| Technical Specifications |
| Picture / Display |
| Panel Size |
23.8 inch / 60.5 cm |
| Aspect Ratio |
16:9 |
| LCD Panel Type |
IPS technology |
| Backlight Type |
W-LED system |
| Pixel Pitch |
0.2745 x 0.2745 mm |
| Brightness |
300 cd/m² |
| Display Colors |
16.7 million |
| Contrast Ratio (Typical) |
1500:1 |
| SmartContrast |
Mega Infinity DCR |
| Response Time (Typical) |
4 ms (Gray to Gray)* |
| Viewing Angle |
178º (H) / 178º (V) @ C/R > 10 |
| Picture Enhancement |
SmartImage |
| Maximum Resolution |
1920 x 1080 @ 144 Hz |
| Effective Viewing Area |
527.04 (H) x 296.46 (V) mm |
| Scanning Frequency |
30 KHz–160 KHz (H) / 48 Hz–144 Hz (V) |
| sRGB |
Yes |
| Flicker-Free |
Yes |
| Pixel Density |
93 PPI |
| LowBlue Mode |
Yes |
| Display Screen Coating |
Anti-Glare, 3H, Haze 25% |
| MPRT |
0.5 ms* |
| EasyRead |
Yes |
| Adaptive Sync |
Yes |
| HDR |
HDR 10 |
| Connectivity |
| Signal Input |
HDMI 1.4 x1, DisplayPort 1.4 x1 |
| Audio (In/Out) |
Audio Out |
| HDCP |
HDCP 1.4 (HDMI/DP) |
| Convenience |
| Plug & Play Compatibility |
DDC/CI, Mac OS X, sRGB, Windows 11/10 |
| User Convenience |
Power On/Off, Menu, Brightness, Input, SmartImage |
| OSD Languages |
Brazil Portuguese, Czech, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Turkish, Ukrainian |
| Other Convenience |
Kensington Lock, VESA Mount (100×100mm) |
| Stand |
| Tilt |
-5° / 20° |
| Power |
| Power Supply |
External, 100–240VAC, 50–60Hz |
| Off Mode |
0.3 W (typ.) |
| On Mode |
14.3 W (typ.) |
| Standby Mode |
0.5 W (typ.) |
| Power LED Indicator |
Operation – White / Standby – White (blinking) |
| Dimensions |
| Packaging (W×H×D) |
610 × 378 × 126 mm |
| Product Without Stand |
544 × 319 × 32 mm |
| Product With Stand (Max Height) |
544 × 413 × 180 mm |
| Weight |
| With Packaging |
4.45 kg |
| With Stand |
2.46 kg |
| Without Stand |
2.18 kg |
| Operating Conditions |
| Altitude |
Operation: up to 12,000 ft (3,658 m) / Non-operation: up to 40,000 ft (12,192 m) |
| Operating Temperature |
0–40 °C |
| Storage Temperature |
-20–60 °C |
| Relative Humidity |
20–80% |
| MTBF |
50,000 hours (excluding backlight) |
| Sustainability |
| Environmental & Energy |
RoHS |
| Recyclable Packaging Material |
100% |
| Compliance & Standards |
| Regulatory Approvals |
CB, CE Mark, PSB, CEL, CCC, CECP, BSMI, UKCA, EMF, FCC, ICES-003 |
| Cabinet |
| Color |
Black |
| Finish |
Textured |
