| Key specifications | |
|
Feature
|
Specification |
| Ports | 8 x 2.5GBASE-T Ethernet ports |
| Switching Capacity | 40 Gbps |
| LAN Transfer Rate | 10/100/1000/2500 Mbps |
| MAC Address Table | 4K entries |
| Standards | IEEE 802.3, 802.3u, 802.3ab, 802.3bz, 802.3x, 802.1p, 802.3az |
| Features | IGMP Snooping, Quality of Service (QoS), Flow Control, Auto MDI/MDIX, Energy-Efficient Ethernet (EEE) |
| Installation | Plug-and-play, no configuration required |
| Design | Durable metal casing, fanless, desktop or wall-mount design |
| Dimensions |
|
| 145×82×28 | |
| mm | |
| Weight | 343 g |
| Power | 12V/1A; Max consumption: 8.586 W |
| Operating Temperature |
|
| 0 | |
|
to
|
|
| 40 | |
| °C | |
More ports. Multi-Gigabit Ethernet.
Maximise network throughput with 2.5Gbps Multi-Gigabit Ethernet on each port of this compact 8-port switch. Whether it’s to connect to your core or create a network between devices, now you can easily start sharing an internet connection, files, music, and video, or for gaming without bottlenecks.
Plug-and-play convenience.
The DMS-108 is a plug-and-play device that requires no configuration to get started. Plug-and-play makes it easy to instantly create a network without any technical knowledge.
