Picture/Display
Panel Size: 15.6 inch / 39.6 cm
Aspect ratio: 16:9
LCD panel type: IPS technology
Backlight type: W-LED system
Pixel pitch: 0.17925 x 0.17925 mm
Brightness:250 cd/m²
Display colors: 16.2 M
Color gamut (typical): NTSC 46%*, sRGB 64%*
Contrast ratio (typical): 700:1
Smart Contrast: 50,000,000:1
Response time (typical): 4 ms (Gray to Gray) *
Viewing angle:
-170º (H) / 170º (V) -@ C/R > 10
Picture enhancement: Smart Image
Maximum resolution: 1920 x 1080 @ 75 Hz*
Effective viewing area: 344.16 (H) x 193.59 (V)
Scanning Frequency:
Landscape mode: HDMI 30 - 140 kHz (H), USB-C 30 - 85 kHz (H) / 48 - 75 Hz (V); Portrait mode: 30 - 150 kHz (H) / 48 - 75 Hz (V)
sRGB: Yes
Flicker-free: Yes
Pixel Density: 141 PPI
Low Blue Mode: Yes
Display Screen Coating: Anti-Glare, 3H, Haze 25%
Easy Read: Yes
HDR: HDR 10 supported
Dimensions
Packaging in mm (WxHxD): 400 x 281 x 103 mm
Product with stand (max height): 359 x 232 x 119 mm
Weight
Product with packaging (kg): 2.45 kg
Product with stand (kg): 1.03 kg
|
Connectivity
Signal Input: micro-HDMI 2.0 x 1, USB-C x 1 (DisplayPort 1.4 Alt mode and Power Delivery)
Sync Input: Separate Sync
Audio (In/Out): Audio out
HDCP: HDCP 1.4 (HDMI / USB-C), HDCP 2.2 (HDMI / USB-C)
Power Delivery
Version: USB PD version 3.0
USB-C (input): up to 65W (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/3.25A)
USB-C (output): up to 15W (5V/3A)
Convenience
Plug & Play Compatibility
- DDC/CI
- Mac OS X
- sRGB
- Windows 11 / 10 / 8.1 / 8 / 7
User convenience
- SmartImage
- Input
- Menu
- Power On/Off
-
Other convenience: VESA mount: Yes*
Control software: Smart Control
Stand
Pivot: +90 degree
Tilt: 0 ~ 90 degree
Power
ECO mode: 5.5 W (typ.)
Power supply
-
External
-
100-240VAC, 50-60Hz
Off mode: 0.3 W (typ.)
On mode: 8.2 W (typ.) (Energy Star test method)
Standby mode: 0.3 W (typ.)
Power LED indicator
-
Operation - White
- Standby mode- White (blinking)
Operating conditions
Altitude: Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)
Temperature range (operation): 0°C to 40 °C
Relative humidity: 20%-80 %
Temperature range (storage): -20°C to 60 °C
MTBF (demonstrated): 70,000 hrs (excluded backlight)
|
