| Key specifications
|
|
Feature
|
Specification |
| Ports
|
8 x 2.5GBASE-T Ethernet ports |
| Switching Capacity
|
40 Gbps |
| LAN Transfer Rate
|
10/100/1000/2500 Mbps |
| MAC Address Table
|
4K entries |
| Standards
|
IEEE 802.3, 802.3u, 802.3ab, 802.3bz, 802.3x, 802.1p, 802.3az |
| Features
|
IGMP Snooping, Quality of Service (QoS), Flow Control, Auto MDI/MDIX, Energy-Efficient Ethernet (EEE) |
| Installation
|
Plug-and-play, no configuration required |
| Design
|
Durable metal casing, fanless, desktop or wall-mount design |
| Dimensions
|
145×82×28145 cross 82 cross 28
|
|
145×82×28 |
|
mm |
| Weight
|
343 g |
| Power
|
12V/1A; Max consumption: 8.586 W |
| Operating Temperature
|
|
|
0 |
|
to
|
|
4040
|
|
40 |
|
°C |
More ports. Multi-Gigabit Ethernet.
Maximise network throughput with 2.5Gbps Multi-Gigabit Ethernet on each port of this compact 8-port switch. Whether it’s to connect to your core or create a network between devices, now you can easily start sharing an internet connection, files, music, and video, or for gaming without bottlenecks.
Plug-and-play convenience.
The DMS-108 is a plug-and-play device that requires no configuration to get started. Plug-and-play makes it easy to instantly create a network without any technical knowledge.
