Technical Specifications
| Category | Specifications |
|---|---|
| Processor | LGA1700 socket: Supports 13th and 12th Gen Intel Core, Pentium Gold, and Celeron processors. L3 cache varies by CPU. |
| Chipset | Intel B760 Express Chipset |
| Memory | 2 × DDR4 DIMM slots, up to 64 GB (32 GB per DIMM), dual-channel architecture. Supports DDR4 2133–5333 MT/s (OC). Supports ECC Un-buffered DIMM (non-ECC mode) and non-ECC DIMM. Supports XMP memory modules. |
| Onboard Graphics | Integrated Intel HD Graphics (CPU dependent). Ports: 1 × D-Sub (1920×1200@60 Hz), 1 × HDMI (4096×2160@60 Hz, HDMI 2.0, HDCP 2.3), 1 × DisplayPort (4096×2304@60 Hz, DP 1.2, HDCP 2.3). Supports up to 3 displays. |
| Audio | Realtek Audio CODEC, High Definition Audio, 2/4/5.1/7.1-channel support, S/PDIF Out support. |
| LAN | Realtek 2.5GbE LAN (2.5 Gbps / 1 Gbps / 100 Mbps). |
| Wireless Communication Module | AzureWave Wi-Fi AW-CB304NF (RTL8821CE): Wi-Fi 802.11a/b/g/n/ac, 2.4/5 GHz dual-band, Bluetooth 4.2, up to 433 Mbps. Intel Wireless-AC 9461: Wi-Fi 802.11a/b/g/n/ac, 2.4/5 GHz dual-band, Bluetooth 5.1, up to 433 Mbps. |
| Expansion Slots | 1 × PCIe 4.0 x16 slot (CPU), 1 × PCIe 3.0 x1 slot (Chipset). |
| Storage Interface | 2 × M.2 (PCIe 4.0 x4/x2 SSD support), 4 × SATA 6 Gb/s connectors. RAID 0, 1, 5, 10 support for SATA. |
| USB | 1 × USB Type-C (USB 3.2 Gen 1, rear). 5 × USB 3.2 Gen 1 (3 rear + 2 via header). 2 × USB 2.0 rear. 4 × USB 2.0 via internal headers. |
| Internal I/O Connectors | 24-pin ATX power, 8-pin ATX 12V power, 1 × CPU fan header, 3 × system fan headers, 1 × addressable LED header, 1 × RGB LED header, 2 × M.2 sockets, 4 × SATA, front panel header, front panel audio header, S/PDIF Out header, USB 3.2 Gen 1 header, 2 × USB 2.0 headers, TPM header, serial port header, Q-Flash Plus button, reset jumper, Clear CMOS jumper. |
| Back Panel Connectors | 2 × USB 2.0, 1 × PS/2 keyboard/mouse port, 2 × SMA antenna connectors, 1 × D-Sub, 1 × HDMI, 1 × DisplayPort, 3 × USB 3.2 Gen 1, 1 × USB Type-C (USB 3.2 Gen 1), 1 × RJ-45 LAN, 3 × audio jacks. |
| I/O Controller | iTE I/O Controller Chip |
| H/W Monitoring | Voltage, temperature, fan speed, water cooling flow rate detection, fan fail warning, fan speed control. |
| BIOS | 1 × 128 Mbit flash, AMI UEFI BIOS. Supports PnP 1.0a, DMI 2.7, WfM 2.0, SMBIOS 2.7, ACPI 5.0. |
| Unique Features | GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus support. |
| Bundled Software | Norton Internet Security (OEM version), LAN bandwidth management software. |
| Operating System | Supports Windows 11 64-bit and Windows 10 64-bit. |
| Form Factor | Micro ATX, 24.4 cm × 22.5 cm. |
