Description
Upgrade to Gigabit Networking
With data transfer speeds of up to 2000 Mbps at full-duplex, these switches are ideal for quick file transfers, online gaming and smooth streaming media. They feature easy-to-access Ethernet ports with LED indicators per port to easily distinguish link status.
Conserve Energy
The DGS-1024C supports IEEE 802.3az Energy-Efficient Ethernet, which saves energy and reduces heat automatically without sacrificing performance or functionality. The switches can detect when a connected computer is shut down or when there is no Ethernet traffic and can automatically reduce the power used for that port, cutting power usage substantially.
Reliable Plug and Play Installation
The DGS-1024C is a plug-and-play device that requires no configuration, so setup is simple and hassle-free, and you can easily connect multiple computers, share files, music, and video across your home or small office network, or even create a multiplayer gaming environment.
Smooth Streaming
These switches support QoS, which prioritizes network traffic so that time sensitive data is delivered efficiently, even during bursts of high data traffic. This helps ensure an optimal experience for streaming media and VoIP calls.
SPECIFICATION
|
Interfaces
|
24 x 1000Base-T |
| Auto MDI/MDIX |
| 120G CXP |
|
Switching Capacity
|
48Gbps |
|
Maximum Forwarding Rate
|
35.712 Mpps |
|
Store & Forwarding Forwading
|
Yes |
|
Dimensions
|
282.2 x 178 x 44.5 mm (11.11 in. x 7.01 in. x 1.75 in.) |
|
Weight
|
1.14 kgs |
|
Max Power Consumption
|
13.5 watts |
|
Standby Power Consumption
|
6.5 watts |
|
Maximum Heat Dissipation
|
46.035 BTU/h |
|
MTBF
|
247,291 hours |
|
Power Input
|
AC:100 ~ 240 V |
|
Packet Buffer Size
|
512KBytes |
|
FAN
|
Fanless |
|
Comply with RoHS 6
|
Yes |
|
Energy Efficiency Ethernet (EEE)
|
Yes |
|
MAC Address Table Size
|
16000 |
|
Control
|
802.3x Flow |
|
Head-of-line (HOL) Blocking Prevention
|
Yes |
|
Jumbo Frame
|
9,216 Bytes |
|
Switch intelligence
|
Unmanaged |
|
Acoustic
|
0 dB |
|
Humidity
|
Storage: 5% ~ 95% RH |
| Operating: 10% ~ 90% RH |
|
Temperature
|
Operating: 0 ~ 40 °C |
| Storage: - 40 ~ 70 °C |
|
Power Saving
|
By Link Status |
| By Cable Length |
