Adlink AD-OUF601-C FTP Cat6E 305M 0.5MM CCA Outdoor

Description

General specs
Model:  AD-OUF601-C
Category:  Cat6E
Length:  305 meters (1000 ft)
Application:  High-performance data transfer for outdoor installations, telecommunications, CCTV, computer networking, and POE power supply
Conductor and material specs
Conductor material:  Copper Clad Aluminum (CCA)
Conductor thickness:  0.5mm
Conductor size:  24AWG or 23AWG
Conductor structure:  Solid
Number of conductors:  4 Pairs (8 total)
Insulator material:  HDPE
Insulation thickness:  0.18mm
Performance and physical specs
Shielding:  FTP (Foil Twisted Pair) with unshielded twisted pairs
Filler:  PE CROSS
Jacket material:  PVC+HDPE
Jacket thickness:  0.65mm (±0.02mm)
Stretching resistance:  (max) 400N
Impedance:

100±15%Ω100 plus or minus 15 % cap omega
100±15%Ω
at 1~250MHz
Transmission velocity:  66%
Working capacitance:  5.4nf/100m
Insulation resistance:

10000MΩ⋅km10000 cap M cap omega center dot k m
10000𝑀Ω⋅𝑘𝑚
Operating temperature:

-40 ∘Cnegative 40 space raised to the composed with power cap C
−40 ∘𝐶
to

+70 ∘Cpositive 70 space raised to the composed with power cap C
+70 ∘𝐶

Adlink AD-OUF601-C FTP Cat6E 305M 0.5MM CCA Outdoor

Product form

General specs  Model:  AD-OUF601-C Category:  Cat6E Length:  305 meters (1000 ft) Application:  High-performance data transfer for outdoor installations, telecommunications, CCTV,... Read more

Out of stock

₱3,500.00

    • Authorized Partner. Guaranteed Original Product
    • Available for SAME DAY DELIVERY for Metro Cities
    • Available for SAME DAY DELIVERY in DAVAO
    • Available for SAME DAY DELIVERY FOR PAID CUSTOMERS

    • Guaranteed secure & safe checkout.

    Description

    General specs
    Model:  AD-OUF601-C
    Category:  Cat6E
    Length:  305 meters (1000 ft)
    Application:  High-performance data transfer for outdoor installations, telecommunications, CCTV, computer networking, and POE power supply
    Conductor and material specs
    Conductor material:  Copper Clad Aluminum (CCA)
    Conductor thickness:  0.5mm
    Conductor size:  24AWG or 23AWG
    Conductor structure:  Solid
    Number of conductors:  4 Pairs (8 total)
    Insulator material:  HDPE
    Insulation thickness:  0.18mm
    Performance and physical specs
    Shielding:  FTP (Foil Twisted Pair) with unshielded twisted pairs
    Filler:  PE CROSS
    Jacket material:  PVC+HDPE
    Jacket thickness:  0.65mm (±0.02mm)
    Stretching resistance:  (max) 400N
    Impedance:

    100±15%Ω100 plus or minus 15 % cap omega
    100±15%Ω
    at 1~250MHz
    Transmission velocity:  66%
    Working capacitance:  5.4nf/100m
    Insulation resistance:

    10000MΩ⋅km10000 cap M cap omega center dot k m
    10000𝑀Ω⋅𝑘𝑚
    Operating temperature:

    -40 ∘Cnegative 40 space raised to the composed with power cap C
    −40 ∘𝐶
    to

    +70 ∘Cpositive 70 space raised to the composed with power cap C
    +70 ∘𝐶
