Gigabyte GA-B850M-D3HP Micro-ATX AM5 M-ATX
Gigabyte GA-B850M-D3HP Micro-ATX AM5 M-ATX
Gigabyte GA-B850M-D3HP Micro-ATX AM5 M-ATX
Gigabyte GA-B850M-D3HP Micro-ATX AM5 M-ATX

Gigabyte GA-B850M-D3HP Micro-ATX AM5 M-ATX

(0)
SKU: 0000070670

₱9,096.50

Out of stock

This product will be available for sale in 2 weeks, but you can pre-order now to receive 10% discount!

Estimated delivery between June 07 and June 09.

In stock and ready to ship

Delivery Information

Metro Manila: 2–3 days | Provincial: 3–7 days

Main Office Branch only

Same Day Delivery

Same-Day Delivery Available

Processing starts 1–2 hours after checkout Mon–Sat | Main Office Branch only

Processing only during office hours from Main Office 9am - 5pm
Gigabyte GA-B850M-D3HP Micro-ATX AM5 M-ATX

₱9,096.50

₱9,096.50

Authorized Seller

100% Original Authentic Product

Gigabyte B850M Gaming X WIFI6E AM5 Micro ATX Motherboard GA-B850M-GAMING-X-WF6E (Copy)<h4>Features</h4> 🔹 CPU & Chipset: AMD Ryzen™ 9000/8000/7000 (AM5), B850 chipset 🔹 <a href="https://bermorzone.com.ph">Memory:</a> 4 x DDR5 (up to 256GB, 8200MT/s OC, EXPO/XMP) 🔹 Graphics: HDMI 2.1 & DP 1.4 (Triple-display support) 🔹 Networking: Realtek® 2.5GbE LAN, Wi-Fi 6E, Bluetooth 5.3 🔹 Storage: 1 x PCIe 5.0 M.2, 1 x PCIe 4.0 M.2, 4 x SATA 6Gb/s 🔹 Expansion: 1 x PCIe 5.0 x16, 1 x PCIe 3.0 x16 (x4 mode) 🔹 USB Ports: USB-C (3.2 Gen 2), multiple USB 3.2 & 2.0 ports 🔹 Cooling & RGB: Multiple fan headers, ARGB Gen2 & RGB headers 🔹 Form Factor: Micro ATX (24.4cm x 24.4cm)

Gigabyte B850M Gaming X WIFI6E AM5 Micro ATX Motherboard GA-B850M-GAMING-X-WF6E (Copy)<h4>Features</h4> 🔹 CPU & Chipset: AMD Ryzen™ 9000/8000/7000 (AM5), B850 chipset 🔹 <a href="https://bermorzone.com.ph">Memory:</a> 4 x DDR5 (up to 256GB, 8200MT/s OC, EXPO/XMP) 🔹 Graphics: HDMI 2.1 & DP 1.4 (Triple-display support) 🔹 Networking: Realtek® 2.5GbE LAN, Wi-Fi 6E, Bluetooth 5.3 🔹 Storage: 1 x PCIe 5.0 M.2, 1 x PCIe 4.0 M.2, 4 x SATA 6Gb/s 🔹 Expansion: 1 x PCIe 5.0 x16, 1 x PCIe 3.0 x16 (x4 mode) 🔹 USB Ports: USB-C (3.2 Gen 2), multiple USB 3.2 & 2.0 ports 🔹 Cooling & RGB: Multiple fan headers, ARGB Gen2 & RGB headers 🔹 Form Factor: Micro ATX (24.4cm x 24.4cm)

Gigabyte B850M Gaming X WIFI6E AM5 Micro ATX Motherboard GA-B850M-GAMING-X-WF6E (Copy)<h4>Features</h4> 🔹 CPU & Chipset: AMD Ryzen™ 9000/8000/7000 (AM5), B850 chipset 🔹 <a href="https://bermorzone.com.ph">Memory:</a> 4 x DDR5 (up to 256GB, 8200MT/s OC, EXPO/XMP) 🔹 Graphics: HDMI 2.1 & DP 1.4 (Triple-display support) 🔹 Networking: Realtek® 2.5GbE LAN, Wi-Fi 6E, Bluetooth 5.3 🔹 Storage: 1 x PCIe 5.0 M.2, 1 x PCIe 4.0 M.2, 4 x SATA 6Gb/s 🔹 Expansion: 1 x PCIe 5.0 x16, 1 x PCIe 3.0 x16 (x4 mode) 🔹 USB Ports: USB-C (3.2 Gen 2), multiple USB 3.2 & 2.0 ports 🔹 Cooling & RGB: Multiple fan headers, ARGB Gen2 & RGB headers 🔹 Form Factor: Micro ATX (24.4cm x 24.4cm)

