Name: Gigabyte GA-B650M-D3HP-AX Wi-Fi DDR5 AM5 m-ATX
Brand: PCWORX
SKU: 0000063504
Price: 8199.5 PHP
Availability: InStock

Gigabyte GA-B650M-D3HP-AX Wi-Fi DDR5 AM5 m-ATX

Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Description

B650M D3HP AX

AMD Socket AM5：Supports AMD Ryzen™ 7000/ Ryzen™ 8000/ Ryzen™ 9000 Series Processors
Unparalleled Performance：5+2+2 Phases Digital VRM Solution
Dual Channel DDR5：4*SMD DIMMs with AMD EXPO™ & Intel® XMP Memory Module Support
SuperSpeed Storage：PCIe 4.0 x4 M.2 Connector
EZ-Latch：PCIe x16 Slot with Quick Release Design
Fast Networks：Wi-Fi 6E 802.11ax & 2.5GbE LAN
Extended Connectivity：2*DP, HDMI
Smart Fan 6：Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
Q-Flash Plus：Update BIOS Without Installing the CPU, Memory and Graphics Card

Category	Specification
CPU	AMD Socket AM5; Supports Ryzen™ 7000 / 8000 / 9000 Series
Chipset	AMD B650
Memory	DDR5 8000(OC)–4800 MT/s; 4× DIMM up to 256GB; Dual-channel; Supports EXPO & XMP
Onboard Graphics	Radeon™ Graphics (CPU dependent) • 2× DisplayPort 3840×2160@144Hz • 1× HDMI 4096×2160@60Hz Supports triple-display
Audio	Realtek® Audio CODEC; HD Audio; 2/4/5.1/7.1-channel
LAN	Realtek® 2.5GbE LAN
Wireless	Realtek® Wi-Fi 6E RTL8852CE Wi-Fi 2.4/5/6GHz, BT 5.3, 11ax 160MHz
Expansion Slots	1× PCIe x16 (CPU): • Ryzen 7000/9000: PCIe 4.0 x16 • Ryzen 8000 P1: PCIe 4.0 x8 • Ryzen 8000 P2: PCIe 4.0 x4 Chipset: 1× PCIe 3.0 x1
Storage	• 1× M.2 (M2A_CPU) PCIe 4.0 x4/x2 • 1× M.2 (M2C_SB) PCIe 4.0 x4/x2 (22110/2280) • 4× SATA 6Gb/s • RAID 0/1/10
USB	CPU: • 1× USB-C (USB 3.2 Gen 1, rear) • 1× USB 3.2 Gen 1 (rear) • 1× USB 2.0 (rear) Chipset: • 2× USB 3.2 Gen 1 (rear) • 1× USB-C (USB 3.2 Gen 1, internal) • 2× USB 3.2 Gen 1 (internal) • 5× USB 2.0 (1 rear, 4 internal)
Internal I/O	24-pin ATX, 8-pin 12V CPU fan, 2× system fan 2× ARGB, 1× RGB 2× M.2 4× SATA Front panel, audio USB-C (3.2 Gen1), USB 3.2 Gen1, USB 2.0 TPM header Q-Flash Plus button Reset jumper, Clear CMOS
Back Panel	PS/2 1× USB-C (3.2 Gen1) 3× USB 3.2 Gen1 2× USB 2.0 HDMI, 2× DP RJ-45 LAN 3× audio jacks
I/O Controller	iTE® Controller Chip
H/W Monitoring	Voltage, Temperature, Fan speed, Fan fail, Speed control
BIOS	256Mbit AMI UEFI; PnP 1.0a, DMI 2.7, ACPI 5.0
Unique Features	GIGABYTE Control Center (GCC); Q-Flash; Q-Flash Plus
Bundled Software	Norton Internet Security; LAN management tools
OS Support	Windows 11 64-bit; Windows 10 64-bit
Form Factor	Micro ATX; 24.4 cm × 24.4 cm

Gigabyte GA-B650M-D3HP-AX Wi-Fi DDR5 AM5 m-ATX

Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Product form

B650M D3HP AX AMD Socket AM5：Supports AMD Ryzen™ 7000/ Ryzen™ 8000/ Ryzen™ 9000 Series Processors Unparalleled Performance：5+2+2 Phases Digital VRM... Read more

Free pickup in our shop(s) Free pickup in our shop(s)

SKU: 0000063504

1 in stock

₱8,199.50

Authorized Partner. Guaranteed Original Product

Available for SAME DAY DELIVERY for Metro Cities

Available for SAME DAY DELIVERY in DAVAO

Available for SAME DAY DELIVERY FOR PAID CUSTOMERS

Guaranteed secure & safe checkout.

