| Standards |
• Wi-Fi 6 • IEEE 802.11ax/ac/n/a 5 GHz • IEEE 802.11ax/n/b/g 2.4 GHz
|
| Wi-Fi Speeds |
• AX3000 • 5 GHz: 2402 Mbps (802.11ax 160Mhz) • 2.4 GHz: 574 Mbps (802.11ax 40Mhz)
|
| Wi-Fi Range |
• Bedroom Houses • 5 * Fixed High Performance Antennas • Multiple antennas form a signal boosting array to cover more directions and large areas • Beamforming • Concentrates wireless signal strength towards clients to expand Wi-Fi range~ • High Power FEM • Improves transmission power to strengthen signal coverage
|
| Wi-Fi Transmission Power |
• CE:<20dBm (2.4GHz); <23dBm (5.15GHz~5.35GHz); <30dBm (5.47GHz~5.725GHz) • FCC:<30dBm (2.4GHz &5.15GHz~5.25GHz&5.725GHz~5.825GHz)
|
| Modes |
• Router Mode, Bridge Mode |
| Processor |
• 1G Arm9 Dual Core CPU |
| Ethernet Ports |
• 1 × Gigabit WAN Port • 3 × Gigabit LAN Ports
|
| Connectors & Buttons |
• Power On/Off, WPS, Reset Button |
| Power |
• 12V 1.5A DC |
| Wi-Fi Encryption |
• WPA, WPA2, WPA3 |
| Network Security |
• SPI Firewall • Access Control • IP & MAC Binding • Application Layer Gateway • DDoS Attack Prevention
|
| Guest Network |
• 1 × 5 GHz Guest Network • 1 × 2.4 GHz Guest Network
|
| Protocols |
• IPv4, IPv6 |
| WAN Types |
• DHCP, Static IP, PPPoE |
| Easy Mesh |
• Easy Mesh™ Supported • Coverage your whole home with 3 x Devices
|
| NAT Forwarding |
• Port Forwarding, DMZ, UPnP |
| IPTV |
• IGMP Proxy, IGMP Snooping, Bridge, Tag VLAN |
| DHCP |
• DHCP Client List, Server |
| DDNS |
• DynDNS |
| Management |
• Web based Configuration (HTTP) • Remote Management • Telnet Management • TR069 • TR143 • TR181 • TR098 • Web Based Firmware Upgrade • CWMP • Diagnostic Tools
|
| Package Contents |
• Wi-Fi Router • Power Adapter • RJ45 Ethernet Cable • Quick Installation Guide
|
| System Requirements |
• Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser • Cable or DSL Modem (if needed) • Subscription with an internet service provider (for internet access)
|
| Certifications |
• CE, FCC |
| Environment |
• Operating Temperature: 0℃~40℃ • Storage Temperature: -40℃~70℃ • Operating Humidity: 10%~90% non-condensing • Storage Humidity: 5%~90% non-condensing
|
