W (Burst mode)
* Actual power consumption may vary depending on system hardware &
configuration
Power consumption (Idle): Max. 50 mW
* Actual power consumption may vary
depending on system hardware
& configuration
Allowable Voltage: 3.3 V ± 5 % Allowable voltage
Reliability (MTBF): 1.5 Million Hours Reliability (MTBF)
Operating Temperature: 0 - 70 ℃ Operating Temperature
Shock: 1,500 G & 0.5 ms (Half sine)
Software
Management SW: Magician Software for SSD management
|
