PSU SHROUD DESIGN
Enjoy a clean look by hiding the PSU and those messy power cables inside the PSU shroud, while separating the PSU heat from the rest of the internal system. With the window design on the left side of the shroud, users can show off the cool outlook of PSU.
DETACHABLE DUST FILTER
The filters keep your PC from accumulating dust, while maintaining optimal cooling performance. The top magnetic filter, along with the removable filter at the bottom, make maintenance easy.
| Specification |
Details |
| Case Form Factor |
Mid Tower |
| M/B Type |
Mini ITX / Micro ATX / ATX / E-ATX |
| Color |
White |
| Materials |
Steel, Plastic, Glass |
| Dimensions |
H=486 W=220 D=473 mm (±1% error) |
| Expansion Slots |
7 |
| 5.25" Drive Bays |
None |
| 3.5"/2.5" Drive Bays |
2 |
| 2.5" Drive Bays |
2 |
| I/O Panel |
USB 3.1 Gen2 Type-C x1 / USB 3.0 x2 / Audio In & Out (HD Audio) / LED Switch |
| Pre-installed Fans |
Front: 120mm x3 (ARGB & PWM), Rear: 120mm x1 (ARGB & PWM), Fan splitter cable included |
| Radiator Support |
Front: Max 360mm, Top: Max 360mm, Rear: Max 120mm |
| Power Supply Type |
Standard ATX (Not included) |
| Maximum Compatibility |
CPU Height: 170mm, GPU Length: 400mm, PSU Length: 180mm |
| Vertical GPU Mount |
Yes (VGA holder bracket: 100mm total clearance) Requires PCIe Riser Cable
|
| Dust Filters |
Top, Bottom |
| RGB Lighting |
Yes (Support RGB Fusion) |
| Weight |
N.W. 7.8 kg, G.W. 9.0 kg |
| Package Dimensions |
H=530 W=282 D=530 mm |
| Accessories |
Manual, Accessories kit |
