Hikvision DS-7616NXI-K2 AcuSense H.265+ 160Mbps 16CH 2SATA 1U NVR [Alarm I/O=4/1

Description

Key specifications
Video Channels:  Up to 16 IP camera inputs
Bandwidth:  Up to 160 Mbps incoming bandwidth
Video Compression:  H.265+/H.265/H.264+/H.264
Decoding Capacity:  Up to 2-ch@12 MP, 3-ch@8 MP, 6-ch@4 MP, or 12-ch@1080p
Intelligent Analytics:
AcuSense technology for reduced false alarms
Motion Detection 2.0 (all channels)
2-ch video analysis for human and vehicle recognition
1-ch facial recognition (stream) or 4-ch (picture library)
Storage:  2 SATA interfaces for HDDs (up to 10 TB per HDD)
Video Output:  Independent HDMI and VGA outputs, with HDMI up to 4K resolution
Power:
Consumption:  = 15 W (without HDD)
Working Temperature:  -10 °C to 55 °C
Dimensions:  385 mm × 315 mm × 52 mm

  • DS-7616NXI-K2

    Intelligent Analytics
  • AI By DeviceFacial recognition, perimeter protection, motion detection 2.0
  • AI By CameraFacial recognition, perimeter protection, throwing objects from building, motion detection2.0, ANPR, VCA
  • Facial Recognition
  • Facial Detection And AnalyticsFace picture comparison, human face capture, face picture search
  • Face Picture LibraryUp to 16 face picture libraries, with up to 20,000 face pictures in total (each picture ≤ 4 MB, total capacity ≤ 1 GB)
  • Facial Detection And Analytics Performance1-ch, 8 MP
  • Face Picture Comparison4-ch
  • Motion Detection 2.0
  • By DeviceAll channels, 4 MP (when enhanced SVC mode is enabled, up to 8 MP) video analysis for human and vehicle recognition to reduce false alarm
  • By CameraAll channels
  • Perimeter Protection
  • By Device2-ch, 4 MP (HD network camera, H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm
  • By CameraAll channels
  • Video And Audio
  • IP Video Input16-ch
  • Incoming Bandwidth160 Mbps
  • Outgoing Bandwidth160 Mbps
  • HDMI Output1-ch, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
  • VGA Output1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
  • Video Output ModeHDMI/VGA independent output
  • CVBS OutputN/A
  • Audio Output1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
  • Two-Way Audio1-ch, RCA (Linear, 1 KΩ)
  • Decoding
  • Decoding FormatH.265/H.265+/H.264+/H.264
  • Recording Resolution12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
  • Synchronous Playback16-ch
  • Decoding Capability

    AI on: 1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30 fps)

    AI off: 2-ch@12 MP (30 fps)/3-ch@8 MP (30 fps)/6-ch@4 MP (30 fps)/12-ch@1080p (30 fps)

  • Stream TypeVideo, Video & Audio
  • Audio CompressionG.711ulaw/G.711alaw/G.722/G.726/AAC
  • Network
  • Remote Connection128
  • APIONVIF (profile S/G); SDK; ISAPI
  • Compatible BrowserIE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version
  • Network ProtocolTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
  • Network Interface1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
  • Auxiliary Interface
  • SATA2 SATA interfaces
  • CapacityUp to 10 TB capacity for each HDD
  • USB InterfaceFront panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
  • Alarm In/Out4/1
  • General
  • GUI LanguageEnglish, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish Language, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz , Brazilian Portuguese, Indonesian
  • Power Supply12 VDC, 3.3 A
  • Consumption≤ 15 W (without HDD)
  • Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
  • Working Humidity10% to 90%
  • Dimension (W × D × H)385 mm × 315 mm × 52 mm (15.2"× 12.4" × 2.0")
  • Weight≤ 1 kg (without HDD, 2.2 lb.)
  • Certification
  • FCCPart 15 Subpart B, ANSI C63.4-2014
  • CEEN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
  • Obtained CertificationCE, FCC, IC, CB, KC, UL, Rohs, Reach, WEEE, RCM, UKCA, LOA, BIS

Hikvision DS-7616NXI-K2 AcuSense H.265+ 160Mbps 16CH 2SATA 1U NVR [Alarm I/O=4/1

Product form

Key specifications Video Channels:  Up to 16 IP camera inputs Bandwidth:  Up to 160 Mbps incoming bandwidth Video Compression:  H.265+/H.265/H.264+/H.264... Read more

SKU: 0000058628

Out of stock

₱6,638.22

    • Authorized Partner. Guaranteed Original Product
    • Available for SAME DAY DELIVERY for Metro Cities
    • Available for SAME DAY DELIVERY in DAVAO
    • Available for SAME DAY DELIVERY FOR PAID CUSTOMERS

    • Guaranteed secure & safe checkout.