Description

B650M D3HP AX

AMD Socket AM5：Supports AMD Ryzen™ 7000/ Ryzen™ 8000/ Ryzen™ 9000 Series Processors
Unparalleled Performance：5+2+2 Phases Digital VRM Solution
Dual Channel DDR5：4*SMD DIMMs with AMD EXPO™ & Intel® XMP Memory Module Support
SuperSpeed Storage：PCIe 4.0 x4 M.2 Connector
EZ-Latch：PCIe x16 Slot with Quick Release Design
Fast Networks：Wi-Fi 6E 802.11ax & 2.5GbE LAN
Extended Connectivity：2*DP, HDMI
Smart Fan 6：Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
Q-Flash Plus：Update BIOS Without Installing the CPU, Memory and Graphics Card

Category	Specification
CPU	AMD Socket AM5; Supports Ryzen™ 7000 / 8000 / 9000 Series
Chipset	AMD B650
Memory	DDR5 8000(OC)–4800 MT/s; 4× DIMM up to 256GB; Dual-channel; Supports EXPO & XMP
Onboard Graphics	Radeon™ Graphics (CPU dependent) • 2× DisplayPort 3840×2160@144Hz • 1× HDMI 4096×2160@60Hz Supports triple-display
Audio	Realtek® Audio CODEC; HD Audio; 2/4/5.1/7.1-channel
LAN	Realtek® 2.5GbE LAN
Wireless	Realtek® Wi-Fi 6E RTL8852CE Wi-Fi 2.4/5/6GHz, BT 5.3, 11ax 160MHz
Expansion Slots	1× PCIe x16 (CPU): • Ryzen 7000/9000: PCIe 4.0 x16 • Ryzen 8000 P1: PCIe 4.0 x8 • Ryzen 8000 P2: PCIe 4.0 x4 Chipset: 1× PCIe 3.0 x1
Storage	• 1× M.2 (M2A_CPU) PCIe 4.0 x4/x2 • 1× M.2 (M2C_SB) PCIe 4.0 x4/x2 (22110/2280) • 4× SATA 6Gb/s • RAID 0/1/10
USB	CPU: • 1× USB-C (USB 3.2 Gen 1, rear) • 1× USB 3.2 Gen 1 (rear) • 1× USB 2.0 (rear) Chipset: • 2× USB 3.2 Gen 1 (rear) • 1× USB-C (USB 3.2 Gen 1, internal) • 2× USB 3.2 Gen 1 (internal) • 5× USB 2.0 (1 rear, 4 internal)
Internal I/O	24-pin ATX, 8-pin 12V CPU fan, 2× system fan 2× ARGB, 1× RGB 2× M.2 4× SATA Front panel, audio USB-C (3.2 Gen1), USB 3.2 Gen1, USB 2.0 TPM header Q-Flash Plus button Reset jumper, Clear CMOS
Back Panel	PS/2 1× USB-C (3.2 Gen1) 3× USB 3.2 Gen1 2× USB 2.0 HDMI, 2× DP RJ-45 LAN 3× audio jacks
I/O Controller	iTE® Controller Chip
H/W Monitoring	Voltage, Temperature, Fan speed, Fan fail, Speed control
BIOS	256Mbit AMI UEFI; PnP 1.0a, DMI 2.7, ACPI 5.0
Unique Features	GIGABYTE Control Center (GCC); Q-Flash; Q-Flash Plus
Bundled Software	Norton Internet Security; LAN management tools
OS Support	Windows 11 64-bit; Windows 10 64-bit
Form Factor	Micro ATX; 24.4 cm × 24.4 cm
