| CPU | LGA1851 socket: Supports Intel® Core™ Ultra Processors; L3 cache varies with CPU |
| Chipset | Intel® Z890 Express Chipset |
| Memory | – Supports DDR5 8800(O.C) / 8600(O.C) / 8400(O.C) / 8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C) / 7400(O.C) / 7200(O.C) / 7000(O.C) / 6800(O.C) / 6600(O.C) / 6400 / 6200 / 6000 / 5800 / 5600 MT/s modules – 4 x DDR5 DIMM slots (up to 256 GB, 64 GB per DIMM) |
| Memory Architecture | Dual-channel, supports ECC (operates in non-ECC mode) and non-ECC un-buffered DIMMs, XMP memory modules |
| Onboard Graphics | – 1 x USB4® USB Type-C® port (3840×2160 @144 Hz) – 1 x DisplayPort (3840×2160 @144 Hz) – 1 x HDMI (1920×1080 @30 Hz) Supports up to 3 displays |
| Audio | Realtek® Audio CODEC, supports 2/4/5.1/7.1 channels, S/PDIF Out |
| LAN | Realtek® 2.5GbE LAN (2.5 Gbps/1 Gbps/100 Mbps) |
| Wi-Fi | – MediaTek Wi-Fi 7 MT7925 (PCB rev. 1.0) – Realtek® Wi-Fi 7 RTL8922AE (PCB rev. 1.1), Bluetooth 5.4, supports 11be 160MHz wireless standard |
| Expansion Slots (CPU) | 1 x PCI Express x16 slot (PCIe 5.0, running at x16) |
| Expansion Slots (Chipset) | 2 x PCI Express x16 slots (PCIe 4.0, running at x4) |
| Storage Interface (CPU) | – 1 x M.2 (PCIe 5.0 x4/x2 SSD) – 1 x M.2 (PCIe 4.0 x4/x2 SSD) |
| Storage Interface (Chipset) | – 1 x M.2 (PCIe 4.0 x4/x2 SSD) – 1 x M.2 (PCIe 4.0 x4/x2 SATA/SSD) – 4 x SATA 6Gb/s connectors |
| RAID Support | RAID 0, RAID 1, RAID 5, RAID 10 (for NVMe and SATA) |
| USB Ports (CPU) | 1 x USB4® USB Type-C® port on the back panel |
| USB Ports (Chipset) | – 1 x USB Type-C® (USB 3.2 Gen 2) – 2 x USB 3.2 Gen 2 Type-A (red) – 5 x USB 3.2 Gen 1 ports – 8 x USB 2.0/1.1 ports |
| Internal I/O Connectors | – 1 x 24-pin ATX power – 2 x 8-pin ATX 12V power – 1 x CPU fan – 3 x system fan – 1 x RGB header – 3 x Addressable RGB Gen2 headers – 4 x M.2 connectors – 4 x SATA 6Gb/s connectors |
| Back Panel Connectors | – 1 x USB4® Type-C – 2 x USB 3.2 Gen 2 Type-A – 3 x USB 3.2 Gen 1 – 4 x USB 2.0/1.1 – 1 x DisplayPort – 2 x antenna connectors – 1 x RJ-45 – 1 x optical S/PDIF – 2 x audio jacks |
| H/W Monitoring | Voltage, temperature, fan speed detection, fan fail warning, water cooling flow rate detection, fan/pump speed control |
| BIOS | 1 x 256 Mbit flash, AMI UEFI BIOS, PnP 1.0a, ACPI 5.0, SM BIOS 2.7 |
| Unique Features | Supports GIGABYTE Control Center, Q-Flash, Q-Flash Plus, Smart Backup |
| Bundled Software | Norton® Internet Security (OEM), LAN bandwidth management software |
| Operating System Support | Windows 11 64-bit |
| Form Factor | ATX (30.5cm x 24.4cm) |