    Description

    Key specifications
    Video Channels:  Up to 16 IP camera inputs
    Bandwidth:  Up to 160 Mbps incoming bandwidth
    Video Compression:  H.265+/H.265/H.264+/H.264
    Decoding Capacity:  Up to 2-ch@12 MP, 3-ch@8 MP, 6-ch@4 MP, or 12-ch@1080p
    Intelligent Analytics:
    AcuSense technology for reduced false alarms
    Motion Detection 2.0 (all channels)
    2-ch video analysis for human and vehicle recognition
    1-ch facial recognition (stream) or 4-ch (picture library)
    Storage:  2 SATA interfaces for HDDs (up to 10 TB per HDD)
    Video Output:  Independent HDMI and VGA outputs, with HDMI up to 4K resolution
    Power:
    Consumption:  = 15 W (without HDD)
    Working Temperature:  -10 °C to 55 °C
    Dimensions:  385 mm × 315 mm × 52 mm

    • DS-7616NXI-K2

      Intelligent Analytics
    • AI By DeviceFacial recognition, perimeter protection, motion detection 2.0
    • AI By CameraFacial recognition, perimeter protection, throwing objects from building, motion detection2.0, ANPR, VCA
    • Facial Recognition
    • Facial Detection And AnalyticsFace picture comparison, human face capture, face picture search
    • Face Picture LibraryUp to 16 face picture libraries, with up to 20,000 face pictures in total (each picture ≤ 4 MB, total capacity ≤ 1 GB)
    • Facial Detection And Analytics Performance1-ch, 8 MP
    • Face Picture Comparison4-ch
    • Motion Detection 2.0
    • By DeviceAll channels, 4 MP (when enhanced SVC mode is enabled, up to 8 MP) video analysis for human and vehicle recognition to reduce false alarm
    • By CameraAll channels
    • Perimeter Protection
    • By Device2-ch, 4 MP (HD network camera, H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm
    • By CameraAll channels
    • Video And Audio
    • IP Video Input16-ch
    • Incoming Bandwidth160 Mbps
    • Outgoing Bandwidth160 Mbps
    • HDMI Output1-ch, 4K (3840 × 2160)/30 Hz, 2K (2560 × 1440)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
    • VGA Output1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz
    • Video Output ModeHDMI/VGA independent output
    • CVBS OutputN/A
    • Audio Output1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
    • Two-Way Audio1-ch, RCA (Linear, 1 KΩ)
    • Decoding
    • Decoding FormatH.265/H.265+/H.264+/H.264
    • Recording Resolution12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
    • Synchronous Playback16-ch
    • Decoding Capability

      AI on: 1-ch@12 MP (30 fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p (30 fps)

      AI off: 2-ch@12 MP (30 fps)/3-ch@8 MP (30 fps)/6-ch@4 MP (30 fps)/12-ch@1080p (30 fps)

    • Stream TypeVideo, Video & Audio
    • Audio CompressionG.711ulaw/G.711alaw/G.722/G.726/AAC
    • Network
    • Remote Connection128
    • APIONVIF (profile S/G); SDK; ISAPI
    • Compatible BrowserIE11, Chrome V57, Firefox V52, Safari V12, Edge V89, or above version
    • Network ProtocolTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
    • Network Interface1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
    • Auxiliary Interface
    • SATA2 SATA interfaces
    • CapacityUp to 10 TB capacity for each HDD
    • USB InterfaceFront panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
    • Alarm In/Out4/1
    • General
    • GUI LanguageEnglish, Russian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Turkish, Japanese, Danish, Swedish Language, Norwegian, Finnish, Korean, Traditional Chinese, Thai, Estonian, Vietnamese, Croatian, Slovenian, Serbian, Latvian, Lithuanian, Uzbek, Kazakh, Arabic, Ukrainian, Kyrgyz , Brazilian Portuguese, Indonesian
    • Power Supply12 VDC, 3.3 A
    • Consumption≤ 15 W (without HDD)
    • Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
    • Working Humidity10% to 90%
    • Dimension (W × D × H)385 mm × 315 mm × 52 mm (15.2"× 12.4" × 2.0")
    • Weight≤ 1 kg (without HDD, 2.2 lb.)
    • Certification
    • FCCPart 15 Subpart B, ANSI C63.4-2014
    • CEEN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017
    • Obtained CertificationCE, FCC, IC, CB, KC, UL, Rohs, Reach, WEEE, RCM, UKCA, LOA, BIS