CPU AMD Socket AM5
Supports AMD Ryzen™ 9000/8000/7000 Series Processors
(Check GIGABYTE’s website for latest support list)
Chipset AMD B850
Memory DDR5 8200(OC) / 8000(OC) / 7800(OC) / 7600(OC) / 7200(OC) / 7000(OC) / 6800(OC) / 6666(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s
4 x DDR5 DIMM sockets (up to 256 GB)
Dual channel architecture
Supports non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16
Supports AMD EXPO™ & XMP profiles
Onboard Graphics Integrated AMD Radeon™ Graphics
1 x HDMI 2.1 port (4096×2160@60 Hz)
2 x DisplayPort 1.4 (3840×2160@144 Hz)
Supports triple display
Audio Realtek® Audio CODEC
High Definition Audio
2/4/5.1/7.1-channel (configurable via software)
LAN Realtek® GbE LAN chip (1 Gbps)
Expansion Slots 1 x PCIe x16 slot (from CPU):
– Ryzen™ 9000/7000: PCIe 5.0 x16
– Ryzen™ 8000 Phoenix 1: PCIe 4.0 x8
– Ryzen™ 8000 Phoenix 2: PCIe 4.0 x4
1 x PCIe x16 slot (Chipset): PCIe 3.0 x4
Storage Interface 1 x M.2 (M2A_CPU):
– Ryzen™ 9000/7000: PCIe 5.0 x4/x2
– Ryzen™ 8000: PCIe 4.0 x4/x2
1 x M.2 (M2B_CPU):
– Ryzen™ 9000/7000: PCIe 4.0 x4/x2
– Ryzen™ 8000 Phoenix 1: PCIe 4.0 x4/x2
– Ryzen™ 8000 Phoenix 2: PCIe 4.0 x2
4 x SATA 6Gb/s connectors
RAID support: RAID 0, 1, 5 (only Ryzen 9000), 10 (NVMe); RAID 0, 1, 10 (SATA)
USB Ports CPU:
– 1 x USB Type-C® (USB 3.2 Gen 1, back panel)
– 1 x USB 3.2 Gen 1 (back panel)
– 1 x USB 2.0/1.1 (back panel)
Chipset:
– 1 x USB Type-C® (USB 3.2 Gen 1, internal header)
– 4 x USB 3.2 Gen 1 ports (2 back panel, 2 internal header)
– 5 x USB 2.0/1.1 ports (1 back panel, 4 internal headers)
Internal I/O Connectors 1 x 24-pin ATX main power
1 x 8-pin ATX 12V power
CPU/System fan headers
Water cooling pump headers
Addressable RGB Gen2 & RGB LED strip headers
2 x M.2 Socket 3
4 x SATA 6Gb/s
Front panel, audio, USB 3.2/2.0 headers
Trusted Platform Module header
Reset/CMOS jumpers
Back Panel Connectors 1 x HDMI port
2 x DisplayPorts
1 x PS/2 keyboard/mouse port
1 x Q-Flash Plus button
1 x USB Type-C® (USB 3.2 Gen 1)
3 x USB 3.2 Gen 1 ports
2 x USB 2.0/1.1 ports
1 x RJ-45 LAN port
3 x Audio jacks
I/O Controller iTE® I/O Controller Chip
H/W Monitoring Voltage/Temperature/Fan speed/Water cooling flow rate detection
Fan fail warning
Fan speed control (depending on installed fan/pump)
BIOS 256 Mbit flash
AMI UEFI BIOS
Support for PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features Support for GIGABYTE Control Center (GCC)
Q-Flash and Q-Flash Plus
Smart Backup
Bundled Software Norton® Internet Security (OEM)
LAN bandwidth management software
Operating System Windows 11 64-bit
Windows 10 64-bit
Form Factor Micro ATX (24.4cm x 24.4cm)
