₱288.00
| Specifications | |
| Main | |
| Range of product | |
| AvatarOn A | |
| Product or component type | |
| Socket-outlet | |
| Device presentation | |
| Complete product | |
| Colour tint | |
| White | |
| Outlet poles configuration | |
| 2P + E | |
| Colour tint | |
| White | |
| Complementary | |
| Rated current | |
| 16 A at 250 V AC 50...60 Hz | |
| Socket number | |
| 1 | |
| Clamping connection capacity | |
| 2 x 1.5...2 x 4 mm² for solid cable(s) | |
| 2 x 1.5...2 x 4 mm² for stranded cable(s) | |
| Connections - terminals | |
| Screwless terminals | |
| Material | |
| Polycarbonate grid plate | |
| Polycarbonate cover | |
| Device mounting | |
| Flush | |
| Width | |
| 120 mm | |
| Height | |
| 70 mm | |
| Depth | |
| 30.3 mm | |
| Embedding depth | |
| 19 mm | |
| Environment | |
| IP degree of protection | |
| IP20 | |
| Maximum ambient air temperature for operation | |
| 35 °C | |
| Ambient air temperature for storage | |
| -5…45 °C | |
| Relative humidity | |
| 0…95 % | |
| Operating altitude | |
| < 2000 m | |
| Standards | |
| IEC 60884-1 | |
| Product certifications | |
| IEC | |
| Packing Units | |
| Unit Type of Package 1 | |
| PCE | |
| Number of Units in Package 1 | |
| 1 | |
| Package 1 Height | |
| 3 cm | |
| Package 1 Width | |
| 7 cm | |
| Package 1 Length | |
| 12 cm | |
| Package 1 Weight | |
| 137 g | |
| Unit Type of Package 2 | |
| BB1 | |
| Number of Units in Package 2 | |
| 10 | |
| Package 2 Height | |
| 8.8 cm | |
| Package 2 Width | |
| 18.5 cm | |
| Package 2 Length | |
| 26.5 cm | |
| Package 2 Weight | |
| 1.476 kg | |
| Unit Type of Package 3 | |
| S03 | |
| Number of Units in Package 3 | |
| 60 | |
| Package 3 Height | |
| 30 cm | |
| Package 3 Width | |
| 30 cm | |
| Package 3 Length | |
| 40 cm | |
| Package 3 Weight | |
| 9.506 kg | |
₱288.00
Estimated delivery between March 16 and March 18.
Delivery Information
Metro Manila: 2–3 days | Provincial: 3–7 days
Main Office Branch only
Same Day Delivery
Same-Day Delivery Available
Processing starts 1–2 hours after checkout Mon–Sat | Main Office Branch only
Processing only during office hours from Main Office 9am - 5pm
₱288.00
₱288.00
Authorized Seller
100% Original Authentic Product
