| Model name |
22B15HN |
| EAN |
697 398523 297 8 |
| Panel |
21.45" / VA |
| Pixel Pitch (mm) |
0.2493 (H) × 0.241 (V) |
| Effective Viewing Area (mm) |
478.656 (H) × 260.28 (V) |
| Brightness (typical) |
250 cd/m² |
| Contrast Ratio |
3000 : 1 (typical) |
| Response Time |
4ms (GtG) |
| Viewing Angle |
178° (H) / 178° (V) (CR > 10) |
| Color Gamut |
NTSC 102% (CIE1976) / sRGB 122% (CIE1931) |
| Color Accuracy |
- |
| Optimum Resolution |
1920 × 1080 @ 100Hz – HDMI; 1920 × 1080 @ 75Hz – VGA |
| Display Colors |
16.7 Million |
| Signal Input |
VGA × 1, HDMI 1.4 × 1 |
| HDCP Version |
- |
| USB Hub |
No |
| Power Supply |
External 12VDC, 2.0A |
| Power Consumption (typical) |
17W |
| Speakers |
No |
| Line in & Earphone |
No |
| Wall-Mount |
75mm x 75mm |
| Adjustable Stand |
Tilt: - 5° ~ 20° |
| Product without Stand (mm) |
492.3 (W) × 285.7 (H) × 35.3 (D) |
| Product with Stand (mm) |
492.3 (W) × 367.1 (H) × 184.8 (D) |
| Packaging (mm) |
565 (W) × 385 (H) × 115 (D) |
| Product without Stand (kg) |
1.8 |
| Product with Stand (kg) |
2.2 |
| Product with Packaging (kg) |
3.2 |
| Cabinet Color |
Black |
| Regulatory Approvals |
CE / RoHS |
| What's in the box |
HDMI Cable 1.5m × 1 |
