Hikvision Hi-Watch E-HWIB 2.8mm 2MP IR Network Mini Bullet IPCAM | CCTV
Product properties
Camera
Appearance : Bullet
Image Sensor : 1/2.8" progressive scan CMOS
Min. Illumination : Color: 0.01 Lux @(F1.2, AGC ON), 0.028 Lux @ (F2.0, AGC ON)
Shutter Speed : 1/3 s to 1/100, 000 s
Slow Shutter : Yes
Auto-Iris : No
Day & Night : IR cut filter
Digital Noise Reduction : 3D DNR
WDR : DWDR
Angle Adjustment : Pan: 0° to 360°, tilt: 0° to 180°, rotation: 0° to 360°
Lens
Focal Length : 2.8 mm, 4 mm
Aperture : F2.0
Focus : Fixed
Angle of view : 2.8 mm, horizontal FOV 114.8°, vertical FOV 62°, diagonal FOV 135.5°
4 mm, horizontal FOV 86°, vertical FOV 46.5°, diagonal FOV 102.5°
Lens Mount : M12
IR
IR Range : Up to 30 m
Wavelength : 850 nm
Compression Standard
Video Compression
Main stream: H.265+/H.265/H.264+/H.264
Sub stream: H.265/H.264/MJPEG
H.264 Type : Main Profile/High Profile/Baseline Profile
H.265 Type : Main Profile
Video Bit Rate : 32 Kbps to 8 Mbps
Smart Feature-Set
Region of Interest : 1 fixed region for main stream
Resolution : 2MP
Main Stream Max. Frame Rate
• 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)
• 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-stream Max. Frame Rate
• 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
• 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Image Enhancement : BLC, 3D DNR
Image Setting : Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
Day/Night Switch : Auto, scheduled, day, night
Network
Alarm Trigger : Motion detection, video tampering alarm, illegal login
Protocols : TCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, UDP
General Function : Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark
API : ONVIF (PROFILE S), ISAPI
Simultaneous Live View Up to 6 channels
User/Host
• Up to 32 users
• 3 levels: Administrator, Operator, and User
Client : iVMS-4200, Hik-Connect
Web Browser : IE8+, Chrome 31.0-44, Firefox 30.0-51
Interface
Communication Interface : 1 RJ45 10M/100M self-adaptive Ethernet port
General
Operating Conditions : -30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing)
Power Supply : 12 VDC ± 25%, 5.5 mm coaxial power plug
PoE (802.3af, class 3)
Power Consumption : 12 VDC, 0.3 A, Max: 3.5 W
PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, Max: 4.5 W
Ingress Protection level : IP67
Material : Front cover: metal, camera body: plastic, bracket: plastic
Dimensions : Ø 70 mm × 181.6 mm (Ø 2.8" × 7.1")
Weight
• Camera: Approx. 270 g (0.6 lb.)
• With package: Approx. 510 g (1.1 lb.)
