| CPU |
LGA1700 socket: Support for 14th, 13th, 12th Gen Intel® Core™, Pentium® Gold, Celeron®; L3 cache varies by CPU |
| Chipset |
Intel® B760 Express Chipset |
| Memory |
DDR4 3200/3000/2933/2666/2400/2133 MT/s; 2 x DDR4 DIMM slots up to 64GB; Dual channel; Supports ECC/non-ECC, XMP |
| Onboard Graphics |
Intel® HD Graphics: 1 x D-Sub 1920x1200@60Hz, 1 x HDMI 4096x2160@60Hz; HDMI 2.1, HDCP 2.3 |
| Audio |
Realtek® Audio CODEC; High Definition; 2/4/5.1/7.1-channel; S/PDIF Out support |
| LAN |
Realtek® GbE LAN chip, 1 Gbps |
| Expansion Slots |
CPU: 1 x PCIe x16 (PCIe 4.0) for GPU/NVMe; Chipset: 1 x PCIe x1 (PCIe 3.0) |
| Storage Interface |
CPU: 1 x M.2 PCIe 4.0 x4/x2 (M2A_CPU); Chipset: 1 x M.2 PCIe 4.0 x4/x2 (M2P_SB), 4 x SATA 6Gb/s; RAID 0/1/5/10 support |
| USB |
Chipset: 6 x USB 3.2 Gen 1 (4 back, 2 internal); 6 x USB 2.0/1.1 (2 back, 4 internal) |
| Internal I/O Connectors |
1 x 24-pin ATX, 1 x 8-pin ATX 12V, 1 CPU fan, 2 system fans, 1 RGB header, 2 x M.2 sockets, 4 x SATA 6Gb/s, front panel/audio/USB headers, S/PDIF, TPM, serial, Clear CMOS |
| Back Panel Connectors |
2 x USB 2.0/1.1, 1 x D-Sub, 1 x HDMI, 4 x USB 3.2 Gen 1, 1 x RJ-45, 3 x audio jacks |
| I/O Controller |
iTE® I/O Controller Chip |
| H/W Monitoring |
Voltage, temperature, fan speed, water cooling flow, fan fail warning, fan control |
| BIOS |
128 Mbit flash, AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features |
GIGABYTE Control Center (GCC), Q-Flash support |
| Bundled Software |
Norton® Internet Security (OEM), LAN bandwidth management software |
| Operating System |
Windows 11 64-bit, Windows 10 64-bit |
| Form Factor |
Micro ATX; 23.0cm x 21.5cm |
