Unobstructed Roll Axis Arm
An innovative framework elevates camera payload above the roll axis, keeping the camera's built-in display free of obstruction. After DJI introduced this concept, it has been embraced throughout the handheld gimbal industry.
| Category | Specification |
|---|---|
| Peripheral / Ports | |
| Accessory Connections | 1/4β, 3/8β mounting holes; Camera control port; Accessory port; USB-C; RSA port |
| Connections | Bluetooth 5.0, USB-C |
| Mobile Assistant Requirements | iOS 9+, Android 5.0+ |
| Intelligent Battery | |
| Model | RB2-2450mAh-7.2V |
| Type | 18650 LiPo |
| Capacity | 2450 mAh |
| Energy | 17.64 Wh |
| Battery Life | Up to 11 hours |
| Charging Time | 2.5 hours (5V/2A) |
| Charging Temperature | 5Β°C β 40Β°C |
| Working Performance | |
| Tested Payload | β€ 2.0 kg |
| Angular Vibration Range | Β±0.02Β° |
| Max Rotation Speed | 180Β°/s (Pan, Tilt, Roll) |
| Mechanical Movement | |
| Pan Range | 360Β° continuous |
| Tilt Range (mechanical) | -202.5Β° to +112.5Β° |
| Roll Range (mechanical) | -95Β° to +220Β° |
| Controlled Pan Range | 360Β° continuous |
| Controlled Tilt Range | -90Β° to +145Β° |
| Controlled Roll Range | Β±30Β° |
| Connectivity & Power | |
| Working Current | 0.2 A (static) |
| Frequency | 2.400 β 2.4835 GHz |
| Transmission Power | β€ 8 dBm |
| Operating Temperature | -20Β°C to 45Β°C |
| Physical Specs (Weight) | |
| Gimbal Weight | β 830 g (0.83 kg) |
| BG18 Grip Weight | β 258 g (0.258 kg) |
| Tripod Weight | β 160 g (0.16 kg) |
| Total (approx. assembled) | β 1.25 kg (gimbal + grip + tripod) |
| Dimensions | |
| Folded Size | 220 Γ 200 Γ 75 mm |
| Unfolded Size | 370 Γ 165 Γ 150 mm |
