| CPU |
|
| LGA1700 socket:
|
Support for the 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors* |
| L3 cache varies with CPU |
| * Please refer to "CPU Support List" for more information. |
| Chipset |
|
| Intel® H610 Express Chipset |
| Memory |
|
| Support for DDR4 3200/3000/2933/2666/2400/2133 MT/s memory modules |
| 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory |
| Dual channel memory architecture |
| Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) |
| Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules |
| Support for Extreme Memory Profile (XMP) memory modules |
| (Please refer "Memory Support List" for more information.) |
| Onboard Graphics |
| Integrated Graphics Processor-Intel® HD Graphics support: |
| 1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz |
| 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz |
| * Support for HDMI 2.1 version and HDCP 2.3. |
| ** Support native HDMI 2.1 TMDS compatible ports |
| (Graphics specifications may vary depending on CPU support.) |
| Audio |
|
| Realtek® Audio CODEC |
| High Definition Audio |
| 2/4/5.1/7.1-channel |
|
|
| LAN |
|
| Realtek® GbE LAN chip (1 Gbps/100 Mbps) |
| Expansion Slots |
| CPU: |
|
| 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 |
| Chipset: |
|
| 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 |
| Storage Interface |
| Chipset: |
|
| 1 x M.2 connector (Socket 3, M key, type 2280/2260 PCIe 3.0 x4/x2 SSD support) |
| 4 x SATA 6Gb/s connectors |
| USB |
|
| Chipset: |
|
| 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) |
| 4 x USB 2.0/1.1 ports on the back panel |
| Chipset+USB 2.0 Hub: |
| 4 x USB 2.0/1.1 ports available through the internal USB headers |
| Internal I/O Connectors |
| 1 x 24-pin ATX main power connector |
| 1 x 8-pin ATX 12V power connector |
| 1 x CPU fan header |
| 2 x system fan headers |
| 1 x M.2 Socket 3 connector |
| 4 x SATA 6Gb/s connectors |
| 1 x RGB LED strip header |
| 1 x front panel header |
| 1 x front panel audio header |
| 1 x USB 3.2 Gen 1 header |
| 2 x USB 2.0/1.1 headers |
| 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) |
| 1 x serial port header |
| 1 x Clear CMOS jumper |
| Back Panel Connectors |
| 1 x PS/2 keyboard port |
| 1 x PS/2 mouse port |
| 1 x D-Sub port |
| 1 x HDMI port |
| 2 x USB 3.2 Gen 1 ports |
| 4 x USB 2.0/1.1 ports |
| 1 x RJ-45 port |
| 3 x audio jacks |
| I/O Controller |
| iTE® I/O Controller Chip |
| H/W Monitoring |
| Voltage detection |
| Temperature detection |
| Fan speed detection |
| Water cooling flow rate detection |
| Fan fail warning |
| Fan speed control |
| * Whether the fan speed control function is supported will depend on the cooler you install. |
| BIOS |
|
| 1 x 128 Mbit flash |
| Use of licensed AMI UEFI BIOS |
| PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features |
| Support for APP Center |
| * * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. |
| @BIOS |
|
| Ambient LED |
| EasyTune |
|
| Smart Backup |
| System Information Viewer |
| Support for Q-Flash |
| Support for Xpress Install |
| Bundled Software |
| Norton® Internet Security (OEM version) |
| LAN bandwidth management software |
| Operating System |
| Support for Windows 11 64-bit |
| Support for Windows 10 64-bit |
| Form Factor |
| Micro ATX Form Factor; 23.0cm x 21.5cm |
