| Print: Print Head / Ink |
| Type:
|
Fine Cartridge |
| Number of Nozzles:
|
Total 1,280 nozzles |
| Ink Cartridges: |
PG-47, CL-57S |
| (Optional: CL-57) |
| Maximum Printing Resolution:
|
4800 (horizontal)*1 x 1200 (vertical) dpi |
| Print Speed*2 |
| Based on ISO/IEC 24734 |
| Document (ESAT/Simplex) |
| Approx. 8.8 ipm (black) / 4.4 ipm (colour) |
| Printable Width |
| Up to 203.2 mm (8 inch) |
| Printable Area |
| Bordered Printing |
| Top margin:
|
3 mm, Bottom margin: 16.7 mm, Left/Right margin: 3.4 mm (LTR: Left: 6.4 mm, Right: 6.3 mm) |
| Recommended Printing Area |
| Top Margin |
| 31.6 mm |
|
| Bottom Margin |
| 29.2 mm |
|
| Paper Size |
| A4, A5, B5, Letter, Legal, 4x6", 5x7", Envelopes (DL, COM10), Custom size (width 101.6 - 215.9 mm, length 152.4 - 676 mm) |
| * F4 is possible via custom size settings. |
| Paper Handling Rear Tray (Maximum Number) |
| Plain Paper |
| A4, A5, B5, Letter = 60 |
| Legal = 10 |
|
| Photo Paper Plus Glossy II (PP-201) |
| 4x6" = 20, 5x7" = 10 |
| Glossy Photo Paper (GP-508) |
| 4x6" = 20 |
|
| Envelope |
|
| European DL / US Com. #10=5 |
| Paper Weight |
| Rear Tray |
|
| Plain Paper:
|
64-105 g/m², |
| Canon specialty paper:
|
max paper weight: approx. 275 g/m² (Photo Paper Plus Glossy II, PP-201) |
| Ink End Sensor |
| Dot count |
| Print Head Alignment |
| Manual |
|
| Scan*3 |
|
| Scanner Type |
| Flatbed |
|
| Scanner Method |
| CIS (Contact Image Sensor) |
| Optical Resolution*4 |
| Optical resolution scan is available, only when you use TWAIN Driver. |
| 600 x 1200 dpi |
| Selectable Resolution*5 |
| 25 - 19200 dpi |
| Scanning Bit Depth (Input/Output) |
| Grayscale |
|
| 16 bit/8 bit |
| Colour |
|
| 48 bit / 24 bit (RGB each 16 bit / 8 bit) |
| Line Scanning Speed*6 |
| Grayscale |
|
| 1.2 ms/line (300 dpi) |
| Colour |
|
| 3.5 ms/line (300 dpi) |
| Scanning Speed*7 |
| Reflective (A4 Colour / 300dpi) |
| Approx. 19 sec |
| Maximum Document Size |
| Flatbed |
|
| A4/LTR (216 x 297 mm) |
| Copy |
|
| Maximum Document Size |
| Flatbed |
|
| A4/LTR (216 x 297 mm) |
| Compatible Media |
| Size |
|
| A4, Letter |
| Type |
|
| Plain Paper |
| Image Quality |
| Plain Paper: Draft, Standard |
| Copy Speed*8 |
| Based on ISO/IEC 24734 |
|
|
| Measurement Conditions |
| Document (sFCOT/Simplex) |
| Approx. 30 sec |
| Document (sESAT/Simplex) |
| Approx. 1.8 ipm |
| Multiple Copy |
| Black/Colour: |
| 1 - 21 pages |
| System Requirements*9 |
| Windows 10 / 8 / 7 SP1, Windows Vista SP2 |
| Mac OS X 10.8.5 and later |
| Interface |
|
| Hi-Speed USB 2.0 |
| Operating Environment*10 |
| Temperature |
| 5 - 35°C |
|
| Humidity |
|
| 10 - 90% RH (no dew condensation) |
| Recommended Environment*11 |
| Temperature |
| 15 - 30°C |
|
| Humidity |
|
| 10 - 80% RH (no dew condensation) |
| Storage Environment |
| Temperature |
| 0 - 40°C |
|
| Humidity |
|
| 5 - 95% RH (no dew condensation) |
| Quiet Mode |
| Available |
|
| Acoustic Noise*12 (PC Print) |
| 46.0 dB(A) |
| Power |
|
| AC 100-240 V, 50/60 Hz |
| Power Consumption |
| OFF |
|
| Approx. 0.4 W |
| Standby (Scanning lamp is off) |
| Approx.1.0 W |
| Copying*13 |
| Approx. 9 W |
| Printing*14 |
| Approx. 9 W |
| Dimension (WxDxH) |
| Approx. 426 x 306 x 145 mm |
| Weight |
|
| Approx. 3.4 kg |
| Page Yield |
| Plain Paper (A4 pages) |
| (ISO/IEC 24712 test file)*15 |
| Standard: PG-47: 400 |
| CL-57S: 180 |
| Optional: CL-57: 300 |
