| Core Specifications |
| CPU Socket:
|
LGA 1700 |
| Supported Processors:
|
12th and 13th Gen Intel Core, Pentium Gold, and Celeron processors |
| Chipset: |
Intel Z790 Express Chipset |
| Form Factor: ATX
|
| Memory |
|
| Type:
|
DDR5 |
| Slots: 4 DIMM sockets |
| Maximum Capacity:
|
Up to 128 GB (32GB per DIMM) |
| Memory Speed:
|
Support for up to 7600 MHz (OC) |
| Features:
|
Dual Channel, XMP 3.0 support
|
| Storage |
|
| M.2 Slots:
|
4 x M.2 connectors with support for PCIe 4.0 x4/x2 and SATA III modes on some slots
|
| SATA Connectors: |
6 x SATA 6Gb/s connectors
|
| RAID Support:
|
Yes, for both NVMe and SATA drives
|
| Expansion Slots |
| PCIe x16:
|
1 x PCI Express 5.0 x16 slot
|
| PCIe x4:
|
2 x PCI Express 4.0 x16 slots running at x4 speed
|
| Networking |
| LAN:
|
2.5GbE LAN chip |
| Wireless: |
Intel Wi-Fi 6E (802.11ax) |
| Bluetooth:
|
Bluetooth 5.3
|
| Rear Panel Connectors |
| Display:
|
1 x DisplayPort, 1 x HDMI port |
| USB: |
|
| 2 x USB 3.2 Gen 2 Type-A ports |
| 3 x USB 3.2 Gen 1 ports |
| 4 x USB 2.0/1.1 ports |
| Audio:
|
2 x SMA antenna connectors
|
| Internal Connectors |
| USB Headers: |
| 1 x USB Type-C header (USB 3.2 Gen 2 support) |
| 1 x USB 3.2 Gen 1 header |
| 2 x USB 2.0/1.1 headers |
| Fan Headers: |
1 x CPU fan, 1 x water cooling CPU fan, 3 x system fan, 1 x system fan/water cooling pump header |
| Other:
|
1 x Q-Flash Plus button, reset button, reset jumper, Clear CMOS jumper
|
