| Specifications |
|
|
| Model name: 24B30H2/BW |
|
|
| EAN: 697 398523 218 3 |
|
|
| Panel: 23.8" / IPS |
|
|
| Pixel Pitch (mm): 0.2745 (H) × 0.2745 (V) |
|
|
| Effective Viewing Area (mm): 527.04 (H) × 296.46 (V) |
|
|
| Brightness (typical): 300 cd/m² |
|
|
| Contrast Ratio: 1300 : 1 (typical) 20 Million : 1 (DCR) |
|
|
| Response Time: 1ms MPRT / 4ms (GtG) |
|
|
| Viewing Angle: 178° (H) / 178° (V) (CR > 10) |
|
|
| Color Gamut: NTSC 95% (CIE1976) / sRGB 106% (CIE1931) |
|
|
| Color Accuracy - |
|
|
| Optimum Resolution: 1920 × 1080 @ 120Hz – HDMI (OC); 1920 × 1080 @ 75Hz – VGA |
|
|
| Display Colors: 16.7 Million |
|
|
| Signal Input: HDMI 1.4 × 1, VGA × 1 |
|
|
| HDCP Version: HDMI : 1.4 |
|
|
| USB Hub: No |
|
|
| Power Supply: External 19VDC, 1.31A |
|
|
| Power Consumption (typical): 20W |
|
|
| Speakers: No |
|
|
| Line in & Earphone: No |
|
|
| Wall-Mount: 100mm × 100mm |
|
|
| Adjustable Stand: Tilt: -5° ~ 23° |
|
|
| Product without Stand (mm): 321.2 (H) × 540.6 (W) × 34.8 (D) |
|
|
| Product with Stand (mm): 415.4 (H) ×540.6 (W) × 185.9 (D) |
|
|
| Packaging (mm): 372 (H) × 615 (W) × 93 (D) |
|
|
| Product without Stand (kg): 2.28 |
|
|
| Product with Stand (kg): 2.54 |
|
|
| Product with Packaging (kg): 4.12 |
|
|
| Cabinet Color: Black & White |
|
|
| Regulatory Approvals: CE / FCC / RoHS |
|
|
| What's in the box: HDMI Cable 1.8m × 1 |
|
|
| * Design and specifications are subject to change without notice. |
