| GPU Engine Specs |
|
| CUDA Cores |
6144 |
| Boost Clock (MHz) |
2542MHz |
| Base Clock (MHz) |
2325MHz |
| Thermal and Power Spec |
| Minimum System Power Requirement (W) |
650W |
| Supplementary Power Connectors |
2x PCIe 8-pin cables (adapter in box) OR 300 W or greater PCIe Gen 5 cable |
| Memory Specs |
|
| Memory Clock |
28Gbps |
| Standard Memory Config |
12GB |
| Memory Interface |
GDDR7 |
| Memory Interface Width |
192-bit |
| Memory Bandwidth (GB/sec) |
672 GB/sec |
| Feature Support |
|
| Real-Time Ray Tracing |
Yes |
| Ray Tracing Cores |
4th Generation, 94 TFLOPS |
| Tensor Cores |
5th Generation, 988 AI TOPS |
| NVIDIA Architecture |
Blackwell |
| Microsoft DirectX |
12 Ultimate |
| NVIDIA DLSS |
4 |
| NVIDIA Ansel |
Yes |
| NVIDIA FreeStyle |
Yes |
| Bus Support |
PCI Express Gen 5 |
| NVIDIA ShadowPlay |
Yes |
| OS Certification |
Windows 11 / 10, Linux, FreeBSDx86 |
| NVIDIA Highlights |
Yes |
| NVIDIA G-SYNC™-Ready |
Yes |
| Game Ready Drivers |
Yes |
| NVIDIA Studio Drivers |
Yes |
| NVIDIA GPU Boost™ |
Yes |
| Vulkan API |
1.4 |
| OpenGL |
4.6 |
| NVIDIA Encoder |
2x Ninth Generation |
| NVIDIA Decoder |
1x Sixth Generation |
| Accessories |
|
| Graphics Card Dimensions |
| Length |
250mm |
| Height |
116mm |
| Width |
41mm |
| Display Support |
|
| Multi Monitor |
up to 4 |
| Maxmium Digital Resolution |
4K at 480Hz or 8K at 165Hz with DSC |
| HDCP |
2.3 |
| Standard Display Connectors |
3x DisplayPort 2.1b, 1x HDMI 2.1b |
