Specifications
|
U32G4
|
|
EAN Code
|
6973985233159
|
|
Picture / Display
|
|
|
LCD Panel Type
|
Fast IPS LCD with Hardware Low Blue Light tech
|
|
Backlight Type
|
W-LED system
|
|
Panel Size
|
32"
|
|
Effective Viewing Area (mm)
|
698.112 (H) × 392.688 (V)
|
|
Aspect Ratio
|
16 : 9
|
|
Optimum Resolution
|
3840 × 2160 @ 160Hz–DisplayPort1.4, HDMI2.1
1920 × 1080 @ 320Hz–DisplayPort1.4, HDMI2.1
|
|
Scan Frequency
|
UHD:30K~360KHz (H) / 48~160Hz (V)
FHD:30K~360KHz (H) / 48~320Hz (V)
|
|
Smart Response Time (typical)
|
0.3ms MPRT /1ms GtG
0.3ms MPRT@320Hz/0.5ms MPRT@160Hz)
|
|
Response Time (typical)
|
5ms GtG
|
|
Brightness (Peak for HDR)
|
450 cd/m²
|
|
Brightness (typical)
|
350 cd/m²
|
|
Smart Contrast
|
80 Million : 1 / MEGA DCR
|
|
Contrast Ratio (typical)
|
1000:1
|
|
Pixel Pitch (mm)
|
0.1818(H) × 0.1818 (V)
|
|
Viewing Angle
|
178° (H) / 178° (V) (CR > 10)
|
|
Display Colors
|
16.7 Million
|
|
Color Gamut
|
NTSC 104% (CIE1976) / sRGB 119% (CIE1931) / DCI-P3 95% (CIE1976)
|
|
Color Accuracy :
|
Delta E < 2
|
|
Low Input Lag
|
Yes
|
|
PxP (PIP, PBP)
|
Yes
|
|
HDR
|
HDR400
|
|
HDR Mode
|
Yes
|
|
Gaming Motion Technology
|
Adaptive Sync (G-sync compatible under testing)
|
|
Connectivity
|
|
|
Signal Input
|
HDMI 2.1 × 2
DisplayPort 1.4 × 1
|
|
HDCP Version
|
HDMI: 2.2 / DisplayPort: 2.2
|
|
MHL
|
no
|
|
USB Hub
|
no
|
|
Line In/Earphone
|
Earphone
|
|
Other
|
|
|
Convenience
|
|
|
Built-in Speakers
|
no
|
|
User Controls
|
Source / Exit
Dial Point / Up
Dual Resolution / Down
Menu / Enter
Power
|
|
OSD Languages
|
Japanese
Simplified Chinese
Traditional Chinese
Korean
Russian
Czech
Polish
Finnish
Swedish
Dutch
Italian
German
Portuguese
Spanish
French
English
|
|
Plug & Play Compatibility
|
DDC / CI
|
|
Software Certification
|
Windows 11
|
|
Stand
|
|
|
Height Adjustment
|
130 mm
|
|
Pivot
|
—90°~ 90°
|
|
Swivel
|
—20° ~20°
|
|
Tilt
|
—5° ~ 23°
|
|
Power
|
|
|
Smart Power Mode: Maximum
|
88W
|
|
Smart Power Mode: Typical
|
40W
|
|
Standby Mode
|
0.5W
|
|
Off Mode
|
0.3W
|
|
Power LED Indicator
|
Operating: White
|
|
Standby: Orange
|
|
Power Supply
|
Internal 100 - 240V～1.5A, 50 / 60Hz
|
|
Dimensions
|
|
|
Product without Stand (mm)
|
424.3 (H) × 716.1 (W) × 61.4 (D)
|
|
Product with Stand (mm)
|
462~592 (H) × 716.1 (W) × 269.6 (D)
|
|
Packaging (mm)
|
527(H) × 980 (W) × 226 (D)
|
|
Wall Mount
|
100mm × 100mm
|
|
Weight
|
|
|
Product without Stand
|
5.72 kg
|
|
Product with Stand
|
8.22 kg
|
|
Product with Packaging
|
11.37 kg
|
|
Operating Conditions
|
|
|
Temperature Range (Operating)
|
0° ~ 40°
|
|
Relative Humidity (Operating)
|
10% ~ 85%
|
|
Altitude (Operating)
|
0 ~ 5000m (0 ~ 16404 ft)
|
|
MTBF
|
—
|
|
Storage Conditions
|
|
|
Temperature Range (Storage)
|
—20° ~ 55°
|
|
Relative Humidity (Storage)
|
5% ~ 93%
|
|
Altitude (Storage)
|
0 ~ 12192m (0 ~ 40000 ft)
|
|
Sustainability
|
|
|
Environmental and Energy
|
RoHS
|
|
Recyclable Packaging Material
|
—
|
|
Compliance and Standards
|
|
|
Regulatory Approvals
|
BSMI
KC / KCC / e-Standby
RCM / MEPS
CE
|
|
Cabinet
|
|
|
Color
|
Black & Red
|
