Description
Output
• Output power capacity: 450Watts / 800VA
• Max Configurable Power (Watts): 450Watts / 800VA
• Nominal Output Voltage: 230V
• Output Frequency (not synced): 50/60 Hz +/-1 Hz
• Topology: Line Interactive
• Waveform type: Stepped approximation to a sinewave
• Transfer Time: 6ms typical : 10ms maximum
Input
• Nominal Input Voltage: 230V
• Input frequency: 50/60 Hz +/- 5 Hz (auto sensing)
• Input Connections: IEC-320 C14
• Cord Length: 1.52meters
• Number of Power Cords: 1
Batteries & Runtime
• Battery type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
• Expected Battery Life (years): 3 - 5
• Efficiency: View Efficiency Graph
Communications & Management
• Control panel:LED Status display with On Line : On Battery
• Audible Alarm: Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Physical
• Maximum Height: 92mm, 9.25CM
• Maximum Width: 160mm, 16.05CM
• Maximum Depth: 305mm, 30.5CM
• Net Weight: 5.3KG
• Shipping weight: 5.6KG
• Shipping Height: 237mm, 23.7CM
• Shipping Width: 143mm, 14.3CM
• Shipping Depth: 373mm, 37.3CM
• SCC Codes: 1073130433837 3
Environmental
• Operating Temperature: 0 - 40 °C
• Operating Relative Humidity: 0 - 90 %
• Operating Elevation: 0-1968.3meters
• Audible noise at 1 meter from surface of unit: 40.0dBA
Conformance
• Approvals: CE
• Sustainable Offer Status
• RoHS: CompliantREACH
• REACH: Contains No SVHCs
