| Maximum Memory: |
8 GB (2 x 4 GB) |
| Memory Slot: |
2 x SODIMM DDR3L |
| Flash Memory: |
512MB (Dual boot OS protection) |
| Drive Bay: |
3 x 3.5-inch SATA 6Gb/s, 3Gb/s |
|
Bay 1, 2: SATA 3Gbps |
|
Bay 1, 2: SATA 3Gbps |
| Drive Compatibility: |
3.5-inch SATA hard disk drives |
|
2.5-inch SATA hard disk drives |
|
2.5-inch SATA solid state drives |
|
An optional 2.5" drive tray base (TRAY-25-NK-BLK03) is needed to install a 2.5" SSD/HDD |
| Hot-swappable: |
✓ |
| M.2 Slot: |
2 x M.2 2280 NVMe 500 MB/s slots |
| SSD Cache Acceleration Support: |
Drive bay 3 |
|
M.2 Slots 1 to 2 |
| Gigabit Ethernet Port (RJ45): |
1 |
| Wake on LAN (WOL): |
✓ |
| Jumbo Frame: |
✓ |
| USB 2.0 port: |
2 |
| USB 3.2 Gen 1 port: |
1 |
| HDMI™ Output: |
1, HDMI™ 1.4a (up to 1080p) |
| Audio Output: |
1 x built-in speaker, 1 x 3.5mm line out jack (for amplifiers or speakers) |
| Form Factor: |
Tower |
| LED Indicators: |
System Status, LAN, USB, HDD1~3, M.2 SSD1~2 |
| Buttons: |
Power, Reset, USB Copy |
| Dimensions (HxWxD): |
142 × 150 × 260.1 mm |
| Weight (Net): |
1.64 kg |
| Weight (Gross): |
2.69 kg |
| Operating Temperature: |
0 - 40 °C (32°F - 104°F) |
| Storage Temperature: |
-20 - 70°C (-4°F - 158°F) |
| Relative Humidity: |
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply: |
65W adapter, 100 - 240V |
| Power Consumption: HDD Sleep Mode: |
18.56 W |
| Power Consumption: Operating Mode, Typical: |
26.22 W |
|
Tested with drives fully populated. |
| Fan: |
1 x 90mm, 12VDC |
| System Warning: |
Voice prompts or Buzzer |
| Kensington Security Slot: |
✓ |
